Aerial Bundle Cable 11kv 33kv Aluminium Conductor 3+1core

Aerial Bundle Cable 11kv 33kv Aluminium Conductor 3+1core image

Get Latest Price Request a quote

Product Details

Model NO.

ABC Aerial Bundle Cable 11kv

Application

Overhead

Conductor Material

Aluminum

Sheath Material

XLPE/PE/PVC

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Overhead Cable

Certification

ISO9001, CE, CCC, RoHS

Brand

Hongda

Insulation

XLPE/PE/PVC

Core

Standard

IEC/NFC33-209

Quality Guarantee

10 Years

Sheath Color

Black

Mark

Laser Type

Manufacture

Yes

Sample

Yes

Cable Parts

Yes

Transport Package

Wooden Drum

Specification

11KV ABC cable

Trademark

Hongda

Origin

China, Henan

HS Code

8544492100

Production Capacity

3000km/Per Months

Product Description

Aerial Bundle Cable 11kV 33kV Aluminium Conductor 3+1core

Specifications and Standards

IEC
NFC 33-209
ASTM, BS, DIN

Construction

Stranded
Aluminum conductor
XLPE insulation Messenger wire

Applications

Aerial Bundle Conductor (ABC cable) is a very innovative concept for overhead power distribution as compared to the conventional bare conductor overhead distribution system. It provides higher level of safety and reliability, lower power losses and ultimate system economy by reducing installation, maintenance and operative cost. This system is ideal for rural distribution and it is especially perfect for installation in difficult terrains such as hilly areas, forest areas, coastal areas etc. ABC is also considered to be ideal for power distribution in congested urban areas with narrow lanes and by-lanes. In developing urban complex, ABC cable is the first choice because of its flexibility for re-routing as demanded by changes in urban development plan.

Standard:

ASTM B230, B231, B232,B399,B498, ICEA S-76-474 Standard

Construction

The phase conductors are concentrically stranded compressed 1350-H19 aluminum and insulated polyethylene or crosslinked polyethylene(XLPE), The neutral messengers are concentrically stranded AAC, ACSR, or 6201 aluminum alloy.The conductors are manufactured with ridges for phase identification(one conductor with one ridge,one conductor with two ridges ,one conductor is plain).

^{Packaging&Delivery}

Packaging Details:Wooden drums,steel wooden drums or as your requirement
Delivery Time:Normally within 10 days (detailly depend on the order quantity)

^{Contact us}

Looking forward to cooperation with you.If you have any questions or need our certification and sample.Pls contact me freely.You can talk with me by Email or chat software.

We are China Aerial Bundle Cable 11kv 33kv Aluminium Conductor 3+1core manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
