Rz1-K 0.6/1 Kv Flexible & UV Resistant XLPE LSZH Flexible Cable 1X240

RZ1-K 0.6-1 kV FLEXIBLE & UV RESISTANT XLPE LSZH Flexible Cable 1×240

RZ1-K 0.6/1kV is a halogen-free flexible power cable with low smoke emission and no fire propagation. Due to its flexibility, it is particularly suitable for use in complex industrial installations. They are also known as “halogen-free electrical hose”.

RZ1-K CABLE Technology

• 1. Conductor
  • Electrolytic annealed copper conductor, class 5 (flexible), according to

    EN 60228 and IEC 60228.
• 2. Insulation
  • Cross-linked polyethylene type XLPE according to IEC 60502-1 and type

    DIX-3 according to HD 603. The standard identification of insulated conductors according to HD 308 is the following:
  • 1 x Natural
  • 2 x Blue + Brown
  • 3 G Blue + Brown + Green/yellow
  • 3 x Brown + Black + Grey
  • 3 x + 1 x Brown + Black + Grey + Blue (reduced cross-section)
  • 4 G Brown + Black + Grey + Green/yellow
  • 4 x Brown + Black + Grey + Blue
  • 5 G Brown + Black + Grey + Blue + Green/yellow
  • 6 G or more Black numbered + Green/yellow.
• 3. Outer sheath
  • Low Smoke Halogen Free (LSHF) polyolefin outer sheath, type ST8 according to IEC 60502- 1 and type DMZ-E according to UNE 21123-4. Green color.

RZ1-K (AS) 0.6/1kV cable has excellent performance in the event of a fire: it does flame non-propagation, does fire non-propagation, is halogen-free, and has a low emission of smoke and corrosive gases. This is what is known as “halogen-free”, or LSHF (Low Smoke Halogen Free) cable, with B2ca and Cca classification according to the European CPR Standard. It is a cable that must be installed in public places such as shopping centres, airports, schools, etc.

RZ1-K 0.6/1kV cable is highly flexible and has good resistance to maximum and minimum temperatures, impact, chemical attack and ultraviolet rays. A flexible cable such as RZ1-K offers greater ease of handling and laying, as well as better adaptability to winding routes when laying. In addition, its easy-stripping jacket can save up to 30% in labour costs.

INSTALLATIONS WHERE THE USE OF RZ1-K CABLE IS RECOMMENDED

RZ1-K (AS) 0.6/1kV cable, is very versatile and is used in all types of installations:

• Underground power supply networks for outdoor lighting installations.
• Individual derivation.
• General power supply line.
• Indoor or receiving installations.
• Public premises.
• Underground networks for low voltage distribution.
• Electrical energy distribution networks and underground connections.
• Installations in premises with special characteristics.

It can be installed in the open air, in conduits and/or buried in indoor and outdoor installations, both in single and multi-conductor versions.

RZ1-K CABLE PARAMETER :

If you need to consult additional technical aspects of this cable, such as its maximum admissible current or voltage drop, please contact VIVIAN YUAN.
