Aerial insulated cable with rated voltage 1KV and Aerial Bundle Cable(ABC cable)
1. Applications
Aerial Bundle Cable (ABC cable) is a very innovative concept for overhead power distribution as compared to the conventional bare conductor overhead distribution system. It provides higher level of safety and reliability, lower power losses and ultimate system economy by reducing installation, maintenance and operative cost.
KAIQI POWER LV Aerial Bundle Cables are designed to supply 600/1000 volt aerial service for temporary service at construction sites, as a service drop (power pole to service entrance),as a secondary cable (pole to pole) or street lighting. This over-head cable provides reinforced insulation acc.
2. Standards
GB/T12527,GB/T1179 ,IEC60502 ,NFC 33-209 ,BS 7870 ,ANSI/ICEA S-76-474 AS/NZS 3560.1 etc.
3. Overhead insulated cable type, name and scope
| Chinese Type (General Type) | Short time | Description | Primary applications | |
| Copper conductor | Aluminum conductor | |||
| JKV(Cu/PVC) | JKLV(AAC/PVC) , JKLHV (AAAC/PVC) | Covered line wire
Service drop cable Secondary UD cable |
PVC insulated aerial cables | For aerial power transmission application |
| JKY(Cu/PE) | JKLY(AAC/PE),JKLHY(AAAC/PE) | PE insulated aerial cables | ||
| JKYJ(Cu/XLPE) | JKLYJ(AAC/XLPE) JKLHYJ(AAAC/XLPE) | XLPE insulated aerial cables | ||
| JKLGYJ(ACSR/XLPE) | Steel reinforced aluminium wire with XLPE insulated aerial cable | For aerial power transmission application | ||
| For aerial power transmission application able to bear moderate pulling force. | ||||
4. Operational performance
| Rated voltage | Operating temperature of different insulations ºC | Temperature while installing | Accepted bending radius | |||||||
| Long-time is allow | Short-circuit(within 5s) | |||||||||
| PVC | PE | XLPE | PVC | PE | XLPE | |||||
| D<25 | D≥25 | |||||||||
| 1kV | 70 | 70 | 90 | 160 | 130 | 250 | ≥0ºC | ≥4D | ≥6D | |
Phase conductors :Round standed or compacted 1350-H19 aluminium or Copper conductor ,AAAC,ACSR
Neutral or messenger conductor :Round standed or compacted 6201 aluminium alloy or AAC ,ACSR
Street lighting conductor: Round standed or compacted Aluminium conductor
Insulation : LDPE ,HDPE,XLPE ,PVC ( UV-resistant)
Note: The above provisions can be changed as order
Overhead line wire (Aerial line) Technical parameter GB/T12527, GB/T1179 Standar
| Number of Cores x Nominal Cross Section | Overall Diameter | Weight | Maximum Conductor Resistance | Minimum Breaking Load | Current Rating |
| No.×mm² | mm | Kg/Km | Ω/Km | kN | A |
| 4×16 RM | 18,8 | 286 | 1,910 | 2,5 | 72 |
| 4×25 RM | 21,2 | 430 | 1,200 | 4,0 | 107 |
| 4×35 RM | 24,1 | 553 | 0,868 | 5,5 | 132 |
| 4×50 RM | 27,8 | 746 | 0,641 | 8,0 | 165 |
| 4×70 RM | 31,8 | 1.009 | 0,443 | 10,7 | 205 |
| 4×95 RM | 37,8 | 1.332 | 0,320 | 13,7 | 240 |
| 4×120 RM | 54,4 | 1.632 | 0,253 | 18,6 | 290 |
0.6/1kv abc aerial bundle 4 core 35mm aluminum cable0.6/1kv abc aerial bundle 4 core 35mm aluminum cable0.6/1kv abc aerial bundle 4 core 35mm aluminum cable
