NFC 33-209: Aerial Bundled Cables UV Resistance Coated Overhead Aluminum Cable

NFC 33-209: Aerial Bundled Cables HDPE PVC XLPE insulation UV resistance coated overhead aluminum cable



1.Applications
            Aerial Bundle Cable (ABC cable) is a very innovative concept for overhead power distribution as compared to the conventional bare conductor overhead distribution system. It provides higher level of safety and reliability, lower power losses and ultimate system economy by reducing installation,maintenance and operative cost. The cables are designed for aerial power lines and room-entrance wires with AC rated voltage 1kV and below.
2.Standards
         GB/T12527,1179 ,IEC60502 ,NFC 33-209 ,BS 7870 ,ANSI/ICEA S-76-474  AS/NZS 3560.1 etc.
 *HONGDA can also design and produce for special application requirement.
3.Production Range
          Rated Voltage U0/U(Um) (kV) : 0.6/1(1.2) No. of cores : 1 , 2 , 3, 4 , 5, 3+1 , 4+1 ,3+2
Nominal cross-section(mm2): 10~240
4.Construction
           Phase conductors :Round standed or compacted 1350-H19 aluminium or Copper conductor ,AAAC,ACSR
Neutral or messenger conductor :Round standed or compacted 6201 aluminium alloy or AAC ,,ACSR
Street lighting conductor: Round standed or compacted Aluminium conductor

Note: The above provisions can be changed as order.

Standard
NFC 33-209: Aerial Bundled Cables
ICEA S-76-474: Standard for Neutral-supported Power Cable Assemblies with Weather-resistant Extruded Insulation Rated 600 Volts

Application
This 16mm aluminium xlpe cable (usually twisted by 2~4 cores) is used in overhead power distribution lines of rated voltage 600/1000V and below. With the XLPE insulation, it can be installed near the buildings, trees in downtown areas.
Product Details
1) Phase conductor: stranded 1350 aluminum, 7/1.70 mm
2) Insulation: XLPE, 1.2 mm
3) Overall diameter: 7.2 mm
4) Approx. weight: 66 kg/km
5) Max. DC resistance at 20 degrees: 1.91 ohm/km
6) Max. working temperature: 90 degrees

 Standard Aerial Bundled Conductor (ABC) Cables
