Tw/Thw 250mcm PVC Insualted Copper Cable
Tw/Thw 250mcm PVC Insualted Copper Cable image
Get Latest Price Request a quote
You May Like
Product Details
Model NO.
THW TW
Application
Housing and Building
Conductor Material
Copper
Sheath Material
No Jacket
Insulation Material
PVC
Material Shape
Round Wire
Range of Application
Housing and Building
Certification
ISO9001, CCC
Brand
Hongda
Color
Red Yellow Green Blue Black White
Transport Package
on The Drum or on The Pallent
Specification
14 12 10 8 6 4 2 1 1/0 2/0 4/0
Trademark
hongda
Origin
Henan
HS Code
8544492100
Production Capacity
10000m/Day
Product Description
TW – Indicates a single conductor having flame-retardant, moisture-resistant thermoplastic insulation. The wire is rated 60°C wet or dry.
THW – Indicates a single conductor having flame-retardant, moisture- and heat-resistant thermoplastic insulation. The wire is rated 75°C wet or dry.
Specific size
| Item Spec. | AWG SIZE | No./Diameter of conductor (mm) |
Insulation thickness (mm) |
Max.outer diameter (mm) | Ref .Weight(km/kg) |
| THW-16B | 16 | 7/0.49 | 0.76 | 2.8 | 19 |
| THW-14B | 14 | 7/0.62 | 0.76 | 3.4 | 29 |
| THW-12B | 12 | 7/0.78 | 0.76 | 3.9 | 42 |
| THW-10B | 10 | 7/0.98 | 0.76 | 4.5 | 62 |
| THW-8B | 8 | 7/1.23 | 1.14 | 6 | 103 |
| THW-6B | 6 | 7/1.56 | 1.52 | 7.8 | 169 |
| THW-4B | 4 | 7/1.96 | 1.52 | 9 | 249 |
| THW-3B | 3 | 7/2.20 | 1.52 | 9.7 | 306 |
| THW-2B | 2 | 7/2.47 | 1.52 | 10.5 | 376 |
| THW-1B | 1 | 19/1.68 | 2.03 | 12.5 | 487 |
| THW-1/0B | 1/0 | 19/1.89 | 2.03 | 13.6 | 600 |
| THW-2/0B | 2/0 | 19/2.12 | 2.03 | 14.7 | 739 |
| THW-3/0B | 3/0 | 19/2.38 | 2.03 | 16 | 912 |
| THW-4/0B | 4/0 | 19/2.67 | 2.03 | 17.5 | 1130 |
| THW-16A | 16 | 1/1.29 | 0.76 | 2.9 | 19 |
| THW-14A | 14 | 1/1.63 | 0.76 | 3.2 | 27 |
| THW-12A | 12 | 1/2.05 | 0.76 | 3.6 | 39 |
| THW-10A | 10 | 1/2.59 | 0.76 | 4.1 | 59 |
| THW-8A | 8 | 1/3.26 | 1.14 | 5.6 | 98 |
We are China Tw/Thw 250mcm PVC Insualted Copper Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
Get Latest Price Request a quote
Tags: 250mcm Copper Cable, 250mcm PVC Insualted Copper Cable, Henan Hongda Cable Co., Ltd.
