Low Voltage Aluminium Wire Bare Alloy Porter Axka Cable 3X35+16+50mm

Low Voltage Aluminium Wire Bare Alloy Porter Axka Cable 3X35+16+50mm image

Get Latest Price Request a quote

Product Details

Model NO.

AXKA Cable

Current

AC Cable

Insulation Material

XLPE

Sheath Material

N/a

Material Shape

Round Wire

Wire Core Material

Aluminum

Certification

ISO, CCC, SGS

Model

Amka Cable

Brand

Hongda

Rated Voltage

600/1000V

Transport Package

Export Wooden Drum

Specification

10mm to 150mm

Trademark

Hongda or OEM

Origin

China

HS Code

8544492100

Production Capacity

2000km/Month

Product Description

Low voltage (0.6-1kV) Aluminium wire Bare Alloy Porter AXKA Cable 3X35+16+50

Low voltage (0.6-1kV) Aluminium wire Bare Alloy Porter AXKA Cable

1. AXKA Cable Specification

	Aluminium Compacted Conductor
	Black HDPE /XLPE Insulation
	Longitudinal Ridges
	Public lighting
	Bare Alloy Porter
	Uo/U = 0.6/1 kV, Um = 1.2 kV
	Maximum Operating Temperature : 90°C
	Maximum Short Circuit Temperature : 250°C

2. AXKA Cable Application

Low voltage (0.6-1kV) Aluminium wire Bare Alloy Porter AXKA Cable used in power supply in power transmission and distribution line.

It is prefered to use of ABC cables instead of uninsulated conductors at low voltage networks. ABC cables are especially used at areas where the cost of underground networks is expensive and also for electrification of rural areas like villages.

3. AXKA Cable Standard

SFS 2200 HD 626-5D.

We can also manufacture AXKA Cable according to customer’s special requirements.

4. Construction

The basic construction is as follows:
3 power cores consisting of standard aluminum conductors, insulated with XLPE insulation
+ One sheath lighting aluminum conductor with XLPE insulation(optional)
+ One messenger Al-alloy conductor (bare or covered)
The messenger conductor can be of galvanized steel wire also.
The purpose of messenger wire is:
A) It acts as load bearing wire.
B) It acts as earth or neutral conductor.

OPTIONS

AXKA Cable can be manufactured with the following options:

Phase Conductor
Other voltage
Other section
Netural conductor
Insulation Thickness

Cable type	Phase area	Messenger area	Lighting area	Overall diameter whole cable (approx)	Net weight of cable, nominal value	Maximum DC resistance of phase 20ºC	Maximum DC resistance of messenger 20ºC
TWISTED OVERHEAD CABLE AXKA 1 X 16+25	16	25	–	11	135	1.91	1.38
TWISTED OVERHEAD CABLE AXKA 3 X 16+25	16	25	–	20	270	1.91	1.38
TWISTED OVERHEAD CABLE AXKA 4 X 16+25	16	25	–	22	330	1.91	1.38
TWISTED OVERHEAD CABLE AXKA 3 X 25+35	25	35	–	23	390	1.2	0.986
TWISTED OVERHEAD CABLE AXKA 3 X 25+16+35	25	35	16	25	465	1.2	0.986
TWISTED OVERHEAD CABLE AXKA 3 X 35+50	35	50	–	27	530	0.868	0.72
TWISTED OVERHEAD CABLE AXKA 3 X 35+16+50	35	50	16	29	610	0.868	0.72
TWISTED OVERHEAD CABLE AXKA 3 X 35+70	35	70	–	31	670	0.868	0.493
TWISTED OVERHEAD CABLE AXKA 3 X 50+70	50	70	–	31	700	0.641	0.493
TWISTED OVERHEAD CABLE AXKA 3 X 70+95	70	95	–	36	1000	0.443	0.363
TWISTED OVERHEAD CABLE AXKA 3 X 120+95	120	95	–	42	1500	0.253	0.363
