Duplex Triplex Quadruplex Aluminum Service Drop and Secondary Cables

Duplex Triplex Quadruplex Aluminum Service Drop and Secondary Cables image

Get Latest Price Request a quote

Product Details

Model NO.

Secondary cables

Current

AC Cable

Insulation Material

XLPE

Sheath Material

Crosslinking

Material Shape

Round Wire

Wire Core Material

Aluminum

Certification

CCC, SGS

Model

Overhead Power Transmission and Distribution Lines

Brand

Hongda

Voltage Rating

12/20kv or 18/30 Kv.

Operating Temperature

90c Continues Normal Operation

Transport Package

Steel & Wooden Drum

Specification

1.6*1.1

Trademark

Hongda Cable

Origin

Made in China

HS Code

8544601200

Production Capacity

600km/Month

Product Description

SERVICE DROP AND SECONDARY CABLES

Duplex, Triplex, Quadruplex Aluminum

Application

Duplex: Neutral supported secondary distribution cables and neutral supported service drop cables, one (1), 2 or 3 black polyethylene insulated stranded aluminum (AAC) conductor and one (1) bare ACSR neutral conductor as supporting/messenger member, for use in circuits not exceeding 600 volts phase to phase at maximum conductor temperature of 75°C (LDPE or LLDPE), 90 C (XLPE)
Triplex: Self-supporting secondary and service drop cable, two (2) black polyethylene insulated stranded aluminum (AAC) conductor and one (1) bare ACSR neutral conductor as supporting member, for use in circuits not exceeding 600 volts phase to phase at maximum conductor temperature of 75°C
Quadruplex: Self-supporting secondary and service drop cable, three (3) black polyethylene insulated stranded aluminum (AAC) conductor and one (1) bare ACSR neutral conductor as supporting member, for use in circuits not exceeding 600 volts phase to phase at maximum conductor temperature of 75°C

Specifications

ASTM B230
ASTM B231
ASTM B232
ASTM B498
ANSI/ICEA S 70 – 547
ICEA S-76-474
ICEA S 61-402

Features

Economical
Lightweight
Weather resistant
High dielectric strength
High impact/Abrasion resistant

SERVICE DROP AND SECONDARY CABLES STRUCTURE:

Construction:
Three insulated phase conductors twisted around a bare aluminum alloy or ACSR neutral conductor.
Conductors: Aluminum alloy 1350-H19 wire.
Insulation: Black thermoset cross-linked polyethylene (XLPE).
Neutral: Bare aluminum alloy or ACSR.

Phase Conductor	stranded aluminum wires (AAC)
Insulation	black thermosetting cross-linked polyethylene (XLPE)
	thermoplastic low density polyethylene (LDPE)
	thermoplastic high density polyethylene (HDPE)
Neutral	stranded aluminum wires (AAC)
	stranded aluminum alloy wires (AAAC)
	stranded aluminum conductor steel reinforced (ACSR)

SERVICE DROP AND SECONDARY CABLES Specifications:

Code Word	AWG or kcmil	Bare Neutral Messenger			Phase Conductor			Weight kg/km	Allowable Ampacities
		AAC		Rated Strength	AAC		insul. Thick. mm		XLPE	PE
		Number	Dia. mm	Rated Strength	Number	Dia. mm	insul. Thick. mm		XLPE	PE
Pekingese	1×6+1×6 (AWG)	7	1.56	563	1	4.11	1.14	92	85	70
Collie	1×6+1×6 (AWG)	7	1.56	563	7	1.56	1.14	94	85	70
Dachshund	1×4+1×4 (AWG)	7	1.96	881	1	5.19	1.14	139	115	90
Spaniel	1×4+1×4 (AWG)	7	1.96	881	7	1.96	1.14	141	115	90
Doberman	1×2+1×2 (AWG)	7	2.47	1350	7	2.47	1.14	216	150	120
Malemute	1×1/0+1×1/0 (AWG)	7	3.12	1990	19	1.89	1.52	347	205	160

Code Word	AWG or kcmil	Bare Neutral Messenger					Phase Conductor			Weight kg/km	Allowable Ampacities
		ACSR				Rated Strength	AAC		insul. Thick. mm		XLPE	PE
		Number	Dia. mm	Number	Dia. mm	Rated Strength	Number	Dia. mm	insul. Thick. mm		XLPE	PE
Setter	1×6+1×6 (AWG)	1	1.68	6	1.68	1190	1	4.11	1.14	111	85	70
Shepherd	1×6+1×6 (AWG)	1	1.68	6	1.68	1190	7	1.56	1.14	113	85	70
Eskimo	1×4+1×4 (AWG)	1	2.12	6	2.12	1860	1	5.19	1.14	171	115	90
Terrier	1×4+1×4 (AWG)	1	2.12	6	2.12	1860	7	1.96	1.14	173	115	90
Chow	1×2+1×2 (AWG)	1	2.67	6	2.67	2850	7	2.47	1.14	266	150	120
Bull	1×1/0+1×1/0 (AWG)	1	3.37	6	3.37	4380	19	1.89	1.52	427	205	160

Code Word	AWG or kcmil	Bare Neutral Messenger			Phase Conductor			Weight kg/km	Allowable Ampacities
		AAAC		Rated Strength	AAC		insul. Thick. mm		XLPE	PE
		Number	Dia. mm	Rated Strength	Number	Dia. mm	insul. Thick. mm		XLPE	PE
Chihuahua	1x6AWG+1×30.58	7	1.68	1110	1	4.11	1.14	98	85	70
Vizsla	1x6AWG+1*30.58	7	1.68	1110	7	1.56	1.14	100	85	70
Harrier	1x4AWG+1×48.69	7	2.12	1760	1	5.19	1.14	149	115	90
Whippet	1x4AWG+1×48.69	7	2.12	1760	7	1.96	1.14	151	115	90
Schnauzer	1x2AWG+1×77.47	7	2.67	2800	7	2.47	1.14	231	150	120
Heeler	1×1/0AWG+1×123.3	7	3.37	4460	19	1.89	1.52	372	205	160

Please contact us for technical support with the right cable selection for your power distribution projects and to discuss your maintenance or project specific requirements. We provide tailored solutions for this cable range which include storage, cutting to length, and 2 days collection as standard.

Packing & Delivery

Packing

Steel wooden drum (fumigation)

Cable length in each drum: 1000m/2000m or as per actual cable length requirements.

Drum size:

As per cable length and container size

*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!

Shipping Port:

Shanghai, Qingdao, Tianjin or other ports as per your requirements.

Sea freight:

FOB/C&F/CIF/DAP quotation are all available.
