Aluminium overhead insulated cable(low voltage) is the cable that be set at a certain height from the tower for transmitting electric energy. It is used primarily for overhead and distribution lines. There are two main types of it: all aluminum and steel core. The steel core increases breaking force.
ACSR-AWOC cable has been using in Rakhine, Chin, Sagaing, Magway.
ACSR-AWOC strong as steel wires inner core will keep cable long time using and reduce sag level.
ACSR-AWOC applying for high-wind area and complex distances.=
ACSR/AW-OC Structure
– Seal wire : Aluminum-sheathed stranded wire (AW)
– Conductor : Standard aluminum cable
– Interior semi-conductor layer : Black semi-conductor thermosetting compound
– Insulator : weather resistant cross-linked polyethylene (black)
Standard
ES 6145-0021
| minal Sectional Area |
Conductor | Insulation Thickness |
Overall Diameter |
Max. Conductor Resistance at 20ºC |
Min. Insulation Resistance at 20ºC |
Test Voltage |
Min. Tensile Load |
Approx. Weight |
Standard Length |
||
| Number & Diameter of Wire |
Number & Diameter of Wire |
Outer Diameter |
|||||||||
| mm2 | mm | mm | mm | mm | mm | Ω/km | Ω/km | kV | kN(kgf) | kg/km | m |
| 58 | 6/SB | 1/3.5 | 9.7 | 3.0 | 15.7 | 0.484 | 1,500 | 25 | 1,900 | 360 | 600 |
| 95 | 6/SB | 1/3.5 | 12.0 | 3.5 | 19.0 | 0.302 | 1,500 | 25 | 2,360 | 520 | 600 |
| 160 | 18/SB | 1/3.2 | 15.4 | 4.0 | 23.4 | 0.183 | 1,500 | 25 | 3,080 | 750 | 600 |
| 240 | 18/SB | 1/4.0 | 18.9 | 4.0 | 27.0 | 0.123 | 1,000 | 25 | 4,500 | 1,040 | 600 |
