Nya 15mm 25mm PVC Copper Wire Cable Electrical

Nya 15mm 25mm PVC Copper Wire Cable Electrical image

Get Latest Price Request a quote

Product Details

Model NO.

NYA Cable Wire

Application

Heating, Underground

Conductor Material

Copper

Sheath Material

No Sheath

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Flame Retardant

Certification

ISO9001, CCC

Brand

OEM

Transport Package

Wooden Drum

Specification

14 AWG to 1000 Kcmil (MCM)

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

500 Kilometer/Month

Product Description

Application and Description

The NYA conductor is suitable for most current wiring solutions for residential, commercial and industrial
environments. It is used in service entrance, feeders and branch circuits for permanent installations.
NYA conductors in sizes 14 AWG to 1000 Kcmil (MCM) can be installed in conduits and other raceways. The
temperature of installation shall not exceed 75ºC(THW), not exceed 90ºC(THW-2).

Cable Construction

Conductor:
Bare annealed copper conductor, solid or stranded
Insulation:
PVC 70°C insulation
Color:
upon request, black is preferable

Technical Compliances

– ASTM B3, B8
– IEC60502
– UL 83 – Thermoplastic-Insulated Wires and Cables
– UL 1581 – Electrical Wires, Cables and Flexible Cords

Cable Parameter

AWG OR KCMIL	STRAND	NOMINAL INSULATION THICKNESS INCH/MM	NOMINL OVERALL DIAMETER INCH/MM	CABLE WEIGHT LBS/KFT KG/KM
14	1	0.030	0.76	0.169
12	1	0.030	0.76	0.189
10	1	0.030	0.76	0.213
8	1	0.045	1.14	0.240
6	1	0.060	1.52	0.276
14	7	0.030	0.76	0.177
12	7	0.030	0.76	0.201
10	7	0.030	0.76	0.228
8	7	0.045	1.14	0.291
6	7	0.060	1.52	0.335
4	7	0.060	1.52	0.386
2	7	0.080	2.03	0.445
1	19	0.080	2.03	0.531
1/0	19	0.080	2.03	0.575
2/0	19	0.080	2.03	0.622
3/0	19	0.080	2.03	0.677
4/0	37	0.080	2.03	0.740
250	37	0.095	2.41	0.823
300	37	0.095	2.41	0.882
350	37	0.095	2.41	0.937
400	37	0.095	2.41	0.984
500	61	0.095	2.41	1.079
600	61	0.110	2.79	1.197
700	61	0.110	2.79	1.272
750	61	0.110	2.79	1.307
800	61	0.110	2.79	1.343
900	61	0.110	2.79	1.409
1000	61	0.110	2.79	1.472

Available Color

Packing shipping

Why Choose Us ?
1. We have a large production base, and advanced production equipment
2. Have an competitive price and high quality
3. Excellent after-sale service
4. Free issue:packaging list,invoice
5. Powerful technology team
6. Strict quality assurance system and perfect testing means
7. Advanced process equipment
8. Delivery on time
9. Our cable sales to Middle East,Africa,Russia,Southeast Asia, etc.
10.We have a good reputation in the overseas
If you have another question, pls feel free to contact us below
