Multiconductor Cable Vvmv Vvmv-K PVC/PVC/Swa/PVC Armoured Cable

Multiconductor Cable Vvmv Vvmv-K PVC/PVC/Swa/PVC Armoured Cable image

Get Latest Price Request a quote

Product Details

Model NO.

vvmv-k cable

Current

AC Cable

Insulation Material

PVC

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE, SGS

Model

Vvmv-K

Brand

Hongda

Standard

IEC 60502, IEC 60332

Rated Voltage

0.6/1 Kv

Armour

Swa (Awa for Single Core)

Conductor

Class 5 Copper Conductors to En60228

Specification

1.5mm2 to 400mm2

Trademark

Hongda

Origin

China

HS Code

8544492100

Production Capacity

800km/Month

Product Description

0.6/1kV multiconductor cable vvmv vvmv-k pvc pvc swa pvc armoured cable

VVMV / VVMV-K Power Cable

VVMV / VVMV-K flexible, armoured power cable suitable for use in hazardous areas such as petrochemical plants due to its excellent mechanical protection and crush resistance.

Applications

VVMV / VVMV-K cable suitable for installation in potentially explosion hazard locations, eg petrol stations, petrochemical plants. In addition it offers excellent mechanical protection and crush resistance offering highly protected power transmission eg street lighting.

Cable Construction

Conductors: Class 2 copper conductors to EN60228
Insulation: PVC
Bedding: PVC
Armour: SWA (AWA for single core)
Sheath/Jacket: PVC
Colour: Black
Voltage: 0.6/1kV
Operating temperature: Maximum +90°C, minimum -15°C
Standard: IEC 60332 Tests on electric and optical fibre cables under fire conditions
IEC 60502: Power cables with extruded insulation and their accessories for rated voltages from 1kV to 30kV

Colour Code

1 Core	natural
2 Cores	blue & brown
3 Cores	brown, black and gray
3 Cores ground	blue, brown & green/yellow
4 Cores	brown, black, gray, blue
4 Cores ground	brown, black, gray & green/yellow
5 Cores	brown, black, gray, blue, yellow & green
Above 5 Cores	Black Cores with White numerals

Other colours can be manufactured upon request.

Dimensions:

