Multicore Cu PVC CT Sta Copper Tape Screened Steel Tape Armored Control Cable Low Voltage

Multicore Cu PVC CT Sta Copper Tape Screened Steel Tape Armored Control Cable Low Voltage image

Get Latest Price Request a quote

Product Details

Model NO.

Steel Tape Armored Control Cable

Application

Heating

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Certification

ISO9001, CCC

Brand

OEM

Transport Package

Wooden Drum

Specification

1.5mm to 50mm2

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

50 Kilometer/Month

Product Description

Application and Description

For supervisory electrical equipment, station control circuits, outdoor, suitable installation in dry or wet cable trenches.
Cable Construction

Conductor	Concentric stranded annealed copper wires, Sizes: 0.5 mm^2 up to 6 mm^2
Insulation	Polyvinyl chloride (PVC)
Color	2-4 cores : Black, White, Red and Green
	More than 4 cores : Black core with marking numbers
Filler	Non-hygroscopic material(optional)
Binding tape	Polyester (Mylar) tape (optional)
Sheath	Polyvinyl chloride (PVC), Black color (A Special FR-PVC flame retardant sheath can be supplied)

Maximum conductor temperature 70°C

Circuit voltage not exceeding 600 volts

Test voltage 2000volts(JIS) / 3500 volts(IEC)
