NFC 33-209 Aerial Bundled Cables 3X70+54.6+1X16 ABC Cable

NFC 33-209 Aerial Bundled Cables 3X70+54.6+1X16 ABC Cable image

Get Latest Price Request a quote

Product Details

Model NO.

NFC 33-209

Current

DC & AC

Insulation Material

Bare

Sheath Material

XLPE/PE

Material Shape

Round Wire

Wire Core Material

Aluminum / AAC

Certification

ISO, CCC, SGS

Model

ABC Cable

Brand

Hongda

Standard

NFC 33-209

Applications

Ixed Installation as Overhead Power Lines

Rated Voltage

0.6/1 Kv

Test Voltage

4/50 Veff Kv/Hz

Neutral Conductor

Alloy Aluminium Conductor

Phase Conductor

Aluminium Conductor

Transport Package

500m or 1000m Per Drum

Specification

3x70+54.6+1x16 ABC Cable

Trademark

Hongda Cable

Origin

China

HS Code

8544492100

Production Capacity

1500km/Month

Product Description

600/1000V ABC -Aerial Bundled Cables to NFC 33-209 (AL/XLPE)

NFC 33-209 Aerial Bundled Cables

3×70+54.6+1×16 ABC Cable

Application

The aerial bundled cables designed for fixed installation as overhead power lines up to 1000 V incl.

Standard

NFC 33-209

Construction

Phase Conductor	Aluminium conductor, round stranded compressed (RM).
Neutral Conductor	Alloy aluminium conductor (AlMgSi), round stranded compressed (RM).
Insulation	XLPE. Load-bearing / neutral core – marked with standard and producers phase core – marked with digits 1, 2, 3.
Assembly	Cores and the neutral, conductor stranded together in right-hand lay, additionally 1, 2 or 3 cores of reduced cross section can be co-stranded.

Technical Data

Rated voltage	kV	0.6/1
Test voltage	Veff kV/Hz	4/50
Laying temperature	°C	min. -5
Operating temperature	°C	-30 ~ +90
Conductor temperature	°C	max. +90
Short-circuit temperature	°C/s	max. +250 /5
Bending radius (min.)	mm	20 × O of cable

Dimensions

Number of cores x nominal cross section	max. conductor- resistance	min. breaking load of conductor strand	Current rating in the air	Outer diameter	Total weight
mm^2	Ohm/km	kN	A	mm	kg/km
2×10 RM	3.080	1.5	38	12.8	93
4×10 RM	3.080	1.5	38	15.4	183
2×16 RM	1.910	2.3	72	14.8	129
2×16 RN + 2×1.5 RE	1.910/12.100	2.3	72	14.8	176
4×16 RM	1.910	2.3	72	17.8	257
4×16 RN + 2×1.5 RE	1.910/12.100	2.3	72	17.8	304
2×25 RM	1.200	3.8	107	18.0	202
2×25 RM + 2×1,5 RE	1.200/12.100	3.8	107	18.0	249
4×25 RM	1.200	3.8	107	21.7	404
4×25 RM + 2×1,5 RE	1.200/12.100	3.8	107	21.7	451
2×35 RM	0.868	5.2	132	20.8	269
2×35 RM + 2×1,5 RE	0.868/12.100	5.2	132	20.8	316
4×35 RM	0.868	5.2	132	25.1	539
4×35 RM + 2×1,5 RE	0.868/12.100	5.2	132	25.1	586
2×50 RM	0.641	7.6	165	23.4	352
2×50 RM + 2×1,5 RE	0.641/12.100	7.6	165	23.4	399
1×54.6 RM + 3×25 RM	0.630/1.200	3.8	107	21.7	507
1×54.6 RM + 3×25 RM + 1×16 RM	0.630/1.200/1.910	3.8/2.3	107/72	24.3	573
1×54.6 RM + 3×25 RM + 2×16 RM	0.630/1.200/1.910	3.8/2.3	107/72	29.7	639
1×54.6 RM + 3×25 RM + 3×16 RM	0.630/1.200/1.910	3.8/2.3	107/72	31.1	705
1×54.6 RM + 3×35 RM	0.630/0.868	5.2	132	25.1	615
1×54.6 RM + 3×35 RM + 1×16 RM	0.630/0.868/1.910	5.2/2.3	132/72	28.1	680
1×54.6 RM + 3×35 RM + 2×16 RM	0.630/0.868/1.910	5.2/2.3	132/72	34.3	748
1×54.6 RM + 3×35 RM + 3×16 RM	0.630/0.868/1.910	5.2/2.3	132/72	35.9	814
1×54.6 RM + 3×35 RM + 1×25 RM	0.630/0.868/1.200	5.2/3.8	132/107	28.1	714
1×54.6 RM + 3×50 RM	0.630/0.641	7.6	165	28.2	741
1×54.6 RM + 3×50 RM + 1×16 RM	0.630/0.641/1.910	7.6/2.3	165/72	31.6	806
1×54.6 RM + 3×50 RM + 2×16 RM	0.630/0.641/1.910	7.6/2.3	165/72	38.6	875
1×54.6 RM + 3×50 RM + 3×16 RM	0.630/0.641/1.910	7.6/2.3	165/72	40.4	940
1×54.6 RM + 3×50 RM + 1×25 RM	0.630/0.641/1.200	7.6/3.8	165/107	31.6	841
1×54.6 RM + 3×70 RM	0.630/0.443	10.2	205	33.0	950
1×54.6 RM + 3×70 RM + 1×16 RM	0.630/0.443/1.910	10.2/2.3	205/72	37.0	1014
1×54.6 RM + 3×70 RM + 2×16 RM	0.630/0.443/1.910	10.2/2.3	205/72	45.2	1083
1×54.6 RM + 3×70 RM + 3×16 RM	0.630/0.443/1.910	10.2/2.3	205/72	47.3	1148
1×54.6 RM + 3×70 RM + 1×25 RM	0.630/0.443/1.200	10.2/3.8	205/107	37.0	1048
1×54.6 RM + 3×70 RM + 2×25 RM	0.630/0.443/1.200	10.2/3.8	205/107	45.2	1150
1×54.6 RM + 3×70 RM + 3×25 RM	0.630/0.443/1.200	10.2/3.8	205/107	47.3	1250
1×54.6 RM + 3×95 RM	0.630/0.320	13.5	240	37.4	1176
1×54.6 RM + 3×95 RM + 1×16 RM	0.630/0.320/1.910	13.5/2.3	240/72	41.9	1243

other cross-sections on request.

NFC 33-209 Aerial Bundled Cables 3×70+54.6+1×16 ABC Cable

Packing:

Steel wooden drum (fumigation)

Cable length in each drum: 500m/1000m or as per actual cable length requirements.

Drum size:

As per cable length and container size