CABLE REFERENCE		DIMENSIONAL DATA					ELECTRICAL DATA
Cable code	Cores and cross section	Insulation thickness (mm)	Sheath thickness (mm)	Overall Diameter aprox. (mm)	Bending radius (mm)	Weight of cable aprox. (Kg/Km)	Max. Current at 25ºC (Buried) A	Max. Current at 40ºC (Overhead) A	Voltage drop at cos=0,8 V/A-km	Voltage drop at cos=1 V/A-km
10200110015	1×1,5	0,7	1,8	10,1	101	139	–	–	24,75	30,86
10200110025	1×2,5	0,7	1,8	10,6	106	158	–	–	15,17	18,9
10200110040	1×4	0,7	1,8	11,1	111	184	–	–	9,46	11,76
10200110060	1×6	0,7	1,8	11,6	116	210	–	–	6,34	7,86
10200110100	1×10	0,7	1,8	12,6	126	268	–	–	3,79	4,67
10200110160	1×16	0,7	1,8	13,6	136	339	–	–	2,4	2,94
10200110250	1×25	0,9	1,8	15,2	152	464	–	–	1,54	1,86
10200110350	1×35	0,9	1,8	16,3	163	577	–	–	1,12	1,34
10200110500	1×50	1	1,8	17,9	179	734	–	–	0,84	0,99
10200110700	1×70	1,1	1,8	20	200	961	–	–	0,6	0,69
10200110950	1×95	1,1	1,8	22,5	225	1297	–	–	0,44	0,5
10200111200	1×120	1,2	1,8	24,6	246	1585	–	–	0,36	0,39
10200111500	1×150	1,4	1,8	27,2	271	1901	–	–	0,3	0,32
10200111850	1×185	1,6	1,9	29,8	298	2445	–	–	0,25	0,26
10200112400	1×240	1,7	2	33	330	3124	–	–	0,16	0,2
10200113000	1×300	1,8	2,2	38	380	3894	–	–	0,13	0,16
10200114000	1×400	2	2,3	41,4	414	4980	–	–	0,11	0,13
10200115000	1×500	2,2	2,5	47	470	6355	–	–	0,09	0,11
10200116300	1×630	2,4	2,6	52,3	523	7078	–	–	0,07	0,09
10200210015	2×1,5	0,7	1,8	13	130	322	21	19	21,44	26,73
10200210025	2×2,5	0,7	1,8	13,9	139	377	28	26	13,15	16,37
10200210040	2×4	0,7	1,8	15	150	449	36	35	8,2	10,19
10200210060	2×6	0,7	1,8	16	160	522	45	44	5,5	6,81
10200210100	2×10	0,7	1,8	18	180	682	60	61	3,29	4,05
10200210160	2×16	0,7	1,8	19,9	199	870	77	82	2,08	2,54
10200210250	2×25	0,9	1,8	24,1	241	1397	99	104	1,34	1,61
10200210350	2×35	0,9	1,8	26,3	263	1707	119	129	0,98	1,16
10200210500	2×50	1	1,9	29,7	297	2167	141	157	0,73	0,86
10200210700	2×70	1,1	2,1	35,4	354	3122	174	202	0,52	0,6
10200210950	2×95	1,1	2,2	38,8	388	3873	205	245	0,39	0,43
10200211200	2×120	1,2	2,4	44,2	442	4983	234	285	0,32	0,34
10200211500	2×150	1,4	2,6	49,9	499	6094	264	330	0,27	0,28
10200211850	2×185	1,6	2,7	55,3	553	7608	296	378	0,23	0,22
10200212400	2×240	1,7	2,9	60,6	606	9283	343	447	0,14	0,17
10200213000	2×300	1,8	3,2	69,6	696	11593	388	516	0,12	0,14
10200214000	2×400	2	3,5	78	780	15410	–	–	0,09	0,12
10200310015	3×1,5	0,7	1,8	13,5	135	354	17	16	21,44	26,73
10200310025	3×2,5	0,7	1,8	14,4	144	420	23	22	13,15	16,37
10200310040	3×4	0,7	1,8	15,6	156	512	29	30	8,2	10,19
10200310060	3×6	0,7	1,8	16,7	167	601	37	37	5,5	6,81
10200310100	3×10	0,7	1,8	18,9	189	800	49	52	3,29	4,05
10200310160	3×16	0,7	1,8	21,8	218	1211	64	70	2,08	2,54
10200310250	3×25	0,9	1,8	25,4	254	1673	82	88	1,34	1,61
10200310350	3×35	0,9	1,8	27,8	278	2087	98	110	0,98	1,16
10200310500	3×50	1	2	32,3	323	2882	116	133	0,73	0,86
10200310700	3×70	1,1	2,2	37,6	376	3831	143	171	0,52	0,6
10200310950	3×95	1,1	2,3	41,3	413	4815	170	207	0,39	0,43
10200311200	3×120	1,2	2,5	47,4	474	6256	193	240	0,32	0,34
10200311500	3×150	1,4	2,7	53,2	532	7569	218	278	0,27	0,28
10200311850	3×185	1,6	2,9	59,4	594	9615	245	317	0,23	0,22
