LSZH Low Smoke Halogen Free Wire H07z-K 1.5mm 2.5mm 4mm 6mm Single Core Electric Cable

LSOH Cable Low Smoke Halogen Free Copper Wire H07Z-K H07Z-R

H07Z-K Cable 450/750V Application

H07Z -K Halogen-free cables are used for installations in dry environment for wiring of lighting fixtures, tools and other devices in facilities where human lives or valuable property need to be protected against damages caused by fire. Laid on or under plaster, same as in closed installation canals. For inner wiring of switchboards and control panels up to the nominal voltage of 750/1000 V.

In pipes or ducts and internal wiring of appliances with maximum operating temperatures of 90°C, and generally in areas (such as public and government buildings) where smoke and toxic fumes may cause a threat to life and equipment. The cables produce no corrosive gases when burnt which is particularly important where electronic equipment is installed.

This cable is particulary suited in high fire risk places containing a great number of people (like office, data processing centres, schools, hotels, supermarkets, undergrounds, hospitals, cinemas, theaters, discos).

H07Z-K Cable 450/750V Standards

• <HAR> HD 22.9 S2,
• VDE-0282 Part-9,
• BS 7211,
• IEC 60754-2,
• EN 50267,
• VDE 0482-267,
• CE Low Voltage Directive 73/23/EEC and 93/68/EEC,
• ROHS compliant

H07Z-K Cable 450/750V Construction

H07Z -K Cable 450/750V Technical Data

Tolerance of pulley is ±5%

Insulated conductor Cable PACKAGING:

A: Roll of 100 m
B: Reel of 1500 m.
C: Reel of 1000 m.
D: Reel of 500 m.
E: Multiple Reels of 1000 m.
Z – Length to the client’s requirement.

Insulated conductor Cable AVAILABLE COLORS:

Cables (Sizes 0.5mm2 to 6mm2): Black, White, Sky Blue, Blue, Red, Purple, Yellow and Green.
Cables (Sizes 10mm2 to 25mm2): Black, White, Blue and Red.
Cables (Sizes 25mm2 to 240mm2): Black. HIGHER SIZES (FROM 750 MCM TO 1.000 MCM), UNDER REQUIREMENT.

Company Profile:
Hongda cable Co., Ltd. is one of the most professional cable & wire producer under modern enterprise system in China, which was founded in 1988, integrating scientific research, development, production and sales. Henan Hongda Cable Co., is the original Zhengzhou Hongda Cable Co.,  The company mainly produces 1-35 kV power cable, TW, THW, THHW, THHN electrical wire, ABC cable, Overhead Cable, AAC, AAAC, ACSR, ACAR bare conductor, Concentric Cable, etc

Our advantages
1.  With more than 17 years manufacturing experience, our products are strictly in accordance with ISO, SGS, CCC ;
2.  Good cost-control system, with highly-competitive prices;
3.  Strong and Professional R&D team to meet your specific needs;
4.  Fast delivery&reliable products are always the reason why you choose us.
Custom Merchandise: we can make cable as your need include the color ,size and so on.we also offer OEM .
Complete Course Tracking: we can offer you the service from the business begin to you get the cable and use it
Cable sample :  we can offer the sample free

Please contact us for technical support with the right cable selection for your power distribution projects and to discuss your maintenance or project specific requirements. We provide tailored solutions for this cable range which include storage, cutting to length, and 2 days collection as standard.

Any problem and inquiry pls contact with Tina
