Nayy 3 Cores 185sqmm Aluminum Conductor Unarmoured Power Cable

NAYY 3 Cores 185sqmm Aluminum Conductor unarmoured Power Cable

NAYY  3 cores 185mm2 Unarmoured Power Cables  0.6/1KV

TECHNICAL PARTICULAR AND SPECIFICATION



Company Information

Hongda cable Co., Ltd. is one of the most professional cable & wire producer under modern enterprise system in China, which was founded in 1988, integrating scientific research, development, production and sales. Henan Hongda Cable Co., is the original Zhengzhou Hongda Cable Co.,  The company mainly produces 1-35 kV power cable, TW, THW, THHW, THHN electrical wire, ABC cable, Overhead ABC Cable.

Product Description

1 Main Application
These cables are used for electricity supply in low voltage installation system, they are suitable for installation in indoors and outdoors, in cable ducts, underground, in power and switching stations, local energy distributions, industrial plants, where there is no risk of mechanical damage.
2 Standards
GB/12706-2008, IEC60502-1, IEC 60228, IEC60332, BS 6346, AS/NZS 5000.1 etc.
we can also design and produce for special application requirement.

3   Product Properties
3.2 The ambient temperature for installation: ≥0ºC
3.3 Maximum conductor temperature in normal operation:≤70ºC
3.4 Max operating temperature of con. When cable short-circuited(5s maximum duration): 160ºC
3.5 Permissible minimum bending radius:
Single unarmoured cable: (20D±5%)mm
Multi-core unarmoured cable:(15D±5%)mm
Single armoured cable: (15D±5%)mm
Multi-core armoured cable:(12D±5%)mm
Note : D=over cable diameter

4  Product Type


Note: KAIQI POWER can produce “Flame-Retardant Series”, “Fire-Resistant Series”, “Low Smoke Halogen Free (LSHF/LSOH) Series”,”Low Smoke Low Halogen (LSLH) Series”, etc. power cable as customer required.

Performance in line withIEC60331, IEC60332,IEC 61034,IEC60754 requirements.

5   Construction

Conductor shaped:RE=circular solid,CC=compacted circular stranded,SM=sector shaped stranded

Conductor: Plain circular ,compacted or shaped stranded copper or aluminium conductor ,conform to IEC60228 CLass 1 or Class 2

Insulation: PVC Compound Insulation

Colour identification :

1 Core: Red or Black

2 Cores: Red, Black

3 Cores: Red, Yellow, Blue

4 Cores: Red, Yellow, Blue, Black

5 Cores: Red, Yellow, Blue, Black, Green

Above 5 Cores: Black Cores with White numerals

The above identifying can be changed as order

Bedding /Inner Sheath :PVC Compound

Armour: Aluminium wire(AWA) or aluminium alloy wire(AWA), Galvanized steel wire(SWA) or steel tape(STA) ect.

Outer Sheath:PVC or PE Compound

Note: The armored material of single core cable should be non-magnetic or magnetic reduced structure. Generallly, single core armored cable (which uses steel or steel wire armored cable) only applies to DC occasions.