10200312400	3×240	1,7	3,1	64,7	647	11757	282	374	0,14	0,17
10200313000	3×300	1,8	3,4	75,9	759	15563	319	432	0,12	0,14
10200314000	3×400	2	3,7	83,3	833	19471	–	–	0,09	0,12
10200410015	4×1,5	0,7	1,8	14,2	142	399	17	16	21,44	26,73
10200410025	4×2,5	0,7	1,8	15,3	153	479	23	22	13,15	16,37
10200410040	4×4	0,7	1,8	16,6	166	593	29	30	8,2	10,19
10200410060	4×6	0,7	1,8	17,8	178	701	37	37	5,5	6,81
10200410100	4×10	0,7	1,8	21,2	212	1119	49	52	3,29	4,05
10200410160	4×16	0,7	1,8	23,5	235	1440	64	70	2,08	2,54
10200410250	4×25	0,9	1,8	27,5	275	2021	82	88	1,34	1,61
10200410350	4×35	0,9	1,9	30,4	304	2555	98	110	0,98	1,16
10200410500	4×50	1	2,1	35,7	357	3565	116	133	0,73	0,86
10200410700	4×70	1,1	2,3	41,1	411	4701	143	171	0,52	0,6
10200410950	4×95	1,1	2,4	46,1	461	6240	170	207	0,39	0,43
10200411200	4×120	1,2	2,6	52	520	7747	193	240	0,32	0,34
10200411500	4×150	1,4	2,9	58,9	589	9444	218	278	0,27	0,28
10200411850	4×185	1,6	3,1	65,4	654	11969	245	317	0,23	0,22
10200412400	4×240	1,7	3,3	72,4	724	15562	282	374	0,14	0,17
10200413000	4×300	1,8	3,7	83,7	837	19394	319	432	0,12	0,14
10200414000	4×400	2	3,9	92	920	24410	–	–	0,09	0,12
10200510015	5×1,5	0,7	1,8	15	150	448	17	16	21,44	26,73
10200510025	5×2,5	0,7	1,8	16,2	162	545	23	22	13,15	16,37
10200510040	5×4	0,7	1,8	17,7	177	679	29	30	8,2	10,19
10200510060	5×6	0,7	1,8	19,1	191	812	37	37	5,5	6,81
10200510100	5×10	0,7	1,8	22,7	227	1288	49	52	3,29	4,05
10200510160	5×16	0,7	1,8	25,2	252	1693	64	70	2,08	2,54
10200510250	5×25	0,9	1,9	29,9	299	2406	82	88	1,34	1,61
10200510350	5×35	0,9	2	33,9	339	3275	98	110	0,98	1,16
10200510500	5×50	1	2,2	38,9	389	4257	116	133	0,73	0,86
10200510700	5×70	1,1	2,4	45,8	458	5916	143	171	0,52	0,6
10200510950	5×95	1,1	2,6	50,9	509	7564	170	207	0,39	0,43
10200511200	5×120	1,2	2,8	57	569	9328	193	240	0,32	0,34
10200511500	5×150	1,4	3	64,6	646	11390	218	278	0,27	0,28
10200511850	5×185	1,6	3,3	72,9	729	15351	245	317	0,23	0,22
10200512400	5×240	1,7	3,6	80	800	18936	282	374	0,14	0,17
10200513000	5×300	1,8	3,9	92,1	921	23522	319	432	0,12	0,14
10200514000	5×400	2	4,1	97,5	975	28714	–	–	0,09	0,12

Designation:

V – PVC insulation

V – PVC bedding

M – Steel wire armour

V – PVC sheath

-K – Flexible conductor

Packing & Shipping:

Packing
Steel wooden drum (fumigation)
Cable length in each drum: 1000m/2000m or as per actual cable length requirements.

Drum size:
As per cable length and container size
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!

Shipping Port:
Shanghai, Qingdao, Tianjin or other ports as per your requirements.

Sea freight:
FOB/C&F/CIF/DAP quotation are all available.

Whilst HONGDA CABLE plc endeavours to ensure the information on the website, specification sheets and all other technical information is accurate, the information is for guidance only and it is subject to change without notice or liability. HONGDA Cable Plc is not responsible for the consequences of any inadequacies, inaccuracies or other deficiencies contained therein. When selecting cable accessories, please note that the actual cable dimensions may vary due to manufacturing tolerances.
