Product Details

Model NO.

Cyky CYKY-O CYKY-J

Current

DC & AC

Insulation Material

PVC

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Red Copper Wire

Certification

ISO, CCC, SGS

Model

Cyky

Brand

Hongda

Rated Voltage

0.6/1kv

Transport Package

Wooden Drum

Specification

Cyky CYKY-O CYKY-J

Trademark

hongda

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

50 Kilometer/Month

Product Description

CYKY Cable Application

Power distribution cables in power stations, industrial installations and switchgears, as well as in local mains. For fi xed installation underground, in interior premises, cable ducts, in the open air, in water – as permitted by the local building regulations – if no risk of any mechanical damage is to be expected.

CYKY Cable Standard
PNE 34 7659-3, HD 603 S1

CYKY Cable Construction

Conductors: : Cu, class 1 or 2 according to EN 60228
Insulation: PVC compound DIV 1
Bedding: Extruded elastomere or plastomere compound or plastic tape
Sheath: PVC compound DMV 1

CYKY Cable Core Identification
According to HD 308 S2

Insulation Color: 3-core (a): Green/Yellow Brown Blue
3-core (b): Black Brown Grey
4-core (a): Green/Yellow Brown Black Grey
4-core (b): Blue Brown Black Grey
5-core: Green/Yellow Blue Brown Black Grey
Outer SheathColour: Black
Other colours available on request

CYKY Cable Construction Technical Characteristics
CPR class: Eca
Test voltage: 4 Kv
Rated voltage: 0,6/1 kV
Bending radius (min): multicore – 12D
Min. laying temperature: -5°C
Max. conductor temperature: 70°C
Max. short-circuit temperature: 160°C

CYKY Cable Parameter

Number of cores x nominal cross section (mm²)	Max. conductor resistance (Ω/km)	Current rating in the ground¹⁾ (A)	Current rating in the air¹⁾ (A)	Outer diameter (mm) ca.	Total weight (kg/km) ca.
4 x 25 RE	0.752	134	101	22.4	1,350
4 x 25 RM	0.752	134	101	23.8	1,360
5 x 25 RE	0.752	134	101	24.5	1,630
5 x 25 RM	0.752	134	101	26.1	1,740
3 x 35 + 25 RE/RE	0.537/0.752	161	126	22.4	1,650
3 x 35 + 25 RM/RM	0.537/0.752	161	126	23.8	1,780
4 x 35 RE	0.537	161	126	24.8	1,770
4 x 35 RM	0.537	161	126	26.2	1,810
5 x 35 RE	0.537	161	126	27.1	2,150
5 x 35 RM	0.537	161	126	28.8	2,240
3 x 50 + 35 SM/RE	0.387/0.537	191	152	30.4	2,170
3 x 50 + 35 SM/RM	0.387/0.537	191	152	30.4	2,060
4 x 50 RM	0.387	191	152	31.3	2,590
4 x 50 SM	0.387	191	152	30.4	2,360
3 x 70 + 50 SM/RM	0.268/0.387	236	196	33.6	2,800
4 x 70 RM	0.268	236	196	35.8	3,510
4 x 70 SM	0.268	236	196	34.9	3,140
3 x 95 + 50 SM/RM	0.268/0.387	280	238	37.5	3,600
3 x 95 + 70 SM/RM	0.198/0.268	280	238	39.3	3,940
4 x 95 RM	0.198	280	238	41.3	4,730
4 x 95 SM	0.198	280	238	39.3	4,210
3 x 120 + 50 SM/RM	0.157/0.387	317	276	40.0	4,270
3 x 120 + 70 SM/RM	0.157/0.268	317	276	43.0	4,430
4 x 120 SM	0.157	317	276	43.0	5,250
3 x 150 + 70 SM/RM	0.124/0.268	359	319	46.8	5,350
4 x 150 SM	0.124	359	319	46.8	6,620
3 x 185 + 95 SM/RM	0.102/0.198	401	364	49.8	6,780
4 x 185 SM	0.102	401	364	49.8	8,030
3 x 240 + 120 SM/RM	0.078/0.157	464	430	56.4	8,570
4 x 240 SM	0.078	464	430	56.4	9,690
