Lxhioz1 Cable 1120mm 1240mm 8.7/15kv

Lxhioz1 Cable 1*120mm 1*240mm 8.7/15kv image

Get Latest Price Request a quote

Product Details

Model NO.

LXHIOZ1 Cable 1*120mm

Application

Overhead, Underground

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Flame Retardant

Certification

ISO9001, CE, CCC

Brand

OEM

Transport Package

Wooden Drum

Specification

2.5~400sqmm

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

50 Kilometer/Month

Product Description

DESCRIPTION:

LXHIOZ1 Unarmoured PO Single Core Fire Retardant Halogen Free Aluminium Cable with Copper Wire Screen 3.6/6 (7.2) kV up to 18/30 (36) kV – Cable for power distribution and power supply stations, halogen free and fire retardant used in Utility and Industrial applications, for rated voltages up to 18/30kV. Applicable for installations of high security in relation to fire, namely tunnels, underground railways.

A = Voltage U0/U(Um) [kV]

B = Outer Diameter [mm]

C = Conductor Cross-section [mm2]

D = Diameter Over Insulation [mm]

E = Current Carrying Capacity – In Air (A)

Ambient Temperature for cables in air = 30°C

Electrical Characteristic

CONDUCTOR MATERIAL	Aluminium
CONDUCTOR CLASS	Circular, Stranded Class 2
INSULATION	XLPE – Cross-linked Polyethylene
METALLIC SCREEN	Copper Wire Screen – Annealed Copper Wires Helicaly Wound and Equalising Copper Tape Applied in Open Counter-helix. Plastic Tape is Applied Over Screen
OVERSHEATH	LSHF Low Smoke Halogen Free Thermoplastic Compound, Polyolefin Type DMZ2
OVERSHEATH COLOUR	Black
CABLE DESIGNATION	Al, Cu Tape Screen, PO, XLPE
TEST VOLTAGE	3.5xUo
CONDUCTOR OPERATING TEMP	90°C (nominal) to 120°C (2)
MAX SHORT-CIRCUIT TEMP	250°C (t<5s)
AMBIENT TEMPERATURE	Cables in Air 30°C
MAX PULLING FORCE (N)	30xConductor Cross-section [mm2] Over Conductor (N)
BEDDING	LSHF Low Smoke Halogen Free Thermoplastic Compound
FIRE RETARDANT	Bunch of Cables Vertically Mounted on a Ladder, Length of Charred Cable <2.5m

Packing shipping

If you have another question, pls feel free to contact us below

We are China Lxhioz1 Cable 1*120mm 1*240mm 8.7/15kv manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
