Product Details
Model NO.
yjv yjlv yjv22 yjlv22 yjv32 yjlv32
Current
DC Cable
Insulation Material
XLPE
Sheath Material
PVC
Material Shape
Round Wire
Wire Core Material
Bare Copper Wire
Certification
ISO, CCC, SGS
Model
YJV
Brand
Hongda
Rated Voltage
0.6/1kv, 600/1000V, 1.1kv
Transport Package
500m or 1000m Per Drum
Specification
1.5-300 mm2
Trademark
Hongda or OEM
Origin
China
HS Code
8544492100
Production Capacity
4000 Km / Year
Product Description
yjv yjlv yjv22 yjlv22 yjv32 yjlv32 4x240mm2 cu xlpe pvc power cable
DESCRIPTION
CONSTRUCTION
- Conductor: Plain Annealed Copper, Class 2 Stranded Circular, Compacted or Sectored
- Insulation: Cross-linked Polyethylene (XLPE) Compound
- Insulation Color :
- 4 Cores: Brown, Black, Grey,Blue or Red, Yellow, Blue, Black
- Assembly :
- Cores cabled together with filler and covered with Polyester (PET) Tape
- Insulation Color :
- Outer Sheath: Polyvinyl Chloride (PVC) Compound Type ST 2
- Outer Sheath Color : Black
ELECTRICAL CHARACTERISTICS
- Operating Voltage, Uo/U : 0.6/1KV
- Operating Temperature : -15ºC to 90ºC
- Final Short Circuit Temperature : 250ºC
- Test Voltage : 3.5kV for 5 minutes
- Current Carrying Capacity
- Clipped Direct (Ref Method C)
- One 3 or 4-Core Cable, 3-Phase A.C : 73A
- In free air or on a perforated cable tray etc, horizontal or vertical (Ref method E)
- One 3 or 4-Core Cable, 3-Phase A.C : 78A
- Direct in Ground or in ducting in ground, in or around building (Ref method D)
- One 3 or 4-Core Cable, 3-Phase A.C : 58A
- Clipped Direct (Ref Method C)
REFERENCE STANDARD
- Design Specification: IEC60502-1
- Conductor: IEC60228, BS EN60228
- Flame Retardancy: IEC60332-1, BS EN60332-1
INSTALLATION REFERENCE
- Minimum Bending Radius(mm): 8 x cable overall diameter
- Max. Pulling Tension (N/mm2) : 70ºC
| Type | Description |
| VV 0.6/1kV | 0.6/1kV copper conductor, PVC insulation, PVC sheath, low voltage power cable |
| VLV 0.6/1kV | 0.6/1kV aluminum conductor, PVC insulation, PVC sheath, low voltage power cable |
| VV22 0.6/1kV | 0.6/1kV copper conductor, PVC insulation, PVC inner sheath, Galvanized steel tape armored, PVC outer sheath, low voltage power cable |
| VLV22 0.6/1kV | 0.6/1kV aluminum conductor, PVC insulation, PVC inner sheath, Galvanized steel tape armored, PVC outer sheath, low voltage power cable |
| VV32 0.6/1kV | 0.6/1kV copper conductor, PVC insulation, PVC inner sheath, Galvanized steel wire armored, PVC outer sheath, low voltage power cable |
| VLV32 0.6/1kV | 0.6/1kV aluminum conductor, PVC insulation, PVC inner sheath, Galvanized steel wire armored, PVC outer sheath, low voltage power cable |
| YJV 0.6/1kV | 0.6/1kV copper conductor, XLPE insulation, PVC sheath, low voltage power cable |
