Txxp 1kv 400 630 Electrical Energy Al Conductors XLPE Cable

Txxp 1kv 400 630 Electrical Energy Al Conductors XLPE Cable image

Get Latest Price Request a quote

Product Details

Model NO.

TXXP 1KV

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Al Conductor

Certification

ISO, CCC

Model

Txxp

Brand

Hongda

Conductors

Aluminum Conductor, Round Stranded (RM)

Transport Package

500m/Drum, 1000m/Drum

Specification

16mm2 to 400mm2

Trademark

Hongda

Origin

Henan, China

HS Code

8544492100

Production Capacity

1000km/Month

Product Description

TXXP 1KV 400 630 Electrical Energy Al conductors XLPE Cable

TXXP 1KV

Power cables 0,6/1 kV for the supply of electrical energy XLPE Insulated and PVC Sheathed, With Aluminium conductors

APPLICATION
Interconnection cable for transmitting large amount of energy.

CONSTRUCTION
— Aluminum conductor, round stranded (RM)
— Core insulation (XLPE)
— Sheath (PVC black, UV resistant)

TECHNICAL DATA
Standard: IEC 60502-1
Rated voltage: 0.6/1 kV
Test voltage: 3.5 kV/50 Hz
Temperature range:
laying temperature: min. -5 °C
operating temperature: max. +70 °C
short-circuit temperature: max. +250 °C/5 s
Bending radius (min.): 15 x Φ of cable (single core)
Core identification: HD 308 S2
Fire properties: flame retardant: EN 60332-1-2

CONSTRUCTION DATA OF POWER CABLES / TXXP 1 KV

Number of cores and nominal cross section mm2	Aluminium figure kg/km	Overall diameter appr. mm	Weight appr. kg/km	Current carrying capacity ground A	Current carrying capacity air A
1 x 25 RM	74,0	11	174,0	106	87
1 x 35 RM	103,0	12	209,0	127	107
1 x 50 RM	147,0	14	282,0	151	131
1 x 70 RM	206,0	16	363,0	185	166
1 x 95 RM	279,0	18	520,0	222	205
1 x 120 RM	353,0	19	557,0	253	239
1 x 150 RM	441,0	21	674,0	284	273
1 x 185 RM	544,0	24	826,0	322	314
1 x 240 RM	706,0	26	1052,0	375	378
1 x 300 RM	882,0	29	1282,0	425	437
1 x 400 RM	1.200,0	32	1598,0	487	513
1 x 500 RM	1.510,0	36	2022,0	558	600
1 x 630 RM	1.900,0	40	2200,0	635	701
