Power Cables LV Svbt in Electrical Metropolitan Networks and Stations

Power Cables LV Svbt in Electrical Metropolitan Networks and Stations image

Get Latest Price Request a quote

Product Details

Model NO.

SVBT cable

Current

DC Cable

Insulation Material

PVC

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, SGS

Model

YJV

Brand

Hongda

Rated Voltage

0.6/1kv, 600/1000V, 1.1kv

Transport Package

500m or 1000m Per Drum

Specification

1.5-300 mm2

Trademark

Hongda or OEM

Origin

China

HS Code

8544492100

Production Capacity

4000 Km / Year

Product Description

SVBT

Power cable applicable in electrical metropolitan networks and stations

DESCRIPTION

Used for transfer and distribution of electrical power for switching installation and in static installations, at rated voltage Uo/U to 0,6/1 kV with frequency 50 Hz.These cables are used for indoor installations, in the open air, in ditches, tunnels, canals and shafts.

CONSTRUCTION

Conductor:	Cu wire cl.1 or cl.2
Number of cores:	2,5mm²-300mm²
Number of cores:	7-37 cores – 1,5mm²– 2,5mm²
Armor:	steel tapes
Insulation:	PVC
Inner sheath:	PVC compound
Outher sheath:	PVC

ELECTRICAL CHARACTERISTICS

Temp. characteristic:
Max operating tº:	+70ºC
Short circuit tº:	+160ºC up to 5 sec.
tº of installation:	-5ºC/+50ºC
Ambient tº:	-30ºC/+50ºC
Nominal voltage Uo/U:	0,6/1kV
Test voltage:	AC 4kV 50Hz DC 12kV
Flame retardant:	IEC 60332-1
Min. bending radius:	single core: 15xD

Color

No. of cores	cores without green-yellow
2	brown, blue
3	brown, black, grey
4	blue, brown, black, grey
5	blue, brown, black, grey, black
6 and more	black with white numbering
	cores with green-yellow
3	green-yellow, brown, blue
4	green-yellow, brown, black, grey
5	green-yellow, blue, brown, black, grey
6 and more	green-yellow, others black with white numbering

Description	Number of cores	Cross-section /mm2/	Cable weight /kg/km/	Measure unit
Description	Number of cores	Cross-section /mm2/	Cable weight /kg/km/	Measure unit
SVBT 2 х 1,5	2	1,5	260	m
SVBT 2 х 2,5	2	2,5	260	m
SVBT 2 х 4	2	4	348	m
SVBT 2 х 6	2	6	415	m
SVBT 2 х 10	2	10	538	m
SVBT 2 х 16	2	16	710	m
SVBT 2 х 25	2	25	1038	m
SVBT 2 х 35	2	35	1315	m
SVBT 2 х 50	2	50	1706	m
SVBT 3 х 1,5	3	1,5	252	m
SVBT 3 х 2,5	3	2,5	297	m
SVBT 3 х 4	3	4	410	m
SVBT 3 х 6	3	6	490	m
SVBT 3 х 10	3	10	660	m
SVBT 3 х 16	3	16	880	m
SVBT 3 х 25	3	25	1326	m
SVBT 3 х 35	3	35	1685	m
SVBT 3 х 50	3	50	2210	m
SVBT 3 х 70	3	70	2754	m
SVBT 3 х 95	3	95	3670	m
SVBT 3 х 120	3	120	4452	m
SVBT 3 х 150	3	150	5368	m
SVBT 3 х 185	3	185	6635	m
SVBT 3 х 240	3	240	8501	m
SVBT 3 х 2,5 + 1,5	3	2,5 + 1,5	295	m
SVBT 3 х 4 + 2,5	3	4 + 2,5	450	m
SVBT 3 х 6 + 4	3	6 + 4	545	m
SVBT 3 х 10 + 6	3	10 + 6	736	m
SVBT 3 х 16 + 10	3	16 + 10	996	m
SVBT 3 х 25 + 16	3	25 + 16	1514	m
SVBT 3 х 35 + 16	3	35 + 16	1890	m
SVBT 3 х 50 + 25	3	50 + 25	2499	m
SVBT 3 х 70 + 35	3	70 + 35	3212	m
SVBT 3 х 95 + 50	3	95 + 50	4180	m
SVBT 3 х 120 + 70	3	120 + 70	5260	m
SVBT 3 х 150 + 70	3	150 + 70	6220	m
SVBT 3 х 185 + 95	3	185 + 95	7786	m
SVBT 3 х 240 + 120	3	240 + 120	9910	m
SVBT 4 х 1,5	4	1,5	286	m
SVBT 4 х 2,5	4	2,5	350	m
SVBT 4 х 4	4	4	480	m
SVBT 4 х 6	4	6	580	m
SVBT 4 х 10	4	10	800	m
SVBT 4 х 16	4	16	1080	m
SVBT 4 х 25	4	25	1642	m
SVBT 4 х 35	4	35	2175	m
SVBT 4 х 50	4	50	2767	m
SVBT 4 х 70	4	70	3480	m
SVBT 4 х 95	4	95	4794	m
SVBT 4 х 120	4	120	5805	m
SVBT 4 х 150	4	150	7195	m
SVBT 4 х 185	4	185	8715	m
SVBT 4 х 240	4	240	11090	m
SVBT 5 х 1,5	5	1,5	332	m
SVBT 5 х 2,5	5	2,5	412	m
SVBT 5 х 4	5	4	567	m
SVBT 5 х 6	5	6	706	m
SVBT 5 х 10	5	10	964	m
SVBT 5 х 16	5	16	1324	m
SVBT 5 х 25	5	25	2050	m
SVBT 5 х 35	5	35	2760	m
SVBT 5 х 50	5	50	3840	m
SVBT 5 х 70	5	70	5130	m
SVBT 7 х 1,5	7	1,5	422	m
SVBT 8 х 1,5	8	1,5	465	m
SVBT 10 х 1,5	10	1,5	570	m
SVBT 12 х 1,5	12	1,5	612	m
SVBT 14 х 1,5	14	1,5	677	m
SVBT 16 х 1,5	16	1,5	740	m
SVBT 19 х 1,5	19	1,5	818	m
SVBT 24 х 1,5	24	1,5	1043	m
SVBT 27 х 1,5	27	1,5	1072	m
SVBT 30 х 1,5	30	1,5	1183	m
SVBT 37 х 1,5	37	1,5	1371	m
SVBT 7 х 2,5	7	2,5	509	m
SVBT 8 х 2,5	8	2,5	570	m
SVBT 10 х 2,5	10	2,5	719	m
SVBT 12 х 2,5	12	2,5	779	m
SVBT 14 х 2,5	14	2,5	838	m
SVBT 16 х 2,5	16	2,5	942	m
SVBT 19 х 2,5	19	2,5	1059	m
SVBT 24 х 2,5	24	2,5	1356	m
SVBT 30 х 2,5	30	2,5	1552	m
SVBT 37 х 2,5	37	2,5	1827	m

*Further information about rating factor for certain cable arrangement can be found on supplementary technical information.

STANDARD PACKING
1.5 – 50 sqmm supplied in wooden drum @ 1000 m
70 – 300 sqmm will be suplied in wooden drum on available length
Length Tolerance per drum ± 2%
