Steel Wire Armoured Lh Cable 2-4 Core Blue Stripe Swa Cable

Steel Wire Armoured Lh Cable 2-4 Core Blue Stripe Swa Cable image

Get Latest Price Request a quote

Product Details

Model NO.

swa cable

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE

Model

Swa Cable

Brand

Hongda Cable

Armoured

Steel Wire

Voltage Rating

600V/1000V

N2xry

PVC Insulated and Sheathed Cable

N2xrh

Low Smoke Zero Halogen Cable

Transport Package

Steel & Wooden Drum

Specification

1.5mm2 to 400mm2

Trademark

Hongda Cable

Origin

China

HS Code

8544492100

Production Capacity

1000km/Month

Product Description

Steel Wire Armoured LH Cable 2-4 Core Blue Stripe SWA CABLE

1. APPLICATION

The SWA Low Halogen Cable is designed for fixed installations and can withstand heavy mechanical stress. It is highly resistant to weather, UV radiation, oil, and chemicals, ensuring durability and safety. This low halogen cable minimizes toxic smoke in case of fire, making it ideal for power distribution, industrial machinery, and outdoor installations in both dry and wet conditions.

2. PROPERTIES

NOMINAL VOLTAGE:	600/1000V
TEST VOLTAGE:	6000V
TEMPERATURE RANGE:	-10° to +80°C
MIN BENDING RADIUS:	15 x Cable Diameter
PROTECTION:	Steel Wire Armour
FLEXIBILITY CLASS:	2
CONDUCTOR TYPE:	High conductivity annealed copper
INSULATION MATERIAL:	PVC
SHEATH MATERIAL:	Flame Retardant PVC / Low Halogen
SHEATH COLOUR:	Black with Blue Stripe
CORE COLOURS:	Two Cores :Red and Black Three Cores :Red, Yellow and Blue Four Cores :4 core – Red, Yellow, Blue and Black

3. Construction Table

High conductivity bunched, stranded copper conductors, insulated and color-coded with XLPE. Insulated cores are twisted and filled with PVC bedding to give the cable a round finish. It is armored with galvanized steel wire. Final protection is tightly bonded with a Flame Retardant, Low Halogen PVC.

4. Dimensions

No Cores	Size mm²	mV Drop Amps / mtr	Nominal Amps	Nominal Dia	Mass kg/100m
2	1.5	14.4	18	12.5	30
2	2.5	8.6	25	13.3	35
2	4.0	5.4	33	14.3	40
2	6.0	3.6	42	15.4	48
2	10.0	2.1	58	17.1	61
2	16.0	1.5	91	19.3	79
2	25.0	0.93	132	21.7	133
2	35.0	0.67	158	23.3	150
2	50.0	0.49	186	24.9	180
2	70.0	0.34	229	27.0	225
No Cores	Size mm²	mV Drop Amps / mtr	Nominal Amps	Nominal Dia	Mass kg/100m
3	1.5	14.4	18	12.9	33
3	2.5	8.6	25	13.8	40
3	4.0	5.4	33	14.9	45
3	6.0	3.6	42	16.0	55
3	10.0	2.1	58	18.1	72
3	16.0	1.5	91	20.2	95
3	25.0	0.93	132	24.9	161
3	35.0	0.67	158	26.1	191
3	50.0	0.49	186	28.7	240
3	70.0	0.34	229	31.9	310
3	95.0	0.25	275	39.0	438
3	120.0	0.20	312	39.7	510
3	150.0	0.16	357	43.5	610
3	185.0	0.13	397	52.0	800
3	240.0	0.10	459	57.9	995
No Cores	Size mm²	mV Drop Amps / mtr	Nominal Amps	Nominal Dia	Mass kg/100m
4	1.5	14.4	18	13.7	40
4	2.5	8.6	25	14.7	44
4	4.0	5.4	33	15.9	54
4	6.0	3.6	42	17.1	65
4	10.0	2.1	58	19.4	85
4	16.0	1.5	91	22.8	120
4	25.0	0.93	132	27.5	200
4	35.0	0.67	158	30.1	250
4	50.0	0.49	186	33.0	300
4	70.0	0.34	229	38.8	430
4	95.0	0.25	275	44.8	560
4	120.0	0.20	312	49.9	720
4	150.0	0.16	357	56.0	870
4	185.0	0.13	397	60.6	1050
4	240.0	0.10	459	67.9	1250

1. Where a conductor operates at a temperature exceeding 70ºC it must be ascertained that the equipment connected to the conductor is suitable for the conductor operating temperature.

2. Where cables in this table are connected to equipment or accessories designed to operate at a temperature not exceeding 70ºC , the current ratings given in the equivalent table for 70ºC thermoplastic insulated cables must be used.

Sold in full drums (500m) or cut to specification.
