NFC 33209 Aluminum XLPE Insulation 4 Core 35sqmm Overhead Twist 4*35mm2 ABC Aerial Bundle Cable

NFC 33209 Aluminum XLPE Insulation 4 Core 35sqmm Overhead Twist 4*35mm2 ABC Aerial Bundle Cable image

Get Latest Price Request a quote

Product Details

Model NO.

ABC Cable 4 Core 35sqmm

Application

Overhead

Conductor Material

Aluminum

Sheath Material

No Sheath

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Overhead

Certification

ISO9001, CCC

Brand

OEM

Transport Package

Wooden Drum

Specification

4 Core 35sqmm

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

500 Kilometer/Month

Product Description

4 Core 35sqmm ABC cable Application

Used to supply power,usually from a pole-mounted transformer, to the user’s service head where connection to the service entrance.To be used at 600V or less phase to phase and at conductor temperatures not to exceed 75°C for polyethylene insulated or 90°C for cross linked.

4 Core 35sqmm ABC cable Standard
NFC 33-209

4 Core 35sqmm ABC cable Technical Data

Temperature range:
during installation: -5 °C
operating temperature: -30 °C up to +90 °C
at short circuit of max. 5 s: 130 °C
Nominal voltage: Uο/U = 0,6/1 kV
Test voltage: 4 kV
Minimal inner bending radius: 12D

4 Core 35sqmm ABC cable Structure

Conductor	Aluminium conductor, round stranded compressed (RM).
Insulation	XLPE. Load-bearing / neutral core – marked with standard and producers phase core – marked with digits 1, 2, 3.
Assembly	Cores and the neutral, conductor stranded together in right-hand lay, additionally 1, 2 or 3 cores of reduced cross section can be co-stranded.

4 Core 35sqmm ABC Cable Parameter

TECHNICAL DATA SHEET
Câble préassemblé torsadé 4x35mm²
No.	Description	Unit	Data Provided
1	Standards Reference		IEC 60502-1,NFC 33 209
2	Voltage	Volt	600/1000
3	Type of cable	mm²	4×35
4	Material of conductor		Stranded Aluminum wire
	Stranding no. of wires in conductor	No.	7
	Approx.diameter of conductor	mm	7.1
5	Material of insulation		Black XLPE
	Norminal thickness of insulation	mm	1.6
	Approx.diameter of insulated conductor	mm	10.3
6	Approx.overall diameter of completed cable	mm	25.1
7	Maximum d.c. resistance of conductor of cable at 20°C	ohm/km	0.868
8	Approx.weight of completed cable	kg/km	539
