Aeroprex Baxb - Aerial Bundle Cable 0.6/1 Kv

Aeroprex Baxb - Aerial Bundle Cable 0.6/1 Kv image

Get Latest Price Request a quote

Product Details

Model NO.

AEROPREX BAXB

Application

Overhead

Conductor Material

Aluminum

Sheath Material

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Aerial Overhead

Certification

ISO9001, CCC

Brand

Hongda

Standard

HD 626-4b

Transport Package

Wooden Drum or as Customer Requirement

Specification

6mm2 to 120mm2

Trademark

Hongda Cable

Origin

China

HS Code

8544492100

Production Capacity

3000km/Month

Product Description

AEROPREX BAXB – Aerial Bundle Cable 0.6/1 kV

STANDARDS:

CONSTRUCTION	FIRE PERFORMANCE
HD 626-4B	IEC 60754-2
	EN 60754-2
	IEC 60754-1
	EN 60754-1

CONSTRUCTION:

CONDUCTOR: Aluminium class 2 to IEC 60228.
INSULATION: Cross-linked polyethylene (XLPE).

APPLICATIONS:

Cable for low voltage power distribution. Outdoor installation in lines attached to fades. Not suitable for directly buried installation.

Maximum temperature rating of the conductor: +90 C

Physical and Electrical Characteristics:

Cross section (mm)	Nominal overall diameter (mm)	Nominal weight (kg/km)
2×16	14.4	135
3×16	15.6	200
3×35+54.6	26.2	620
3×35+54.6+16	28.6	685
3×35+54.6+2×16	28.6	750
3×70+54.6	31.5	945
3×70+54.6+16	32.1	1010
3×70+54.6+2×16	33.1	1075
3×70+54.6+25+2×16	33.4	1170
3×95+54.6	34.3	1175
3×95+54.6+16	34.5	1240
3×95+54.6+2×16	34.0	1305
3×95+54.6+25+2×16	36.0	1405
4×16	17.4	265
4×25	20.9	390

We are China Aeroprex Baxb - Aerial Bundle Cable 0.6/1 Kv manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
