Single and Three Phase Service Aluminum Cable 2X16mm2 4X25mm2 2 by 16mm2 4 by 25mm2 Low Voltage

China Single and Three Phase Service Aluminum Cable 2X16mm2 4X25mm2 2 by 16mm2 4 by 25mm2 Low Voltage  manufacture and supplier

Single and Three Phase Service Aluminum Cable 2X16mm2 4X25mm2 2 by 16mm2 4 by 25mm2 Low Voltage image

Get Latest Price Request a quote

You May Like

Product Details

Model NO.
Service Aluminum Cable
Application
Overhead
Conductor Material
Aluminum
Insulation Material
XLPE
Material Shape
Round Wire
Range of Application
Flame Retardant
Certification
ISO9001, CE, CCC
Transport Package
Wooden Drum
Specification
Service Aluminum Cable
Trademark
OEM
Origin
China(Mainland)
HS Code
8544492100
Production Capacity
500 Kilometer/Month

Product Description

Cable Application

Bundle conductor for overhead energy distribution network without and with public lighting. (between pole to pole).



 Cable Construction

Conductor

Phase : Stranded All Aluminium conductor (AAC)

Insulation: Extrude of XLPE

Cable Specification

SPLN 42-10 : 1993

Standard: DIN VDE 0276-626 NFC 33209 BS7870-5 IEC 60502-1

(Other specifications are available upon request)


Cable
Parameter

PHYSICAL PROPERTIES ELECTRICAL PROPERTIES
Cable
Size
Insulation
Thickness
Approx.
Twisted
Diameter
Approx.
Net.Weight
Max. Conductor
Resistance
at 20 ºC
Current Carrying
Capacity
at 35ºC
Calculated
Breaking
Force
mm2 mm mm Kg/km Ω/km A kg
2x10rm 1.2 14 94 3.08 54 322
2x16rm 1.2 16 138 1.91 72 515
4x10rm 1.2 17 187 3.08 54 644
4x16rm 1.2 19 272 1.91 72 1030
4x25rm 1.4 24 423 1.2 102 1610
4x35rm 1.6 27 564 0.868 125 2250



Packaging & Shipping

  Packing

Steel wooden drum (fumigation)
Cable length in each drum: 1000m/2000m or as per actual cable length requirements.

 Drum size:
As per cable length and container size
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!

Shipping Port:

Tianjin, Qingdao, or other ports as per your requireents.

Sea freight:
FOB/C&F/CIF quotation are all available.



*For some countries such as Africa countries, middle east countries, our sea freight quotation is much cheaper than clients get from local shipping agency.

Henan Hongda Cable Co., Ltd. located in No. 3, Changping Road, ZhanDian District, Jiaozuo, Wuzhi . our factory established in March of 2004. Our owns registered capital of RMB Fifty-one million six hundred and eighty thousand. Our company covers an area of 100,000 square meters, including 50,000 square meters of building area, and has more than 120 staff members and professional workers accounting for one third .our fixed assets of 90,000,000. We can provide more than 100 varieties, tens of thousands of specifications of wire and cable, with 10000 km annual production capacity

 Our factory has advanced equipment of 20 sets production lines and 25 sets testing machinas, The production capacity is more than 12 million kilometers. We have skillful staff over 20-year experience,before starting working, every worker need to be trained professionally. Therefore, we can promise the product will be 100% quantified.



In our factory, every roll wire need to be test strictly, We wil test resistance, insulation thickness, the tension, stretch and so on. Before packing, every cable need to be test quantified, and we can make promise the 100% quantified.



 Welcome your inquiry to Tina

We are China Single and Three Phase Service Aluminum Cable 2X16mm2 4X25mm2 2 by 16mm2 4 by 25mm2 Low Voltage manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
