Power Cable U1000 RO2V 1120mm2 1150mm2 1185mm2 1240mm2 XLPE PVC with Copper Conductor

Power Cable U1000 RO2V 1*120mm2 1*150mm2 1*185mm2 1*240mm2 XLPE PVC with Copper Conductor image

Get Latest Price Request a quote

Product Details

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Red Copper Wire

Certification

ISO, CCC

Model

Cu XLPE PVC

Brand

OEM

Number of Cores

Single Core

Transport Package

Wooden Drum

Specification

single core copper cable

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

50 Kilometer/Month

Product Description

Application

These cables are designed for power lines of fixed routing in wind tower installation, also used as energy supply cables installed in underground, water, cable ducts, power stations, outdoors, indoors, for industry and distribution boards as well as in subscriber networks, where mechanical damages are not expected.

Standards

IEC 60502
DIN VDE 0276 part 603

Construction

Conductor: Stranded copper conductor according to IEC60228/VDE 0295.
Insulation: XLPE
Sheath: PVC

Parameter

No. of cores and nominal cross section	Thickness of Insulation	Thickness of Sheath	Approx. overall Diameter	Approx. weight	Max. DC resistance of conductor(20ºC)	Current carrying capacity
(mm²)	(mm)	(mm)	(mm)	(kg/km)	(Ω/km)	In Air(A)	In Ground(A)
1X1.5	0.7	1.4	5.5	48	12.1	23	32
1X2.5	0.7	1.4	5.9	59	7.41	31	42
1X4	0.7	1.4	6.4	75	4.61	41	55
1X6	0.7	1.4	6.9	95	3.08	52	69
1X10	0.7	1.4	8.0	140	1.83	71	92
1X16	0.7	1.4	9.0	200	1.15	92	115
1X25	0.9	1.4	10.6	310	0.727	120	150
1X35	0.9	1.4	11.6	410	0.524	150	180
1X50	1.0	1.4	13.1	510	0.387	180	215
1X70	1.1	1.4	15.0	710	0.268	230	265
1X95	1.1	1.5	16.8	990	0.193	285	320
1X120	1.2	1.5	18.4	1230	0.153	335	360
1X150	1.4	1.6	20.5	1450	0.124	385	410
1X185	1.6	1.6	22.6	1800	0.0991	450	460
1X240	1.7	1.7	25.2	2300	0.0754	535	535
1×300	1.8	1.8	27.8	2960	0.0601	620	605
1×400	2.0	1.9	31.4	3800	0.0470	720	685
1×500	2.2	2.0	34.9	4800	0.0366	835	775
1X630	2.4	2.2	39.1	6100	0.0283	960	865

Packing

Steel wooden drum (fumigation)
Cable length in each drum: 1000m/2000m or as per actual cable length requirements.

Drum size:
As per cable length and container size
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!

Shipping Port:

Tianjin, Qingdao, or other ports as per your requireents.

Sea freight:
FOB/C&F/CIF quotation are all available.

*For some countries such as Africa countries, middle east countries, our sea freight quotation is much cheaper than clients get from local shipping agency.

Henan Hongda Cable Co., Ltd. located in No. 3, Changping Road, ZhanDian District, Jiaozuo, Wuzhi . our factory established in March of 2004. Our owns registered capital of RMB Fifty-one million six hundred and eighty thousand. Our company covers an area of 100,000 square meters, including 50,000 square meters of building area, and has more than 120 staff members and professional workers accounting for one third .our fixed assets of 90,000,000. We can provide more than 100 varieties, tens of thousands of specifications of wire and cable, with 10000 km annual production capacity

Our factory has advanced equipment of 20 sets production lines and 25 sets testing machinas, The production capacity is more than 12 million kilometers. We have skillful staff over 20-year experience,before starting working, every worker need to be trained professionally. Therefore, we can promise the product will be 100% quantified.

In our factory, every roll wire need to be test strictly, We wil test resistance, insulation thickness, the tension, stretch and so on. Before packing, every cable need to be test quantified, and we can make promise the 100% quantified.

Why Choose Us ?
1. We have a large production base, and advanced production equipment
2. Have an competitive price and high quality
3. Excellent after-sale service
4. Free issue:packaging list,invoice
5. Powerful technology team
6. Strict quality assurance system and perfect testing means
7. Advanced process equipment
8. Delivery on time
9. Our cable sales to Middle East,Africa,Russia,Southeast Asia, etc.
10.We have a good reputation in the overseas

FAQ
Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock,
it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: 30% T/T in advance,70% T/T balance before shipment
