PVC Insulated Single Core Bulk Power Cord Wire Vsf, Hvsf Flexible Cable

PVC Insulated Single Core Bulk Power Cord Wire Vsf, Hvsf Flexible Cable image

Get Latest Price Request a quote

Product Details

Model NO.

VSF, HVSF

Application

Overhead, Underground

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

Bare

Material Shape

Round Wire

Range of Application

Electronic and Electrical Equipment

Certification

ISO9001, CE, CCC

Brand

Hongda

Standard

Japan PSE Standard

Transport Package

100m Per Roll, or as Customer Requirement

Specification

0.3 - 2 mm2

Trademark

Hongda, customer OEM

Origin

China

HS Code

8544492900

Production Capacity

100km/Day

Product Description

VSF,HVSF Flexible Cable PVC Insulated Single Core Wire

Standard Voltage: 300V
Standard:JIS C3306
Environmental Certifications:ISO 9001
Quality System:ISO9001:2008
Samples: Free with freight collect

Samples shipping date: 7 days
Color: Custom color,white and black are normal
Wire Outject Material: PVC
Conductor: Copper
Cable Specifications:Standard and custom made

VSF,HVSF Flexible Cable Japan PSE Standard PVC Insulated Single Core Bulk Power Cord Wire, Standard voltage 300 Votage, 60°C for Industrial ,Lighting , indoor cable extension and 2 cores flat Wire leads

Application:
For general purpose use apply on internal wiring of electronic and electrical equipment.

Product description:
Annealed stranded copper conductor 0.3-2.0mm2
Reference Standard:JIS C3306
Rated temperature:
Type VSF=60ºC, HVSF=75, 105ºC.
Rated voltage: 300 volt.

Construction Data:

Normal area	Conductor Construction	Insulation thickness	Overall diameter	Max. Conductor resistance at 20ºC	Standard Length
mm2	No./mm	mm	mm	Ω/km	M/coil
0.50	20/0.18	0.80	2.50	36.7	500
0.75	30/0.18	0.80	2.70	24.4	500
1.25	50/0.18	0.80	3.10	14.7	500
2.0	41/0.25	0.80	3.40	9.5	500

VFF HVFF
PVC Insulated Flat Flexible Cords

Normal area	Conductor Construction	Insulation thickness	Overall diameter	Max. Conductor resistance at 20ºC	Standard Length
mm2	No./mm	mm	mm	Ω/km	M/coil
2×0.5	20/0.18	0.80	2.5×5.0	36.7	500
2×0.75	30/0.18	0.80	2.7×5.4	24.4	500
2×1.25	50/0.18	0.80	3.1×6.2	14.7	500
2×2.0	41/0.25	0.80	3.4×6.8	9.5	500

We are China PVC Insulated Single Core Bulk Power Cord Wire Vsf, Hvsf Flexible Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
