Low Voltage Aerial Bundled Cable/ Low Voltage ABC Cable
The basic construction is as follows:
3 power cores consisting of standard aluminium conductors, insulated withXLPE insulation
+ One sheath lighting aluminium conductor with XLPE insulation(optional)
+ One messenger Al-alloy conductor (bare or covered)
The messenger conductor can be of galvanised steel wire also.
The purpose of messenger wire is
A) It acts as load bearing wire.
B) It acts as earth or neutral conductor.
To be used at cotages of 600V phase-to-phase or less and at conductor temperatures not to exceed 75oC for polyethylene insulated conductors or 90oC for crossliked polyethylene(XLPE) insulated conductors.
Standards:
(1). BS 7870-5: Part 5: Polymeric insulated aerial bundled conductors (ABC) of rated voltage 0.6/1 kV for overhead distribution
| ABC Cables without Street Lighting | |||||||
| 1+1 Structure | |||||||
| Phase Conductor | Neutral Conductor | Completed Cable | |||||
| Section | Insulation Thickness | Electrical Resistance | Section | Insulation Thickness | Electrical Resistance | Overall Diameter | Cable Weight |
| DC.20°C | DC.20°C | ||||||
| No.xmm2 | mm | Ω/km | mm2 | mm | Ω/km | mm | kg/km |
| 1×25 | 1.3 | 1.20 | 25 | 1.3 | 1.20 | 17.6 | 210 |
| 1×35 | 1.3 | 0.868 | 35 | 1.3 | 0.868 | 19.6 | 270 |
| 1×50 | 1.5 | 0.641 | 50 | 1.5 | 0.641 | 23 | 360 |
| 1×70 | 1.5 | 0.443 | 70 | 1.5 | 0.443 | 26.4 | 500 |
| 1×95 | 1.7 | 0.320 | 95 | 1.7 | 0.320 | 30.6 | 680 |
| 3+1 Structure | |||||||
| Phase Conductor | Neutral Conductor | Completed Cable | |||||
| Section | Insulation Thickness | Electrical Resistance | Section | Insulation Thickness | Electrical Resistance | Overall Diameter | Cable Weight |
| DC.20°C | DC.20°C | ||||||
| No.xmm2 | mm | Ω/km | mm2 | mm | Ω/km | mm | kg/km |
| 3×25 | 1.3 | 1.20 | 25 | 1.3 | 1.20 | 21.2 | 410 |
| 3×35 | 1.3 | 0.868 | 35 | 1.3 | 0.868 | 23.7 | 550 |
| 3×50 | 1.5 | 0.641 | 50 | 1.5 | 0.641 | 27.8 | 730 |
| 3×70 | 1.5 | 0.443 | 70 | 1.5 | 0.443 | 31.9 | 1000 |
| 3×95 | 1.7 | 0.320 | 95 | 1.7 | 0.320 | 36.9 | 1370 |
| 3×120 | 1.7 | 0.253 | 120 | 1.7 | 0.253 | 40.6 | 1690 |
| ABC Cables with Street Lighting | |||||||
| 3+1+1 Structure | |||||||
| Phase Conductor | Neutral Conductor | Street Lighting Conductor | Completed Cable | ||||
| Section | Insulation Thickness | Section | Insulation Thickness | Section | Insulation Thickness | Overall Diameter | Cable Weight |
| No.xmm2 | mm | mm2 | mm | mm2 | mm | mm | kg/km |
| 3×50 | 1.5 | 50 | 1.5 | 25 | 1.3 | 29.8 | 830 |
| 3×70 | 1.5 | 70 | 1.5 | 25 | 1.3 | 33.6 | 1100 |
| 3×95 | 1.7 | 95 | 1.7 | 25 | 1.3 | 38.2 | 1470 |
Standards
BS 7870-5 Hongda cable can also design and produce for special application requirement.
Packaging&Delivery
Packaging Details:Wooden drums,steel wooden drums or as your requirement
Delivery Time:Normally within 10 days(detailly depend on the order quantity)
