XLPE Flexible Copper Cable Superflex 500mcm 350mcm 300mcm 250mcm 4/0AWG

XLPE Flexible Copper Cable Superflex 500mcm 350mcm 300mcm 250mcm 4/0AWG image

Get Latest Price Request a quote

Product Details

Model NO.

cable superflex

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Red Copper Wire

Certification

ISO, CCC, SGS

Model

Cu/XLPE/PVC

Brand

Hongda Cable

Rated Voltage

600 V

Transport Package

500m Per Drum, 1000m Per Drum

Specification

12AWG to 2000MCM

Trademark

Hongda

Origin

China

HS Code

8544492100

Production Capacity

1200km/Month

Product Description

xlpe flexible copper cable superflex 500mcm 350mcm 300mcm 250mcm 4/0awg

powerflex RV-K cable Application:

Flexible cable for fixed installation intended for the transport of energy and industrial indoor and outdoor connections in low voltage installations.
Its flexibility makes it a special cable for installations
with complex paths

STANDARD
UNE 21123-2.
UNE-EN 60332-1-2: Flame propagation. IEC 60332.

VOLTAGE
0.6/1 kV

powerflex RV-K cable Conductors:
Flexible copper class 5.

powerflex RV-K cable INSULATION:
Cross-linked polyethylene XLPE

powerflex RV-K cable Insulation Jacket:
Polyvinyl Chloride (PVC)

Assembly:
Single conductor of stranded or solid annealed copper, XLPE Insulation and PVC Jacket type RV-K, several colors are available, surface printed.

powerflex RV-K cable Specification:

SIZE AWG / MCM	INSULATION THICKNESS mm.	JACKET THICKNESS mm.	EXTERNAL DIAMETER mm.	TOTAL WEIGHT Kg/Km	AMPACITY Amp.	PACKAGING
14	0.81	0.38	4.14	31.3	20	B,E,Z
12	0.81	0.38	4.54	44.7	25	B,E,Z
10	0.81	0.38	5.10	62.6	35	B,E,Z
8	1,14	0,38	6,73	109,0	50	B,E,Z
6	1,14	0,76	8,45	170,0	65	E,Z
4	1,14	0,76	9,68	301,0	85	E,Z
2	1,14	0,76	11,21	376,0	115	E,Z
1	1,40	1,14	13,42	461,5	130	E,Z
1/0	1,40	1,14	14,53	609,0	150	D,E,Z
2/0	1,40	1,14	15,68	747,0	175	D,E,Z
3/0	1,40	1,14	17,03	915,0	200	D,E,Z
4/0	1,40	1,14	18,48	1132,0	230	D,E,Z
250	1,65	1,65	21,23	1390,0	255	Z
300	1,65	1,65	22,63	1641,0	285	Z
350	1,65	1,65	23,89	1889,0	310	Z
400	1,65	1,65	25,08	2137,0	335	Z
500	1,65	1,65	27,25	2627,0	380	Z
600	2,03	1,65	29,97	3144,0	420	Z
650	2,03	1,65	30,95	3409,0	440	Z
700	2,03	1,65	31,79	3593,0	460	Z
750	2.03	1.65	32.18	3854.0	475	Z
1000	2.03	1.65	35.94	5045.2	545	Z

Powerflex RV-K cable PACKAGE:

A: Roll of 100 m.
B: Reel of 1500 m.
C: Reel of 1000 m.
D: Reel of 500 m.
E: Multiple Reels of 1000 m.
Z – Length to the client’s requirement.

Why Choose Us ?
1. We have a large production base, and advanced production equipment
2. Have an competitive price and high quality
3. Excellent after-sale service
4. Free issue:packaging list,invoice
5. Powerful technology team
6. Strict quality assurance system and perfect testing means
7. Advanced process equipment
8. Delivery on time
9. Our cable sales to Middle East,Africa,Russia,Southeast Asia, etc.
10. We have a good reputation in the overseas

We are China XLPE Flexible Copper Cable Superflex 500mcm 350mcm 300mcm 250mcm 4/0AWG manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
