Thhn 3.5mm2 5.5mm2 Electrical Wire

Thhn 3.5mm2 5.5mm2 Electrical Wire image

Get Latest Price Request a quote

Product Details

Model NO.

THHN

Application

Housing

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Housing

Certification

ISO9001, CCC

Brand

Honda

Color

Red Blue Yellow Green White Black

Transport Package

in Roll or in Pallent

Specification

3.5

Trademark

Origin

Henan

HS Code

8544492100

Production Capacity

10000 M Per Day

Product Description

Application:
Type THHN building wire is intended for general purpose applications as defined by the National Electrical Code (NEC). It is appropriate for new construction or rewiring for 600-volt applications. When used as type THHN, the conductor is suitable for use in wet or dry locations at temperatures not to exceed 90°C or not to exceed 75°C in oil or coolants. When used as type MTW, the conductor is suitable for use in dry locations at 90°C, or not to exceed 60°C in wet locations or where exposed to oils or coolants. Type MTW conductors are primarily used in control cabinets, in machine tool applications and appliance wiring applications at temperatures -25°C to 90°C. They comply with the National Electrical Code (NEC) and NFPA Standard 79. Voltage rating for all applications is 600 volts.
Construction:
• Conductor: pure annealed copper wire ( Stranded Circular).
• Insulation: PVC
• Jacket: Nylon
• Color of Insulation: Black, White, Red, Green, Yellow, Blue, Green-Yellow

Cross Section mm²	Approximate Size AWG or MCM	Stranding Number of wire x diameter mm.	Insulation Thickness mm.	Nylon Jacket mm.	Approx. Outside Diameter mm.	Approx. Net Weight Kg/Km	Ampacity 75ºC
2.0mm2	14	7*0.6	0.4	0.1	2.8	23.57	20
3.5mm2	12	7*0.8	0.4	0.1	3.4	39.29	25
5.5mm2	10	7*1.0	0.5	0.1	4.2	60.93	35
8.0mm2	8	7*1.2	0.8	0.13	5.46	92.49	50
14mm2	6	7*1.6	0.8	0.13	6.66	155.06	65
22mm2	4	7*2.0	1.0	0.15	8.3	241.69	85

We are China Thhn 3.5mm2 5.5mm2 Electrical Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
