China Supplier Low Voltage & Medium Voltage Wire Cable XLPE/PVC Copper Electrical Cable

China Supplier Low Voltage & Medium Voltage Wire Cable XLPE/PVC Copper Electrical Cable image

Get Latest Price Request a quote

Product Details

Model NO.

electrical cable

Current

DC & AC

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC

Model

YJV

Brand

Hongda

Rated Voltage

1-35kv

Transport Package

Wooden Drum and Drums

Specification

1mm2-400mm2

Trademark

OEM

Origin

China, Henan

HS Code

8544492100

Production Capacity

5000km/Year

Product Description

China Supplier Low voltage wire cable xlpe/pvc copper electrical cable

High voltage copper/ aluminum conductor, single core , or multi-core, stranded wires, XLPE insulated, PVC sheath. range of voltage is from 0.6/1KV to 35KV, cross section area of conductor is from 25mm2, 35mm2, 50mm2, 70mm2 …. to 240mm2, 300mm2, 400mm2, 500mm2, 630mm2. There XLPE Cables can be armoured with steel tape, steel wire, aluminum wire. or you can require more functions such as flame retardant etc for your special purpose of application.

International Standards such as IEC60502 is complied, or other Standard can be adoped as you required.

XLPE insulated power cable has advantages of not only high mechanical strength, good ambient stress resistance, good electrical properties and anti-chemical corrossion, but also simple costruction, light weight, convenient to be used. It applies to electrical power transmission and distribution power supply.

Cable construction
Construction	According to IEC 60502-1
Conductor	Aluminum wires solid or stranded class 1 or 2, according to IEC 60228
Conductor
Insulation	XLPE/PVC compound
Cable core	Insulated cores are twisted
Inner sheath	Polymer tapes
Metal screen	STEEL tapes
Sheath	PVC compound
Color	black
	Conductors type
re	circular, solid conductor
rm	circular, stranded conductor
sm	sector, stranded conductor

Technical Parameters

IEC 60502-1

Number of co C1s and size		Insulation thickness	Outer sheath thickness	Outer diameter	Weight of cable
mm2		mm	mm	D approx. mm	approx. kg/km
1 x	16 C2	0,7	1,4	9,5	215
1 x	25 C2	0,9	1,4	11,0	310
1 x	35 C2	0,9	1,4	12,0	410
1 x	50 C2	1,0	1,4	13,5	540
1 x	70 C2	1,1	1,4	15,5	745
1 x	95 C2	1,1	1,5	17,5	1010
1 x	120 C2	1,2	1,5	19,0	1250
1 x	150 C2	1,4	1,6	21,0	1535
1 x	185 C2	1,6	1,6	23,5	1910
1 x	240 C2	1,7	1,7	26,0	2470
1 x	300 C2	1,8	1,8	28,5	3080
1 x	400 C2	2,0	1,9	32,0	3995
2 x	1,5 C1	0,7	1,8	10,5	145
2 x	2,5 C1	0,7	1,8	11,0	180
2 x	4 C1	0,7	1,8	12,0	225
2 x	6 C2	0,7	1,8	13,5	310
2 x	10 C2	0,7	1,8	15,0	420
2 x	16 C2	0,7	1,8	17,5	600
2 x	25 C2	0,9	1,8	20,5	880
2 x	35 C2	0,9	1,8	23,0	1160
3 x	1,5 C1	0,7	1,8	10,5	165
3 x	2,5 C1	0,7	1,8	11,5	210
3 x	4 C1	0,7	1,8	12,5	265
3 x	6 C2	0,7	1,8	14,5	370
3 x	10 C2	0,7	1,8	16,0	515
3 x	16 C2	0,7	1,8	18,5	750
3 x	25 C2	0,9	1,8	21,5	1110
3 x	35 C2	0,9	1,8	24,5	1475
3 x	50 C2	1,0	1,8	26,5	1865
3 x	70 C2	1,1	1,9	31,5	2680
3 x	95 C2	1,1	2,0	35,5	3600
3 x	120 C2	1,2	2,1	39,5	4515
3 x	150 C2	1,4	2,3	44,0	5555
3 x	185 C2	1,6	2,4	48,5	6930
3 x	240 C2	1,7	2,6	55,0	9010
3 x	300 C2	1,8	2,8	61,0	11195
4 x	1,5 C1	0,7	1,8	11,5	190
4 x	2,5 C1	0,7	1,8	12,5	245
4 x	4 C1	0,7	1,8	13,5	320
4 x	6 C2	0,7	1,8	15,5	445
4 x	10 C2	0,7	1,8	17,0	635
4 x	16 C2	0,7	1,8	20,0	930
4 x	25 C2	0,9	1,8	23,5	1390
4 x	35 C2	0,9	1,8	26,5	1850
4 x	50 C2	1,0	1,9	30,5	2450
4 x	70 C2	1,1	2,0	34,5	3410
4 x	95 C2	1,1	2,1	39,5	4640
4 x	120 C2	1,2	2,3	44,0	5780
4 x	150 C2	1,4	2,4	48,5	7075
4 x	185 C2	1,6	2,6	54,5	8965
4 x	240 C2	1,7	2,8	61,0	11510
4 x	300 C2	1,8	3,0	67,5	14370
5 x	1,5 C1	0,7	1,8	12,5	225
5 x	2,5 C1	0,7	1,8	13,5	290
5 x	4 C1	0,7	1,8	14,5	380
5 x	6 C2	0,7	1,8	17,0	540
5 x	10 C2	0,7	1,8	19,0	775
5 x	16 C2	0,7	1,8	21,5	1135
5 x	25 C2	0,9	1,8	27,0	1780
7 x	1,5 C1	0,7	1,8	13,5	275
7 x	2,5 C1	0,7	1,8	14,5	360
12 x	1,5 C1	0,7	1,8	17,0	450
12 x	2,5 C1	0,7	1,8	19,0	595
19 x	1,5 C1	0,7	1,8	20,0	615
19 x	2,5 C1	0,7	1,8	22,0	850
24 x	1,5 C1	0,7	1,8	23,0	785
24 x	2,5 C1	0,7	1,8	25,5	1050
27 x	1,5 C1	0,7	1,8	23,5	840
27 x	2,5 C1	0,7	1,8	26,0	1135
37 x	1,5 C1	0,7	1,8	26,0	1060
37 x	2,5 C1	0,7	1,8	29,0	1485

More products:

Power cables 0,6/1 kV

High-voltage cables 3,6-30 kV

PVC cables

PVC control cables

High flexible cables

Halogen-free cables and flame-resistant cables

Communication and phone cables

Instrumentation Cables

Factory Picture:

We are China China Supplier Low Voltage & Medium Voltage Wire Cable XLPE/PVC Copper Electrical Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
