Runway Aircraft Powering Airport Cable H07RV-K for Airfield Lighting Equipment
Runway Aircraft Powering Airport Cable H07RV-K for Airfield Lighting Equipment image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
Runway Aircraft Powering Airport Cable
H07RV-K
Applications
H07RV-K cables are used for connection between transformers and Airfield Lighting Equipment.
Standards
NF C 32-123
HD 21-3
Construction
Conductor: Stranded bare copper.
Insulation: PVC.
Technical Data
| Rated Voltage Uo/U (Um) | 450/750V |
| Maximum Conductor Temperature | 85ºC |
| Short Circuit Temperature | 200ºC |
| Operating Temperatures | -20ºC~+85ºC |
| Minimum Bending Radius | static: 4×OD; dynamic: 8×OD |
| Impacted Resistant | Yes |
| Weather Resistant | Yes |
| Oil Resistant | Yes |
Dimensions and Weight
| Construction | Nominal Insulation Thickness | Overall Diameter | Nominal Weight |
|---|---|---|---|
| No. ×mm² | mm | mm | kg/km |
| 1×300 | 2.4 | 26 | 3000 |
PACKAGING:
A: Reel of 1500 m.
B: Reel of 1000 m.
C: Reel of 500 m.
D – Length to the client’s requirement.
Please contact us for technical support with the right cable selection for your power distribution projects and to discuss your maintenance or project specific requirements. We provide tailored solutions for this cable range which include storage, cutting to length, and 2 days collection as standard.
Any problem and inquiry pls contact with Vivian Yuan.
We are China Runway Aircraft Powering Airport Cable H07RV-K for Airfield Lighting Equipment manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
