Product Details

Model NO.

XLPE Insulated Service Cable (SDW)

Application

Overhead

Conductor Material

Aluminum

Sheath Material

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Aerial Overhead

Certification

ISO9001, CCC

Brand

Hongda

Standard

IEC, NFC33 209

Transport Package

Wooden Drum or as Customer Requirement

Specification

6mm2 to 120mm2

Trademark

Hongda Cable

Origin

China

HS Code

8544492100

Production Capacity

2400km/Month

Product Description

ASTM Standard XLPE Insulated Service Cable Sdw Cable

1. 0.6/1kV, ASTM Standard XLPE Insulated Service Cable Sdw Cable

1.1 Application

Bundle conductor for overhead distribution network without and with public lighting. (between pole to pole)

1.2 Construction:

Conductor Phase	Stranded All Aluminium conductor (AAC)
Neutral/Messenger	Stranded All Alloy Aluminium Conductor (AAAC)
Insulation	Extrude of XLPE, capable for continous operation at maximum cable’s temperature.

Item #	Phase conductor size AWG	Phase conductor stranding	Phase conductor Insulation Thickness	Bare Neutral Messenger Size AWG	Bare Neutral Messenger Stranding	Bare Neutral Messenger breaking strength	Weight Per 1000ft-XLP	Weight Per 1000ft-Poly	Ampacity -XLP	Ampacity -Poly
Clydesdale	4	7/w	45 mls	4	7	881 Lbs	208 Lbs	201.8 Lbs	100 Amps	80 Amps
Pinto	4	7/w	45 mls	4	7	881 Lbs	223 Lbs	207.9 Lbs	100 Amps	80 Amps
Mustang	2	19/w	45 mls	2	7	1350 Lbs	333 Lbs	312.6 Lbs	135 Amps	105 Amps
Criollo	1/0	19/w	60 mls	1/0	7	1990 Lbs	529 Lbs	504.5 Lbs	180 Amps	140 Amps
Percheron	2/0	19/w	60 mls	2/0	7	2510 Lbs	649 Lbs	620.5 Lbs	205 Amps	160 Amps
Hanoverian	3/0	19/w	60 mls	3/0	19	3310 Lbs	799 Lbs	765.6 Lbs	235 Amps	185 Amps
Oldenburg	4/0	19/w	60 mls	4/0	19	4020 Lbs	986 Lbs	946.7 Lbs	275 Amps	210 Amps
Morochuca	6	7/w	45 mls	6	6/1	1190 Lbs	152 Lbs	147.4 Lbs	75 Amps	60 Amps
Chola	6	Solid	45 mls	6	6/1	1190 Lbs	162 Lbs	151.7 Lbs	75 Amps	60 Amps
Morgan	4	7/w	45 mls	4	6/1	1860 Lbs	226 Lbs	220 Lbs	100 Amps	80 Amps
Hackney	4	7/w	45 mls	4	6/1	1860 Lbs	241 Lbs	226.1 Lbs	100 Amps	80 Amps
Palomino	2	19/w	45 mls	2	6/1	2850 Lbs	362 Lbs	342.6 Lbs	135 Amps	105 Amps
Costena	1/0	19/w	60 mls	1/0	6/1	4380 Lbs	575 Lbs	550.6 Lbs	180 Amps	140 Amps
Grullo	2/0	19/w	60 mls	2/0	6/1	5310 Lbs	707 Lbs	678.7 Lbs	205 Amps	160 Amps
Suffolk	3/0	19/w	60 mls	3/0	6/1	6620 Lbs	872 Lbs	838.9 Lbs	235 Amps	185 Amps
Appaloosa	4/0	19/w	60 mls	4/0	6/1	8350 Lbs	1079 Lbs	1039.2 Lbs	275 Amps	210 Amps
Bronco	336.4	19/w	80 mls	336.4	6/1	8580 Lbs	1613 Lbs	1568.2 Lbs	370 Amps	280 Amps
Gelding	336.4	19/w	80 mls	4/0	6/1	8350 Lbs	1548 Lbs	1494.3 Lbs	370 Amps	280 Amps
Bay	6	Solid	45 mls	6	7	1110 Lbs	145 Lbs	140.0 Lbs	75 Amps	60 Amps
French Coach	6	7/w	45 mls	6	7	1110 Lbs	155 Lbs	144.3 Lbs	75 Amps	60 Amps
German Coach	4	Solid	45 mls	4	7	1760 Lbs	214 Lbs	208.3 Lbs	100 Amps	80 Amps
Arabian	4	7/w	45 mls	4	7	1760 Lbs	229 Lbs	214.4 Lbs	100 Amps	80 Amps
Belgian	2	7/w	45 mls	2	7	2800 Lbs	344 Lbs	323.1 Lbs	135 Amps	105 Amps
Shetland	1/0	19/w	60 mls	1/0	7	4460 Lbs	546 Lbs	521.1 Lbs	180 Amps	140 Amps
Thoroughbred	2/0	19/w	60 mls	2/0	7	5390 Lbs	670 Lbs	641.5 Lbs	205 Amps	160 Amps
Trotter	3/0	19/w	60 mls	3/0	7	6790 Lbs	825 Lbs	791.8 Lbs	235 Amps	185 Amps
Walking	4/0	19/w	60 mls	4/0	7	8560 Lbs	1019 Lbs	979.7 Lbs	275 Amps	210 Amps

