Outdoor PE Hard Drawn Copper Clad Steel Parallel Flat Telephone Service Drop Wire 2 Core 0.9mm 1.02mm

Outdoor PE Hard Drawn Copper Clad Steel Parallel Flat Telephone Service Drop Wire 2 Core 0.9mm 1.02mm image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
Telephone Cable Twin Parallel Drop Wire Application
The drop wires are designed for use in extending telephone circuits to subscriber premises by means of an aerial drop from distribution wire or cables. The shape may be in oval/dumbbell shape to aid in separation of conductors.
1 – Conductor – Electrolytic solid copper or copper clad steel (TS 2, IEC28, ASTM B3)
2 – Outer Jacket – Linear low-density or medium-density, UV resistant black polyethylene outer jacket (ASTM D 1248).
Telephone Cable Twin Parallel Drop Wire Technical Data
Temperature range during operation (fixed state) : -15°C – +70°C
Temperature range during installation (mobile state) : -15°C – +50°C
Minimum bending radius : 10 x Overall Diameter (unarmoured cables)
Mechanical and thermal properties
Temperature range during operation (fixed state) : -30°C – +70°C
Temperature range during installation (mobile state) : -20°C – +50°C
Minimum bending radius : 10 x Overall Diameter (unarmoured cables)
Dimensions and weight
Cable Code | Number of Cores | Minimum Insulation Thickness | Maximum Cable Dimensions Diameter X Height | Nominal Weight |
---|---|---|---|---|
mm | mm | Kg/km | ||
0.91mm Conductor, 2.41mm Insulated Wire | ||||
TP1166-Y-1P091-DW1 | 2 | 0.75 | 2.7×5.6 | 25 |
0.71mm Conductor, 2.75mm Insulated Wire | ||||
TP208-Y-1P071-DW2 | 2 | 1.02 | 2.75×6.0 | 20 |
0.81mm Conductor, 2.41mm Insulated Wire | ||||
TP1247-Y-1P081-DW6 | 2 | 0.8 | 2.5×5.4 | 23 |
1.14mm Conductor, 4.18mm Insulated Wire | ||||
TP1320A-Y-1P114-DW8 | 2 | 1.52 | 4.44×9.4 | 34 |
- 100m/roll,200m/roll,305m/roll,100yard/roll,200yard/roll,305yard/roll,other lengths according clinets requires
- Inner packing:wooden reel,plastic drum,paper stool
- Outer packing:carton box,pull out box pallet available
- Other packing is available according to the client’s requirements
Henan Hongda Cable Co., Ltd. located in No. 3, Changping Road, ZhanDian District, Jiaozuo, Wuzhi. Our factroy established in March of 2004. Our owns registered capital of RMB Fifty-one million six hundred and eighty thousand. Hongda Cable covers an area of 100,000 square meters, including 50,000 square meters of building area. We have more than 120 staff members and professional workers. our fixed assets of 90,000,000. We can provide more than 100 varieties, tens of thousands of specifications of wire and cable, with 10000 km annual production capacity
Henan Hongda Cable Co. Ltd. is the original Zhengzhou Hongda Cable Co. Ltd. established enterprise expansion. The company is committed to system R&D, design, manufacturing, marketing and service of cable products,We mainly aim at managing cross-linking XLPE insulated power cables, PVC insulated power cables, plastic insulated control cables, insulated overhead cables, and stranded aluminum and ACSR. At present, the cables’ biggest cross area is 800 square meters with a maximum electric power of 35KV. The company has more than 300 (sets) domestic and oversea-leading production and testing equipment
Our factory has advanced equipment of 20 sets production lines and 25 sets testing machinas, The production capacity is more than 12 million kilometers. We have skillful staff over 20-year experience,before starting working, every worker need to be trained professionally. Therefore, we can promise the product will be 100% quantified.
In our factory, every roll wire need to be test strictly, We wil test resistance, insulation thickness, the tension, stretch and so on. Before packing, every cable need to be test quantified, and we can make promise the 100% quantified.
Why Choose Us ?
1. We have a large production base, and advanced production equipment
2. Have an competitive price and high quality
3. Excellent after-sale service
4. Free issue:packaging list,invoice
5. Powerful technology team
6. Strict quality assurance system and perfect testing means
7. Advanced process equipment
8. Delivery on time
9. Our cable sales to Middle East,Africa,Russia,Southeast Asia, etc.
10.We have a good reputation in the overseas
Welcome your inquiry to Tina
We are China Outdoor PE Hard Drawn Copper Clad Steel Parallel Flat Telephone Service Drop Wire 2 Core 0.9mm 1.02mm manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