| YJLV 0.6/1kV | 0.6/1kV aluminum conductor, XLPE insulation, PVC sheath, low voltage power cable |
| YJV22 0.6/1kV | 0.6/1kV copper conductor, XLPE insulation, PVC inner sheath, Galvanized steel tape armored, PVC outer sheath, low voltage power cable |
| YJLV22 0.6/1kV | 0.6/1kV aluminum conductor, XLPE insulation, PVC inner sheath, Galvanized steel tape armored, PVC outer sheath, low voltage power cable |
| YJV32 0.6/1kV | 0.6/1kV copper conductor, XLPE insulation, PVC inner sheath, Galvanized steel wire armored, PVC outer sheath, low voltage power cable |
| YJLV32 0.6/1kV | 0.6/1kV aluminum conductor, XLPE insulation, PVC inner sheath, Galvanized steel wire armored, PVC outer sheath, low voltage power cable |
| YJY 0.6/1kV | 0.6/1kV copper conductor, XLPE insulation, PE sheath, low voltage power cable |
| YJLY 0.6/1kV | 0.6/1kV aluminum conductor, XLPE insulation, PE sheath, low voltage power cable |
| YJY23 0.6/1kV | 0.6/1kV copper conductor, XLPE insulation, PE inner sheath, Galvanized steel tape armored, PE outer sheath, low voltage power cable |
| YJLY23 0.6/1kV | 0.6/1kV aluminum conductor, XLPE insulation, PE inner sheath, Galvanized steel tape armored, PE outer sheath, low voltage power cable |
| YJY33 0.6/1kV | 0.6/1kV copper conductor, XLPE insulation, PE inner sheath, Galvanized steel wire armored, PE outer sheath, low voltage power cable |
| YJLY33 0.6/1kV | 0.6/1kV aluminum conductor, XLPE insulation, PE inner sheath, Galvanized steel wire armored, PE outer sheath, low voltage power cable |
| WDZ-YJE 0.6/1kV | 0.6/1kV copper conductor, XLPE insulation, low smoke zero halogen flame retardant sheath, low voltage power cable |
| WDZ-YJLE 0.6/1kV | 0.6/1kV aluminum conductor, XLPE insulation, low smoke zero halogen flame retardant sheath, low voltage power cable |
| WDZ-YJE23 0.6/1kV | 0.6/1kV copper conductor, XLPE insulation, low smoke zero halogen flame retardant inner sheath, Galvanized steel tape armored, low smoke zero halogen flame retardant outer sheath, low voltage power cable |
| WDZ-YJLE23 0.6/1kV | 0.6/1kV aluminum conductor, XLPE insulation, low smoke zero halogen flame retardant inner sheath, Galvanized steel tape armored, low smoke zero halogen flame retardant outer sheath, low voltage power cable |
| WDZ-YJE33 0.6/1kV | 0.6/1kV copper conductor, XLPE insulation, low smoke zero halogen flame retardant inner sheath, Galvanized steel wire armored, low smoke zero halogen flame retardant outer sheath, low voltage power cable |
| WDZ-YJLE33 0.6/1kV | 0.6/1kV aluminum conductor, XLPE insulation, low smoke zero halogen flame retardant inner sheath, Galvanized steel wire armored, low smoke zero halogen flame retardant outer sheath, low voltage power cable |
Note :
Conductor Shape
