Rated Voltage 1 Kv Kabel PVC Nyy 4X95mm2 Power Cable

Rated Voltage 1 Kv Kabel PVC Nyy 4X95mm2 Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

nyy 4x95mm2 power cable

Current

AC Cable

Insulation Material

PVC

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Red Copper Wire

Certification

CCC

Model

Nyy Cable

Brand

OEM

Product Name

35mm 50mm 95 Sq. mm. 120mm 4 Core PVC Power Cable

Packaging

Wooden Drum

Transport Package

Wooden Drum

Specification

35mm 50mm 95 Sq. mm. 120mm 4 Core

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

500 Kilometer/Month

Product Description

They are used as power and control cables in static installations, indoors, in the open air, underground and in water. Direct burial is permitted only under certain conditions.

CABLE MAKE-UP

• Conductors: Solid or stranded (IEC60502 Class 2) bare copper conductors (re=round solid conductor, rm=round stranded conductor, sm=sectorial stranded conductor).

• Insulation: PVC.

• Core Identification: Up to 5 cores color coded according to VDE 0293. 7 cores and above black with white numbering. (-O: a green-yellow earth conductor is not included, -J: a green-yellow earth conductor is included).

• Inner PVC sheath.

• Outer Sheath: PVC standard color black.

• Voltage Rating: 600/1000 V.

• Temperature Range: -20 o C to 70 o C.

• Bending Radius: 15 x cable diameter (solid conductors). 12.5 x cable diameter (stranded conductors).

Conductor Shape

1.5 – 10 sqmm supplied in solid (re) or non compacted circular stranded (rm) 16 sqmm supplied in non compacted circular stranded (rm) conductor shape 25 – 800 sqmm supplied in non compacted circular stranded (rm) or compacted circular stranded (cm)

Single Core
Nominal cross section	No. of wire and conductor shape		Nominal Thickness		Overall Diameter	Weight
mm2	pcs	–	Insulation	Outer sheath	mm	kg/km
1.5	1	re	0.8	1.4	6	34
1.5	7	rm	0.8	1.4	7	55
2.5	1	re	0.8	1.4	7	66
2.5	7	rm	0.8	1.4	7	70
4	1	re	1.0	1.4	8	91
4	7	rm	1.0	1.4	8	97
6	1	re	1.0	1.4	8	113
6	7	rm	1.0	1.4	9	121
10	1	re	1.0	1.4	9	157
10	7	rm	1.0	1.4	9	168
16	7	rm	1.0	1.4	11	234
25	7	rm	1.2	1.4	12	344
35	7	rm	1.2	1.4	13	445
50	19	rm	1.4	1.4	15	578
70	19	rm	1.4	1.4	17	793
95	19	rm	1.6	1.5	19	1079
120	37	rm	1.6	1.5	21	1319
150	37	rm	1.8	1.6	23	1622
185	37	rm	2.0	1.7	25	2009
240	61	rm	2.2	1.8	29	2612
300	61	rm	2.4	1.9	32	3236
400	61	rm	2.6	2.0	35	4077
500	61	rm	2.8	2.1	39	5139
Two Cores
1.5	1	re	0.8	1.8	12	205
1.5	7	rm	0.8	1.8	13	213
2.5	1	re	0.8	1.8	13	243
2.5	7	rm	0.8	1.8	14	259
4	1	re	1.0	1.8	15	326
4	7	rm	1.0	1.8	16	351
6	1	re	1.0	1.8	16	390
6	7	rm	1.0	1.8	17	422
10	1	re	1.0	1.8	18	514
10	7	rm	1.0	1.8	18	557
16	7	rm	1.0	1.8	21	744
25	7	rm	1.2	1.8	24	1066
35	7	rm	1.2	1.8	26	1342
50	19	rm	1.4	1.8	30	1735
70	19	rm	1.4	1.9	33	2331
95	19	rm	1.6	2.0	39	3159
120	37	rm	1.6	2.1	42	3829
150	37	rm	1.8	2.2	46	4667
185	37	rm	2.0	2.4	51	5805
240	61	rm	2.2	2.6	58	7482
300	61	rm	2.4	2.7	64	9253
Three Cores
1.5	1	re	0.8	1.8	13	229
1.5	7	rm	0.8	1.8	13	237
2.5	1	re	0.8	1.8	14	276
2.5	7	rm	0.8	1.8	14	295
4	1	re	1.0	1.8	16	377
4	7	rm	1.0	1.8	16	406
6	1	re	1.0	1.8	17	459
6	7	rm	1.0	1.8	17	495
10	1	re	1.0	1.8	28	620
10	7	rm	1.0	1.8	19	669
16	7	rm	1.0	1.8	22	912
25	7	rm	1.2	1.8	25	1325
35	7	rm	1.2	1.8	28	1688
35	19	sm	1.2	1.8	28	1411
50	19	rm	1.4	1.8	28	1829
70	19	rm	1.4	2.0	31	2527
95	19	rm	1.6	2.1	36	3404
120	37	rm	1.6	2.2	38	4155
150	37	rm	1.8	2.3	43	5119
185	37	rm	2.0	2.5	47	6324
240	61	rm	2.2	2.7	53	8224
300	61	rm	2.4	3.1	59	10304
Three Cores + Ground
3×25+16	7/7	rm/rm	1.2/1.0	1.8	27	1501
3×35+16	7/7	rm/rm	1.2/1.0	1.8	29	1846
3×35+16	19/7	sm/rm	1.2/1.0	1.8	28	1668
3×50+25	19/7	sm/rm	1.4/1.2	1.9	32	2224
3×70+35	19/7	sm/rm	1.4/1.2	2.0	36	3024
3×95+50	19/19	sm/rm	1.6/1.4	2.2	40	4051
3×120+70	37/19	sm/rm	1.6/1.4	2.3	44	5083
3×150+70	37/19	sm/rm	1.8/1.4	2.4	49	6052
3×185+95	37/19	sm/rm	2.0/1.6	2.6	53	7535
3×240+120	37/37	sm/rm	2.2/1.6	2.8	60	9725
3×300+150	37/37	sm/rm	2.4/1.8	2.9	65	11983
Four Cores
1.5	1	re	0.8	1.8	14	262
1.5	7	rm	0.8	1.8	14	272
2.5	1	re	0.8	1.8	15	320
2.5	7	rm	0.8	1.8	15	343
4	1	re	1.0	1.8	17	443
4	7	rm	1.0	1.8	18	477
6	1	re	1.0	1.8	18	546
6	7	rm	1.0	1.8	19	589
10	1	re	1.0	1.8	20	749
10	7	rm	1.0	1.8	21	807
16	7	rm	1.0	1.8	24	1113
25	7	rm	1.2	1.8	28	1630
35	7	rm	1.2	1.8	30	2092
35	19	sm	1.2	1.8	28	1869
50	19	rm	1.4	1.9	32	2491
70	19	rm	1.4	2.1	36	3381
95	19	rm	1.6	2.2	40	4534
120	37	rm	1.6	2.3	44	5596
150	37	rm	1.8	2.5	49	6877
185	37	rm	2.0	2.7	53	8462
240	61	rm	2.2	2.9	60	10999
300	61	rm	2.4	3.1	66	13616

Packing shipping

Any problem and inquiry pls contact with Tina
Phone number: +86-15737156317

We are China Rated Voltage 1 Kv Kabel PVC Nyy 4X95mm2 Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
