Twisted Duplex 2X6AWG Multicore Overhead Line ABC Cable

Twisted Duplex 2X6AWG Multicore Overhead Line ABC Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Duplex cable 2x6awg

Application

Overhead

Conductor Material

Aluminum

Sheath Material

PVC

Insulation Material

PVC/PE/XLPE

Material Shape

Round Wire

Range of Application

Overhead

Certification

ISO9001, CE, CCC, RoHS

Brand

Hongda

Voltage

0.6/1kv

Size

Duplex Cable 2X6AWG

Insulation

XLPE

Packing

Wooden Drum

Transport Package

Wooden Drum/ Wooden Palate

Specification

ABC cable

Trademark

HONGDA CABLE

Origin

Henan China

HS Code

8544492100

Production Capacity

1000km Per Month

Product Description

Twisted Duplex 2x6awg Multicore Overhead line ABC Cable

1.Applications
            Aerial Bundle Cable (ABC cable) is a very innovative concept for overhead power distribution as compared to the conventional bare conductor overhead distribution system. It provides higher level of safety and reliability, lower power losses and ultimate system economy by reducing installation,maintenance and operative cost. The cables are designed for aerial power lines and room-entrance wires with AC rated voltage 1kV and below.
2.Standards
         GB/T12527,1179 ,IEC60502 ,NFC 33-209 ,BS 7870 ,ANSI/ICEA S-76-474  AS/NZS 3560.1 etc.
*HONGDA can also design and produce for special application requirement.
3.Production Range
          Rated Voltage U0/U(Um) (kV) : 0.6/1(1.2) No. of cores : 1 , 2 , 3, 4 , 5, 3+1 , 4+1 ,3+2
Nominal cross-section(mm2): 10~240
4.Construction
           Phase conductors :Round standed or compacted 1350-H19 aluminium or Copper conductor ,AAAC,ACSR
Neutral or messenger conductor :Round standed or compacted 6201 aluminium alloy or AAC ,,ACSR
Street lighting conductor: Round standed or compacted Aluminium conductor
Insulation : LDPE ,HDPE,XLPE ,PVC ( UV-resistant)
Note: The above provisions can be changed as order.

Standard
NFC 33-209: Aerial Bundled Cables
ICEA S-76-474: Standard for Neutral-supported Power Cable Assemblies with Weather-resistant Extruded Insulation Rated 600 Volts

Application
This 16mm aluminium xlpe cable (usually twisted by 2~4 cores) is used in overhead power distribution lines of rated voltage 600/1000V and below. With the XLPE insulation, it can be installed near the buildings, trees in downtown areas.
Product Details
1) Phase conductor: stranded 1350 aluminum, 7/1.70 mm
2) Insulation: XLPE, 1.2 mm
3) Overall diameter: 7.2 mm
4) Approx. weight: 66 kg/km
5) Max. DC resistance at 20 degrees: 1.91 ohm/km
6) Max. working temperature: 90 degrees