1.5 – 10 sqmm supplied in solid (re) or non compacted circular stranded (rm) conductor shape
16 sqmm supplied in non compacted circular stranded (rm) conductor shape
25 – 300 sqmm supplied in compacted circular stranded (cm) conductor shape
Standard Packing
1.5 – 50 sqmm supplied in wooden drum @ 1000 m
70 – 300 sqmm will be suplied in wooden drum on available length
Length Tolerance per drum ± 2%
| YJV / YJLV 1х1,5 – 1kV | YJV / YJLV 1х2,5 – 1kV | YJV / YJLV 1х4,0 – 1kV | YJV / YJLV 1х6,0 – 1kV | YJV / YJLV 1х10 – 1kV |
| YJV / YJLV 1х16 – 1kV | YJV / YJLV 1х25 – 1kV | YJV / YJLV 1х35 – 1kV | YJV / YJLV 1х50 – 1kV | YJV / YJLV 1х70 – 1kV |
| YJV / YJLV 1х95 – 1kV | YJV / YJLV 1х120 – 1kV | YJV / YJLV 1х150 – 1kV | YJV / YJLV 1х185 – 1kV | YJV / YJLV 1х240 – 1kV |
| YJV / YJLV 2х1,5 – 1kV | YJV / YJLV 2х1,5+1х1,0 – 1kV | YJV / YJLV 2х1,5+1х1,5 – 1kV | YJV / YJLV 2х2,5 – 1kV | YJV / YJLV 2х2,5+1х1,5 – 1kV |
| YJV / YJLV 2х4,0 – 1kV | YJV / YJLV 2х4,0+1х2,5 – 1kV | YJV / YJLV 2х6,0 – 1kV | YJV / YJLV 2х6,0+1х2,5 – 1kV | YJV / YJLV 2х6,0+1х4,0 – 1kV |
| YJV / YJLV 2х10 – 1kV | YJV / YJLV 2х10+1х4,0 – 1kV | YJV / YJLV 2х10+1х6,0 – 1kV | YJV / YJLV 2х16 – 1kV | YJV / YJLV 2х16+1х6,0 – 1kV |
| YJV / YJLV 2х16+1х10 – 1kV | YJV / YJLV 2х25 – 1kV | YJV / YJLV 2х25+1х10 – 1kV | YJV / YJLV 2х25+1х16 – 1kV | YJV / YJLV 2х35 – 1kV |
| YJV / YJLV 2х35+1х16 – 1kV | YJV / YJLV 2х50 – 1kV | YJV / YJLV 2х50+1х16 – 1kV | YJV / YJLV 2х50+1х25 – 1kV | YJV / YJLV 2х70 – 1kV * |
| YJV / YJLV 2х70+1х25 – 1kV | YJV / YJLV 2х70+1х35 – 1kV | YJV / YJLV 2х95 – 1kV * | YJV / YJLV 2х95+1х35 – 1kV | YJV / YJLV 2х95+1х50 – 1kV |
| YJV / YJLV 2х120 – 1kV * | YJV / YJLV 2х120+1х35 – 1kV | YJV / YJLV 2х120+1х70 – 1kV | YJV / YJLV 2х150 – 1kV * | YJV / YJLV 2х150+1х50 – 1kV |
| YJV / YJLV 2х150+1х70 – 1kV | YJV / YJLV 2х185 – 1kV * | YJV / YJLV 2х185+1х50 – 1kV | YJV / YJLV 2х185+1х95 – 1kV | YJV / YJLV 2х240 – 1kV * |
| YJV / YJLV 2х240+1х70 – 1kV | YJV / YJLV 2х240+1х120 – 1kV | YJV / YJLV 3х1,5 – 1kV | YJV / YJLV 3х1,5+1х1,0 – 1kV | YJV / YJLV 3х1,5+1х1,5 – 1kV |
| YJV / YJLV 3х2,5 – 1kV | YJV / YJLV 3х2,5+1х1,5 – 1kV | YJV / YJLV 3х4,0 – 1kV | YJV / YJLV 3х4,0+1х2,5 – 1kV | YJV / YJLV 3х6,0 – 1kV |
| YJV / YJLV 3х6,0+1х2,5 – 1kV | YJV / YJLV 3х6,0+1х4,0 – 1kV | YJV / YJLV 3х10 – 1kV | YJV / YJLV 3х10+1х4,0 – 1kV | YJV / YJLV 3х10+1х6,0 – 1kV |
| YJV / YJLV 3х16 – 1kV | YJV / YJLV 3х16+1х6,0 – 1kV | YJV / YJLV 3х16+1х10 – 1kV | YJV / YJLV 3х25 – 1kV | YJV / YJLV 3х25+1х10 – 1kV |
| YJV / YJLV 3х25+1х16 – 1kV | YJV / YJLV 3х35 – 1kV | YJV / YJLV 3х35+1х16 – 1kV | YJV / YJLV 3х50 – 1kV | YJV / YJLV 3х50+1х16 – 1kV |
| YJV / YJLV 3х50+1х25 – 1kV | YJV / YJLV 3х70 – 1kV | YJV / YJLV 3х70+1х25 – 1kV | YJV / YJLV 3х70+1х35 – 1kV | YJV / YJLV 3х95 – 1kV |
