Product Details
Product Description
Copper conductor 450/750v THW 12 AWG cable wire electrical
Type THW is a single conductor ground wire suitable for non-grounded multiconductor cables. Compatible with twisted, heavy-duty,jacketed, or parallel cables. These wires are manufactured to UL standard Type THW. The solid bare copper conductor is insulated with a moisture-resistant, polyvinyl chloride (PVC) insulation .
1.For installation in conduits and other raceways
2.Oil and grease resistant insulation
3.Abrasion and crush resistant
4.THW insulation is flame retardant PVC and meets the UL VW-1 flame test
5.Maximum continuous conductor temperature: 75°C Dry, 75°C Wet
| WG or kcmil | Strand | Nominal Insulation Thichness Inch/mm |
Nominal Overall Diameter Inch/mm |
Cable Weight Lbs/kft kg/km |
|||
| 14 | 1 | 0.030 | 0.76 | 0.169 | 4.3 | 22 | 33 |
| 12 | 1 | 0.030 | 0.76 | 0.189 | 4.8 | 32 | 47 |
| 10 | 1 | 0.030 | 0.76 | 0.213 | 5.4 | 46 | 68 |
| 8 | 1 | 0.045 | 1.14 | 0.240 | 6.1 | 67 | 100 |
| 14 | 7 | 0.030 | 0.76 | 0.177 | 7 | 101 | 151 |
| 12 | 7 | 0.030 | 0.76 | 0.201 | 4.5 | 24 | 36 |
| 10 | 7 | 0.030 | 0.76 | 0.228 | 5.1 | 34 | 50 |
| 8 | 7 | 0.045 | 1.14 | 0.291 | 5.8 | 49 | 73 |
| 6 | 7 | 0.060 | 1.52 | 0.335 | 7.4 | 79 | 118 |
| 4 | 7 | 0.060 | 1.52 | 0.386 | 8.5 | 117 | 174 |
| 2 | 7 | 0.080 | 2.03 | 0.445 | 9.8 | 172 | 256 |
| 1 | 19 | 0.080 | 2.03 | 0.531 | 11.3 | 263 | 391 |
| 1/0 | 19 | 0.080 | 2.03 | 0.575 | 13.5 | 339 | 505 |
| 2/0 | 19 | 0.080 | 2.03 | 0.622 | 14.6 | 418 | 622 |
| 3/0 | 19 | 0.080 | 2.03 | 0.677 | 15.8 | 515 | 767 |
| 4/0 | 37 | 0.080 | 2.03 | 0.740 | 17.2 | 638 | 950 |
| 250 | 37 | 0.095 | 2.41 | 0.823 | 18.8 | 792 | 1179 |
| 300 | 37 | 0.095 | 2.41 | 0.882 | 20.9 | 943 | 1404 |
| 350 | 37 | 0.095 | 2.41 | 0.937 | 22.4 | 1118 | 1664 |
| 400 | 37 | 0.095 | 2.41 | 0.984 | 23.8 | 1292 | 1923 |
| 500 | 61 | 0.095 | 2.41 | 1.079 | 25 | 1465 | 2180 |
| 600 | 61 | 0.110 | 2.79 | 1.197 | 27.4 | 1810 | 2694 |
We are China Tw Thw Electrical Copper Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
