Rwu90 1000V 3 Twisted Aluminum Conductors Cable AA-8000

Rwu90 1000V 3 Twisted Aluminum Conductors Cable AA-8000 image

Get Latest Price Request a quote

Product Details

Model NO.

rwu90 aluminum

Current

DC Cable

Insulation Material

XLPE

Sheath Material

Crosslinking

Material Shape

Round Wire

Wire Core Material

AA-8000 Aluminum Alloy

Certification

ISO, CCC, CE

Model

Rwu90 Aluminum

Brand

Hongda Cable

Insulation Level

100% Insulation Level

Insulation

Cross-Linked Polyethylene (XLPE)

Color

Black, Red and Blue or Black with Coloured Stripe

Cable Assembly

Twisted with or Without a Green Bonding Conductor

Transport Package

1000m Per Drum

Specification

14AWG to 1500MCM

Trademark

Hongda cable

Origin

China

HS Code

8544492100

Production Capacity

600km/Month

Product Description

RWU90 1000V 3 twisted Aluminum Conductors Cable AA-8000

RWU90 1000V – 3 Twisted Aluminum Conductors

APPLICATION:

For use in open wiring and raceways (with the exception of cable troughs and ventilated flexible cableways) in dry or wet locations.
Use in ventilated and non-ventilated cable trays in vaults and switch rooms.
For direct earth burial (with protection as required by inspection authority)
For open wiring exposed to the weather. Maximum conductor temperature 90°C.

VOLTAGE:

1000V

Optional: 600 / 2000V

PRODUCT CONSTRUCTION

Conductor: Stranded AA-8000 Series Aluminum Alloy
Insulation: XLPE – Cross-linked Polyethlene
Color: Black, Red and Blue or Black with Coloured Stripe

CERTIFICATIONS/COMPLIANCES

CSA C22.2 #38, Thermoset Insulated Wires & Cables (XLPE)
-40°C cold bend / impact rated
UV sunlight resistant SUN RES and Halogen-free

SPECIFICATIONS:

CONDUCTOR SIZE	CABLE O.D.	CABLE WEIGHT	MAX. PULLING TENSION	AMPACITY (A)
6 AWG	17.18 mm	230 kg/km	143 kg	55
4 AWG	20.27 mm	318 kg/km	227 kg	75
3 AWG	21.75 mm	377 kg/km	286 kg	85
2 AWG	23.37 mm	450 kg/km	361 kg	100
1 AWG	26.64 mm	588 kg/km	455 kg	115
1/0 AWG	28.97 mm	703 kg/km	575 kg	135
2/0 AWG	30.82 mm	839 kg/km	725 kg	150
3/0 AWG	32.07 mm	1000 kg/km	914 kg	175
4/0 AWG	36.91 mm	1241 kg/km	1106 kg	205
250 kcmil	41.04 mm	1529 kg/km	1361 kg	230
350 kcmil	46.26 mm	2037 kg/km	1905 kg	280
500 kcmil	52.24 mm	2779 kg/km	2722 kg	350
600 kcmil	58.50 mm	3368 kg/km	3629 kg	385
750 kcmil	64.23 mm	4105 kg/km	4083 kg	435

*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!

We are looking forward to your inquiry and nice cooperation.

We are China Rwu90 1000V 3 Twisted Aluminum Conductors Cable AA-8000 manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