Number of Cores x Nominal Cross Section	Overal Diameter	Weight	Maximum Conductor Resistance	Minimum Breaking Load	Current Rating
No.×mm^2	mm	Kg/Km	Ω/Km	KN	A
2×10 RM	12.8	93	3.080	1.5	38
4×10 RM	15.4	183	3.080	1.5	38
2×16 RM	14.8	129	1.910	2.3	72
2×16 RN + 2×1.5 RE	14.8	176	1.910/12.100	2.3	72
4×16 RM	17.8	257	1.910	2.3	72
4×16 RN + 2×1.5 RE	17.8	304	1.910/12.100	2.3	72
2×25 RM	18.0	202	1.200	3.8	107
2×25 RM + 2×1.5 RE	18.0	249	1.200/12.100	3.8	107
4×25 RM	21.7	404	1.200	3.8	107
4×25 RM + 2×1.5 RE	21.7	451	1.200/12.100	3.8	107
2×35 RM	20.8	269	0.868	5.2	132
2×35 RM + 2×1.5 RE	20.8	316	0.868/12.100	5.2	132
4×35 RM	25.1	539	0.868	5.2	132
4×35 RM + 2×1.5 RE	25.1	586	0.868/12.100	5.2	132
2×50 RM	23.4	352	0.641	7.6	165
2×50 RM + 2×1.5 RE	23.4	399	0.641/12.100	7.6	165
1×54.6 RM + 3×25 RM	21.7	507	0.630/1.200	3.8	107
1×54.6 RM + 3×25 RM + 1×16 RM	24.3	573	0.630/1.200/1.910	3.8/2.3	107/72
1×54.6 RM + 3×25 RM + 2×16 RM	29.7	639	0.630/1.200/1.910	3.8/2.3	107/72
1×54.6 RM + 3×25 RM + 3×16 RM	31.1	705	0.630/1.200/1.910	3.8/2.3	107/72
1×54.6 RM + 3×35 RM	25.1	615	0.630/0.868	5.2	132
1×54.6 RM + 3×35 RM + 1×16 RM	28.1	680	0.630/0.868/1.910	5.2/2.3	132/72
1×54.6 RM + 3×35 RM + 2×16 RM	34.3	748	0.630/0.868/1.910	5.2/2.3	132/72
1×54.6 RM + 3×35 RM + 3×16 RM	35.9	814	0.630/0.868/1.910	5.2/2.3	132/72
1×54.6 RM + 3×35 RM + 1×25 RM	28.1	714	0.630/0.868/1.200	5.2/3.8	132/107
1×54.6 RM + 3×50 RM	28.2	741	0.630/0.641	7.6	165
1×54.6 RM + 3×50 RM + 1×16 RM	31.6	806	0.630/0.641/1.910	7.6/2.3	165/72
1×54.6 RM + 3×50 RM + 2×16 RM	38.6	875	0.630/0.641/1.910	7.6/2.3	165/72
1×54.6 RM + 3×50 RM + 3×16 RM	40.4	940	0.630/0.641/1.910	7.6/2.3	165/72
1×54.6 RM + 3×50 RM + 1×25 RM	31.6	841	0.630/0.641/1.200	7.6/3.8	165/107
1×54.6 RM + 3×70 RM	33.0	950	0.630/0.443	10.2	205
1×54.6 RM + 3×70 RM + 1×16 RM	37.0	1014	0.630/0.443/1.910	10.2/2.3	205/72
1×54.6 RM + 3×70 RM + 2×16 RM	45.2	1083	0.630/0.443/1.910	10.2/2.3	205/72
1×54.6 RM + 3×70 RM + 3×16 RM	47.3	1148	0.630/0.443/1.910	10.2/2.3	205/72
1×54.6 RM + 3×70 RM + 1×25 RM	37.0	1048	0.630/0.443/1.200	10.2/3.8	205/107
1×54.6 RM + 3×70 RM + 2×25 RM	45.2	1150	0.630/0.443/1.200	10.2/3.8	205/107
1×54.6 RM + 3×70 RM + 3×25 RM	47.3	1250	0.630/0.443/1.200	10.2/3.8	205/107
1×54.6 RM + 3×95 RM	37.4	1176	0.630/0.320	13.5	240
1×54.6 RM + 3×95 RM + 1×16 RM	41.9	1243	0.630/0.320/1.910	13.5/2.3	240/72

About us :
Hongda Cable, established in 2004, with two factories in Henan Province, China, is dedicated into manufacturing a wide range of electric wire and cable with rated voltage from 300 voltage to 36kv. The electric wire and cable are applied to industrial, commercial, and residential use. Including PVC insulated cable, XLPE insulated cable, Aerial Bundle Cable, Control Cable, Bare Overhead Conductor (AAC, AAAC, ACSR, ACAR), PVC or XLPE insulated with sheath or unsheathed electric wires, which are used for power generation, power transmission, power distribution, house wiring, electrical equipment, oil & Gas, marine & shipboard, telecommunication, control & instrumentation, and so on.

Hongda Cable is certificated by ISO 9001, CCC (China Compulsory Product Certification). With quality and service, Hongda Cable has been supplying cables for China Railway, nilitary Residence, Power Station and Substation, Petrochemical, Hospital, Water Suppliers, Real Estate, Shopping Mall,Smelting and mining industry; For overseas market, Hongda Cable have developed market in North America, Middle East, Asian, Africa, South America, Austria, etc.

With 13 years of development, based on our core values of efficiency, honesty, integrity, and respect for people and the environment, from the heaviest industries to the places closest to hands, Hongda Cable cares every detail and always be here for you.

We are China Twisted Duplex 2X6AWG Multicore Overhead Line ABC Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