1.3 Classification:

Low Voltage Cable Aerial Bundled Conductor, Twisted Cable

Physical Properties
Cable size	Insulation Thickness			Approx Maximum Diameter			Approx. Net. Weight	Standard Length
Cable size	Phase	Neutral / Messenger	Public Lighting	Phase	Neutral/Messenger	Public Lighting	Approx. Net. Weight	Standard Length
mm2	mm	mm	mm	mm	mm	mm	kg/km	m
2×25+25	1.4	1.4	–	10.0	10.0	10.0	338	500
2×35+25	1.6	1.4	–	11.2	10.0	10.0	394	500
2×50+35	1.6	1.6	–	12.6	11.2	11.2	526	500
2×70+50	1.8	1.6	–	15.4	12.6	12.6	760	500
2×95+70	2.0	1.8	–	17.0	15.4	15.4	975	500
3×25+25	1.4	1.4	–	10.0	10.0	10.0	452	500
3×35+25	1.6	1.4	–	11.2	10.0	10.0	537	500
3×50+35	1.6	1.6	–	12.6	11.2	11.2	717	500
3×70+50	1.8	1.6	–	15.4	12.6	12.6	1057	500
3×95+70	2.0	1.8	–	17.0	15.4	15.4	1360	500
3×25+25+2×16	1.4	1.4	1.2	10.0	10.0	8.1	602	500
3×35+25+2×16	1.6	1.4	1.2	11.2	10.0	8.1	687	500
3×50+35+2×16	1.6	1.6	1.2	12.6	11.2	8.1	867	500
3×70+50+2×16	1.8	1.6	1.2	15.4	12.6	8.1	1207	500
3×95+70+2×16	2.0	1.8	1.2	17.0	15.4	8.1	1510	500
3×25+25+16	1.4	1.4	1.2	10.0	10.0	8.1	527	500
3×35+25+16	1.6	1.4	1.2	11.2	10.0	8.1	612	500
3×50+35+16	1.6	1.6	1.2	12.6	11.2	8.1	792	500
3×70+50+16	1.8	1.6	1.2	15.4	12.6	8.1	1132	500
3×95+70+16	2.0	1.8	1.2	17.0	15.4	8.1	1435	500

2. NF2X / NFA2X
Aerial Bundled Conductor , Twisted Cable

2.1 Application:

Bundle conductor for overhead distribution network without and with public lighting. (between pole to pole)

2.2 Construction

Conductor	NF2X : Stranded Copper Conductor NFA2X : Stranded All Aluminium Conductor (AAC)
Insulation	Extrude of XLPE

2.3 Classification

Low Voltage Cable

Physical Properties					Electrical Properties
Cable Size	Insulation Thickness	Approx. Twisted Diameter	Approx. Net. Weight	Max. Conductor Resistance at 20ºC	Current Carrying Capacity at 35ºC	Calculated Breaking Force	Standard Length
mm2	mm	mm	kg/km	ohm/km	A	kg	m
NF2X (Copper Conductor)
2×6 rm	1.2	13.0	136	3.080	54	394	2000
2×10 rm	1.2	14.0	211	1.830	73	656	2000
2×16 rm	1.2	16.0	334	1.150	97	1051	1000
4×6 rm	1.2	15.7	258	3.080	54	788	1000
4×10 rm	1.2	17.0	422	1.830	73	1312	1000
4×16 rm	1.2	19.0	664	1.150	97	2102	1000
4×25 rm	1.4	24.0	1008	0.727	133	3284	1000
NFA2X (All Aluminum Conductor)
2×10 rm	1.2	14.0	94	3.080	54	322	2000
2×16 rm	1.2	16.0	138	1.910	72	515	1000
4×10 rm	1.2	17.0	187	3.080	54	644	1000
4×16 rm	1.2	19.0	272	1.910	72	1030	1000
4×25 rm	1.4	24.0	423	1.200	102	1610	1000
4×35 rm	1.6	27.0	564	0.868	125	2250	1000

*Further information about rating factor for certain cable arrangement can be found on supplementary technical information.

For more information, don’t hesitate to contact us on +86-15838290725

We are China ASTM Standard XLPE Insulated Service Cable Sdw Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
