Product Details

Model NO.
U1000 R2V Cable
Current
AC Cable
Insulation Material
XLPE
Sheath Material
PVC
Material Shape
Round Wire
Wire Core Material
Aluminum
Certification
ISO, CCC
Model
Na2xy
Brand
OEM
Transport Package
Wooden Drum
Specification
3g1.5 3g2.5 3g4
Trademark
OEM
Origin
China(Mainland)
HS Code
8544492100
Production Capacity
500 Kilometer/Month

Product Description

Cable U-1000 RO2V  Application

Low voltage power cable for fixed application, Copper conductor, XLPE insulation, and PVC outer sheath. U-1000 AR2V aluminum cables can be used in all low-voltage power installations.can be fixed on cable trays, within conduits or fixed to walls. They also can be buried directly with extra mechanical protection

Cable U-1000 RO2V Standards:

XP C 32-321( formerly NF C 32-321) , EN 60332-1/NF C 32-070


Cable U-1000 RO2V Construction

Conductors: Cu, class 2 according to EN 60228

Insulation: : XLPE compound

Bedding: Extruded elastomere or plastomere compound

Sheath: PVC compound

Identification of cores HD 308 S2:
2x – brown and blue
3x – brown, black and blue (S=1,5/2,5 mm2)
3x – brown, black and gray (S≥4 mm2)
3G – brown, blue and yellow / green
4x – brown, black, gray, blue
4G – brown, black, gray, yellow / green

5G – brown, black, gray, blue, yellow / green


U-1000 R2V RO2V- Technical data and tests
Standards : NF C 32-321 C32-321/A1; IEC 60502-1 NF EN 60332-1-2; NF C 15-100
Nominal voltage U0/U : 0,6/1 kV
Test voltage (50 Hz) : 4 kV
Maximun voltage Um : 1,2 kV
Maximun operating temperature : +90° C
Maximun short circuit temperature : +250° C
Min. operating temperature
(without mechanical shocks)
: -25° C
Minimum installation and use temp. : -10° C
Minimum bending radius per
D cable diameter (in mm)
: 6 x D
Maximum pulling stress : 5 kg/mm² (of copper cross section)
Sheath colour : black

U-1000 RO2V Cable Parameter

Cross Section

Insulation thickness

Minimum Sheath thickness

Maximum Overall diameter

Approx Cable weight

mm2

mm

mm

mm

kg/km

1×1.5

0.7

1.09

6.6

45

1×2.5

0.7

1.09

7

55

1×4

0.7

1.09

7.6

75

1×6

0.7

1.09

8.2

100

1×10

0.7

1.09

9.2

140

1×16

0.7

1.09

10.5

205

1×25

0.9

1.09

12.5

315

1×35

0.9

1.09

13.5

400

1×50

1

1.09

15

530

1×70

1.1

1.09

17

725

1×95

1.1

1.18

19

985

1×120

1.2

1.18

21

1260

1×150

1.4

1.26

23

1520

1×185

1.6

1.26

25.5

1940

1×240

1.7

1.35

28.5

2310

2×1.5

0.7

1.43

10.5

115

2×2.5

0.7

1.43

11.5

145

2×4

0.7

1.43

13

195

2×6

0.7

1.43

14

265

2×10

0.7

1.43

16

390

2×16

0.7

1.43

18.5

560

2×25

0.9

1.43

22

850

2×35

0.9

1.43

24.5

1080

3×1.5

0.7

1.43

11

130

3×2.5

0.7

1.43

12.5

170

3×4

0.7

1.43

13.5

230

3×6

0.7

1.43

15

325

3×10

0.7

1.43

17

485

3×16

0.7

1.43

19.5

705

3×25

0.9

1.43

23.5

1080

3×35

0.9

1.43

26

1390

3×50

1

1.43

29

1840

3×70

1.1

1.52

34

2540

3×95

1.1

1.6

38.5

3430

3×120

1.2

1.69

42.5

4440

3×150

1.4

1.86

47.5

5380

3×185

1.6

1.94

53

6920

3×240

1.7

2.11

59.5

8420

3×300

1.8

2.28

66

11300

4×1.5

0.7

1.8

11.3

180

4×2.5

0.7

1.8

12.2

220

4×4

0.7

1.8

13.3

300

4×6

0.7

1.8

15

420

4×10

0.7

1.8

17.25

630

4×16

0.7

1.8

18.8

900

4×25

0.9

1.8

23

1350

4×35

0.9

1.8

25.1

1750

4×50

1

1.9

29.1

2350

4×70

1.1

2

33.9

3400

4×95

1.1

2.1

38.4

4500

4×120

1.2

2.3

42.4

5700

4×150

1.4

2.4

47.2

7050

4×185

1.6

2.6

52.65

8700

4×240

1.7

2.8

59

11400

4×300

1.8

3

64.8

14200





Packaging & Shipping

Company Profile

Henan Hongda Cable Co., Ltd. located in No. 3, Changping Road, ZhanDian District, Jiaozuo, Wuzhi. Our factroy established in March of 2004. Our owns registered capital of RMB Fifty-one million six hundred and eighty thousand. Hongda Cable covers an area of 100,000 square meters, including 50,000 square meters of building area. We have more than 120 staff members and professional workers. our fixed assets of 90,000,000. We can provide more than 100 varieties, tens of thousands of specifications of wire and cable, with 10000 km annual production capacity

Henan Hongda Cable Co. Ltd. is the original Zhengzhou Hongda Cable Co. Ltd. established enterprise expansion. The company is committed to system R&D, design, manufacturing, marketing and service of cable products,We mainly aim at managing cross-linking XLPE insulated power cables, PVC insulated power cables, plastic insulated control cables, insulated overhead cables, and stranded aluminum and ACSR. At present, the cables’ biggest cross area is 800 square meters with a maximum electric power of 35KV. The company has more than 300 (sets) domestic and oversea-leading production and testing equipment

 Our factory has advanced equipment of 20 sets production lines and 25 sets testing machinas, The production capacity is more than 12 million kilometers. We have skillful staff over 20-year experience,before starting working, every worker need to be trained professionally. Therefore, we can promise the product will be 100% quantified.



In our factory, every roll wire need to be test strictly, We wil test resistance, insulation thickness, the tension, stretch and so on. Before packing, every cable need to be test quantified, and we can make promise the 100% quantified.
