Single Core XLPE Insulated Copper Tape Screened 22kv Power Cable

Single Core XLPE Insulated Copper Tape Screened 22kv Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

22kV Cu(Al)/XLPE/CTS/PVC single core

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Copper/Aluminum

Certification

ISO, CCC

Model

22kv Cu(Al)/XLPE/Cts/PVC Single Core

Brand

Hongda

Standard

IEC 60502

Transport Package

Steel & Wooden Drum

Specification

25~630sqmm

Trademark

HONGDA

Origin

China

HS Code

8544492100

Production Capacity

500km/Month

Product Description

Single Core XLPE Insulated Copper Tape Screened 22kV power cable

Application

XLPE insulated 22kVpower cable functions well for electricity transmission and distribution lines for its excellent electrical and physical properties, including the advantage of simplicity in construction, lightness in weight; convenience in application besides its excellent electrical, thermal, mechanical and anti-chemical corrosion properties. Laying indoors, in tunnel, fixed on the bracket, pipe and buried in the soil, the cable cannot bear external mechanical forces.

Standard

IEC60502,IEC 60228,IEC60332, BS 5467, BS 6622, IS 1554, IS 7098 and ICEA S-66-524 etc.

Hongda Cable can also design and produce for special application requirement.

Product Range

Rated voltage: 6/10kV

No. of Cores: single core

The ambient temperature for installation: ≥0ºC

Max. conductor temperature in normal operation: 90ºC

Max. operating temperature of conductor when cable short-circuited (5s maximum duration): 250ºC

Construction

Conductor: Plain annealed stranded copper conductor (aluminum) to IEC60228 class 2

Conductor Screen: Extruded semi-conductive compound

Insulation: XLPE (cross-linked polyethylene)

Insulation Screen: Extruded semi-conductive compound

Metallic Screen: Copper tape

Outer Sheath: PVC (type ST2) to IEC 60502

Main Technical Parameters for single core 22kV power cable

Cross Section	Conductor Diameter	Conductor Screen	Insulaiton	Insulation Screen	Outher Sheath	Overall Diameter	Weight of Copper Cable	Weight or Alumimnum Cable
Mm2	mm	mm	mm	mm	mm	mm	kg/km	kg/km
25	6.0	0.8	5.5	0.8	1.7	24.4	786	634
35	7.0	0.8	5.5	0.8	1.8	25.5	912	700
50	8.4	0.8	5.5	0.8	1.8	27.0	1098	796
70	10.0	0.8	5.5	0.8	1.9	28.7	1336	913
95	11.5	0.8	5.5	0.8	1.9	30.3	1619	1042
120	13.0	0.8	5.5	0.8	2.0	31.9	1899	1170
150	14.5	0.8	5.5	0.8	2.0	33.5	2230	1315
185	16.2	0.8	5.5	0.8	2.1	35.3	2616	1483
240	18.4	0.8	5.5	0.8	2.2	37.7	3187	1722
300	20.5	0.8	5.5	0.8	2.2	39.9	3819	1979
400	23.5	0.8	5.5	0.8	2.3	43.1	4781	2365
500	26.5	0.8	5.5	0.8	2.4	46.3	5853	2787

We are China Single Core XLPE Insulated Copper Tape Screened 22kv Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
