URD Single Core Copper XLPE 133% 15kv Underground Power Cable 150mm2 95mm
Cable Structure:
Conductor: Class 2 stranded plain copper conductor to BS EN 60228:2005 (previously BS6360)
Conductor screen: Semi-conducting material
Insulation: XLPE (Cross-Linked Polyethylene) Type GP8 to BS7655
Insulation Screen: Semi-conducting material
Metallic Screen: Individual and overall copper tape screen to BS6622
Filler: PETP (Polyethylene Terephthalate) fibres
Separator: Binding tape
Bedding: PVC (Polyvinyl Chloride) Type TM1 to BS7655
Armouring: Single Core: Aluminium Wire Armoured (AWA)
Multi-core: Steel Wire Armoured (SWA)
Sheath: PVC (Polyvinyl Chloride) Type TM1 to BS7655
Colour: Red or Black
Voltage Rating: 19000/33000V
Temperature Rating: 0°C to +90°C
Minimum Bending Radius: Single Core: 15 x overall diameter
Three Core: 12 x overall diameter
(Single Core 12 x overall diameter and 3 core 10 x overall diameter where bands are positioned adjacent to joint or terminations provided that the bending is carefully controlled by the use of a former)
12kv 15kv 33kV XLPE Cable
| Nominal Cross Sectional Areamm² | Nominal Overall Diametermm |
|---|---|
| 1 x 70 | 41.0 |
| 1 x 95 | 42.9 |
| 1 x 120 | 44.5 |
| 1 x 150 | 47.3 |
| 1 x 185 | 49.3 |
| 1 x 240 | 51.7 |
| 1 x 300 | 54.4 |
| 1 x 400 | 57.7 |
| 1 x 500 | 61.1 |
| 1 x 630 | 65.0 |
| 1 x 800 | 71.6 |
| 1 x 1000 | 76.5 |
| 3 x 50 | 78.2 |
| 3 x 70 | 82.1 |
| 3 x 95 | 86.1 |
| 3 x 120 | 90.0 |
| 3 x 150 | 93.2 |
| 3 x 185 | 97.5 |
| 3 x 240 | 103.3 |
| 3 x 300 | 108.8 |
| 3 x 400 |
116.1 |
company information:
Hongda cable Co., Ltd. is one of the most professional cable & wire producer, which was founded in 1988, have exported for 9 years, integrating scientific research, development, production and sales. Henan Hongda Cable Co., is the original Zhengzhou Hongda Cable Co., The company mainly produces 1-35 kV power cable, TW, THW, THHW, THHN electrical wire, ABC cable, Overhead Cable, AAC, AAAC, ACSR, ACAR bare conductor, Concentric Cable, etc
Our advantages
1. With more than 17 years manufacturing experience, our products are strictly in accordance with ISO, SGS, CCC ;
2. Good cost-control system, with highly-competitive prices;
3. Strong and Professional R&D team to meet your specific needs;
4. Fast delivery&reliable products are always the reason why you choose us.
Custom Merchandise: we can make cable as your need include the color ,size and so on.we also offer OEM
Packing
Steel wooden drum (fumigation)
Cable length in each drum: 1000m/2000m or as per actual cable length requirements.
Drum size:
As per cable length and container size
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!
