LV XLPE Insulated ABC Cable 95mm Aluminum Single Core
LV XLPE Insulated ABC Cable 95mm Aluminum Single Core image
Get Latest Price Request a quote
You May Like
Product Details
Model NO.
abc cable 95mm
Application
Overhead
Conductor Material
Aluminum
Sheath Material
No Sheath
Insulation Material
XLPE
Material Shape
Round Wire
Range of Application
Overhead
Certification
ISO9001, CCC
Brand
OEM
Transport Package
Wooden Drum
Specification
2.5~400sqmm
Trademark
OEM
Origin
China(Mainland)
HS Code
8544492100
Production Capacity
500 Kilometer/Month
Product Description
Application
Use in aerial bundled conductor (ABC) systems for city power grid transmission line.
Operating voltage up to 600/1000 volts.
Main for overhead single-phase and three-phase electricity distribution and other purposes.
Stable working temperature -10°C to 90°C
Product Features:
- Economical – Good electricity property and cheaper than cooper cables.
- Flexible – easy to install and work with distributions and other applications.
- Safe – prevent electric short circuit and potential risk of fire.
- Durable – anti UV Radiation and moisture, Corrosion Resistance.
- Aesthetically pleasing – Good finishing is guaranteed.
- Adaptable – physical properties and electricity suits Africa environment and market.
Construction
- Hard-drawn stranded aluminum wires and compacted as Core.
- All cores strained equally.
- Carbon-loaded XLPE insulated UV resistance acquired.
Specifications
- Both self-supporting and supporting-core systems available.
- Self-supporting is AAC strand compacted conductor up to 4 cores XLPE insulated.
- Supporting-core is AAAC conductor XLPE insulated.
- Conductor and supporting-core can be offered in single, duplex, triplex, and quadruplex.
- Flame retardant, fire resistance and other requirement can be full-filled.
- Rare specifications or producing by your sample can also be full filled.
| Sectional Area | Conductor | Insulation | Weight | |||||
| Thread | Diameter | overall diameter | Thickness | outer diameter | kg/km | |||
| mm2 | No. | mm | mm | mm | mm | Conductor | Insulation | Total |
| 35 | 7 | 2.14 | 6.42 | 1.2 | 8.82 | 69.3 | 32.1 | 101 |
| 50 | 19 | 1.78 | 8.9 | 1.4 | 11.7 | 130.2 | 48.1 | 178 |
| 70 | 19 | 2.14 | 10.7 | 1.4 | 13.5 | 188.2 | 58.1 | 246 |
| 95 | 19 | 2.52 | 12.6 | 1.6 | 15.8 | 261 | 78.3 | 339 |
Packing Shipping
If you have another question, pls feel free to contact us below
Tina / Sales Manager
We are China LV XLPE Insulated ABC Cable 95mm Aluminum Single Core manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
