Sah - Vo 0.6/1 Kv Fn Ki 02.003 Aluminium ABC Overhead Electrical Power Distribution Line

China Sah - Vo 0.6/1 Kv Fn Ki 02.003 Aluminium ABC Overhead Electrical Power Distribution Line  manufacture and supplier

Sah - Vo 0.6/1 Kv Fn Ki 02.003 Aluminium ABC Overhead Electrical Power Distribution Line image

Get Latest Price Request a quote

You May Like

Product Details

Model NO.
SAH - VO
Current
DC & AC
Insulation Material
XLPE
Sheath Material
XLPE
Material Shape
Round Wire
Wire Core Material
Aluminium Conductor
Certification
Fn
Model
ABC Overhead Insulated Cable
Brand
Huadong
Product Name
Aerial Bundled ABC Cable
Rated Voltage
0.6/1kv
Cores
1 2 4 Cores
MOQ
1000m
Transport Package
by Wooden Drum
Specification
by meters
Trademark
huadong
Origin
China
HS Code
8544492100
Production Capacity
15 Million Km

Product Description

Product Description

SAH – VO 0.6/1 kV FN KI  02.003 Aluminium ABC Overhead Electrical Power Distribution Line



APPLICATION

The power cables with XLPE insulation for overhead lines – self-supporting type are designed for transfer, distribution and supply with electrical power in networks low voltage Uo/U 0.6/1 kV.
In constructions for distribution networks these cable permit suspension on fasades and trees.
They allow crossing of forest areas without cutting and maintenance of openings in the wood.
The suspension and support of the whole bundle is carried out by a supporting insulated neutral wire of aluminium steel conductor
or of aluminium alloy

CONSTRUCTION

Phase conductor: Al stranded compacted or Non-compacted according to FN KI 02.003-96

Insulation:XLPE with min. 2% carbon blackcontent type TIX-2

ABC Cable Product Parameters:

Construction, number and cross section Diameter of bundle approx. Mass of Al cores approx. Cable weight approx. Allowed current in power supply networks Allowed current at short-circuit
N o x mm2 mm kg/km kg/km A kA
3x25rm+71,5ASVrm 27 499 675 107 1,0
3x25rm+71,5ASt+1x16rm 27 544 751 107 1,3
3x25rm+71,5ASt+2x16rm 27 589 827 107 1,3
3x35rm+71,5ASt 31 588 767 132 1,9
3x35rm+71,5ASt+1x16rm 31 633 843 132 1,9
3x35rm+71,5ASt+2x16rm 31 679 919 132 1,9
3x50rm+71,5ASt 34 712 925 162 2,7
3x50rm+71,5ASt+1x16rm 34 757 1000 162 2,7
3x50rm+71,5ASt+2x16rm 34 802 1076 162 2,7
3x70rm+71,5ASt 40 864 1099 205 3,8
3x70rm+71,5ASt+1x16rm 40 909 1175 205 3,8
3x70rm+71,5ASt+2x16rm 40 954 1250 205 3,8
