Stranded Copper Conductor H07V-R Cable 1X6mm2

Stranded Copper Conductor H07V-R Cable 1X6mm2 image

Get Latest Price Request a quote

Product Details

Model NO.

H07V-R 1x6mm2

Application

Construction

Conductor Material

Copper

Sheath Material

Without

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Flame Retardant

Certification

ISO9001, CE, CCC, RoHS

Brand

Hongda

Color

Black, White, Red, Blue, Yellow, Green, Yellow&Gre

Warranty

5 Year

Sample

Free

Lead Time

10000 Rolls Stock in Warehouse

Transport Package

Plastic Film & Wooden Pallet

Specification

0~630sqmm

Trademark

Hongda

Origin

China

HS Code

8544492100

Production Capacity

2000km/Month

Product Description

Stranded Copper Conductor H07V-R cable 1x6mm2

450 – 750 VOLTS – Copper Conductor PVC insulated SSA 1320, IEC 60227 & BS 6004

HO 7V – R With Stranded Conductor – TYPE 60227 IEC 01

Wires and wiring cables are used to supply power for lighting and electric appliances and equipment in residences, offices, and similar environments.

SPECIFICATIONS

For internal wiring of equipment rated voltage up to 1000 V AC and up to 750 V DC to earth

Nominal Cross Section	No. of Wires in Conductor	Diameter of Conductor	Insulation Thickness	Overall Diameter	Weight of Finished Cable	Maximum DC Resistance at 20 °C
mm²		mm	mm	mm	mm	Ohm/km
1×1.5	7	1.50	0.7	3.3	22	12.1
1×2.5	7	2.01	0.8	4.0	35	7.41
1×4	7	2.55	0.8	4.6	52	4.61
1×6	7	3.12	0.8	5.2	71	3.08
1×10	7	4.05	1.0	6.7	116	1.83
1×16	7	5.10	1.0	7.8	185	1.15
1×25	7	6.42	1.2	9.7	290	0.727
1×35	7	7.65	1.2	10.9	390	0.524
1×50	19	8.90	1.4	12.8	525	0.387
1×70	19	10.70	1.4	14.6	735	0.268
1×95	19	12.60	1.6	17.1	1010	0.193
1×120	37	14.21	1.6	18.8	1260	0.153
1×150	37	15.75	1.8	20.9	1540	0.124
1×185	37	17.64	2.0	23.3	1940	0.0991
1×240	61	20.25	2.2	26.6	2550	0.0754
1×300	61	22.68	2.4	29.6	3180	0.0601
1×400	61	25.65	2.6	33.2	4050	0.0470
1×500	61	28.8	2.8	37.0	5050	0.0366
1×630	127/91	32.76	2.8	41.0	6050	0.0283

We are China Stranded Copper Conductor H07V-R Cable 1X6mm2 manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