| YJV / YJLV 3х95+1х35 – 1kV | YJV / YJLV 3х95+1х50 – 1kV | YJV / YJLV 3х120 – 1kV | YJV / YJLV 3х120+1х35 – 1kV | YJV / YJLV 3х120+1х70 – 1kV |
| YJV / YJLV 3х150 – 1kV | YJV / YJLV 3х150+1х50 – 1kV | YJV / YJLV 3х150+1х70 – 1kV | YJV / YJLV 3х185 – 1kV | YJV / YJLV 3х185+1х50 – 1kV |
| YJV / YJLV 3х185+1х95 – 1kV | YJV / YJLV 3х240 – 1kV | YJV / YJLV 3х240+1х70 – 1kV | YJV / YJLV 3х240+1х120 – 1kV | YJV / YJLV 4х1,5 – 1kV |
| YJV / YJLV 4х1,5+1х1,0 – 1kV | YJV / YJLV 4х1,5+1х1,5 – 1kV | YJV / YJLV 4х2,5 – 1kV | YJV / YJLV 4х2,5+1х1,5 – 1kV | YJV / YJLV 4х4,0 – 1kV |
| YJV / YJLV 4х4,0+1х2,5 – 1kV | YJV / YJLV 4х6,0 – 1kV | YJV / YJLV 4х6,0+1х2,5 – 1kV | YJV / YJLV 4х6,0+1х4,0 – 1kV | YJV / YJLV 4х10 – 1kV |
| YJV / YJLV 4х10+1х4,0 – 1kV | YJV / YJLV 4х10+1х6,0 – 1kV | YJV / YJLV 4х16 – 1kV | YJV / YJLV 4х16+1х6,0 – 1kV | YJV / YJLV 4х16+1х10 – 1kV |
| YJV / YJLV 4х25 – 1kV | YJV / YJLV 4х25+1х10 – 1kV | YJV / YJLV 4х25+1х16 – 1kV | YJV / YJLV 4х35 – 1kV | YJV / YJLV 4х50 – 1kV |
| YJV / YJLV 4х70 – 1kV | YJV / YJLV 4х95 – 1kV | YJV / YJLV 4х120 – 1kV | YJV / YJLV 4х150 – 1kV | YJV / YJLV 4х185 – 1kV |
| YJV / YJLV 4х240 – 1kV | YJV / YJLV 5х1,5 – 1kV | YJV / YJLV 5х2,5 – 1kV | YJV / YJLV 5х4,0 – 1kV | YJV / YJLV 5х6,0 – 1kV |
| YJV / YJLV 5х10 – 1kV | YJV / YJLV 5х16 – 1kV | YJV / YJLV 5х25 – 1kV | YJV / YJLV 5х35 – 1kV | YJV / YJLV 5х50 – 1kV |
| YJV / YJLV 5х70 – 1kV | YJV / YJLV 5х95 – 1kV | YJV / YJLV 5х120 – 1kV | YJV / YJLV 5х150 – 1kV | YJV / YJLV 5х185 – 1kV |
| YJV / YJLV 5х240 – 1kV |
*Further information about rating factor for certain cable arrangement can be found on supplementary technical information.
Electrical Data
| Conductor | Inductance | Current – Carrying Capacity at 30° C * | Short circuit current at 1 sec | |||
| Nom. Cross Section Area | DC Resistance at 20°C | AC Resistance at 90°C | ||||
| in air | in ground | |||||
| (mm²) | Max. (Ω/km) | Max. (Ω/km) | (mH/km) | Max. (A) | Max. (A) | Max. (kA) |
| 1.5 | 12.1 | 15.429 | 0.315 | 27 | 32 | 0.21 |
| 2.5 | 7.41 | 9.449 | 0.293 | 36 | 42 | 0.36 |
| 4 | 4.61 | 5.878 | 0.275 | 48 | 55 | 0.57 |
| 6 | 3.08 | 3.927 | 0.263 | 60 | 68 | 0.86 |
| 10 | 1.83 | 2.334 | 0.248 | 83 | 91 | 1.43 |
| 16 | 1.15 | 1.467 | 0.238 | 110 | 118 | 2.29 |
| 25 | 0.727 | 0.927 | 0.240 | 148 | 152 | 3.58 |
| 35 | 0.524 | 0.669 | 0.233 | 183 | 183 | 5.01 |
| 50 | 0.387 | 0.494 | 0.232 | 214 | 210 | 7.15 |
| 70 | 0.268 | 0.343 | 0.229 | 269 | 256 | 10.01 |
| 95 | 0.193 | 0.247 | 0.224 | 334 | 309 | 13.59 |
| 120 | 0.153 | 0.197 | 0.223 | 386 | 350 | 17.16 |
| 150 | 0.124 | 0.160 | 0.224 | 449 | 395 | 21.45 |
| 185 | 0.0991 | 0.129 | 0.225 | 512 | 444 | 26.46 |
| 240 | 0.0754 | 0.099 | 0.223 | 604 | 513 | 34.32 |
| 300 | 0.0601 | 0.081 | 0.221 | 692 | 577 | 42.90 |
