Low Voltage Cu XLPE PVC Insulated 3X2.5mm 3 Core 2.5mm2 U1000 RO2V Copper Wire Cable
Low Voltage Cu XLPE PVC Insulated 3X2.5mm 3 Core 2.5mm2 U1000 RO2V Copper Wire Cable image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
XLPE 3 Cores Copper Cable Application
These cables are used for outdoor and indoor installations in damp and wet applications. They are normally used for power distribution in urban networks, industrial plants and energy distribution. For mains, submains and subcircuits unenclosed, enclosed in conduit, buried direct or in underground ducts for buildings and industrial plants where not subject to mechanical damage. Suitable where space is at a premium.
XLPE 3 Cores Copper Cable Standards:
IEC 60228 Conductors
IEC 60502-1 Power cables with extruded insulation and their accessories for rated voltages from 1kV(Um=1.2kV) up to 30kV(Um=36kV) – Part 1: Cables for rated voltages of 1 kV(Um=1.2kV) and 3 kV(Um=3.6kV)
XLPE 3 Cores Copper Cable Construction:
1. Conductor: Copper , Class 1: solid conductor, or Class 2: stranded conductor
2. Insulation: Cross-linked polyethylene XLPE
3. Filler: Non-hygroscopic material
4. Binder tape: Non-hygroscopic material
5. Outer sheath: Polyvinyl chloride PVC
XLPE 3 Cores Copper Cable Parameter:
| 0.6/1kV-3 core copper conductor XLPE insulated PVC sheathed power cable | |||||||
| No. of cores and nominal cross section | Thickness of Insulation | Thickness of Sheath | Approx. overall Diameter | Approx. weight | Max. DC resistance of conductor(20ºC) | Current carrying capacity | |
| (mm2) | (mm) | (mm) | (mm) | (kg/km) | (Ω/km) | In Air(A) | In Ground(A) |
| 3X1.5 | 0.7 | 1.8 | 11.8 | 135 | 12.1 | 21 | 30 |
| 3X2.5 | 0.7 | 1.8 | 12.7 | 180 | 7.41 | 28 | 39 |
| 3X4 | 0.7 | 1.8 | 13.8 | 225 | 4.61 | 37 | 51 |
| 3X6 | 0.7 | 1.8 | 14.9 | 300 | 3.08 | 47 | 64 |
| 3X10 | 0.7 | 1.8 | 17.2 | 430 | 1.83 | 65 | 86 |
| 3X16 | 0.7 | 1.8 | 19.4 | 630 | 1.15 | 84 | 110 |
| 3X25 | 0.9 | 1.8 | 22.8 | 940 | 0.727 | 110 | 140 |
| 3X35 | 0.9 | 1.8 | 25.0 | 1250 | 0.524 | 135 | 170 |
| 3X50 | 1.0 | 1.8 | 24.4 | 1500 | 0.387 | 170 | 205 |
| 3X70 | 1.1 | 1.9 | 29.4 | 2140 | 0.268 | 215 | 250 |
| 3X95 | 1.1 | 2.0 | 33.6 | 2960 | 0.193 | 265 | 300 |
| 3X120 | 1.2 | 2.1 | 35.9 | 3760 | 0.153 | 310 | 345 |
| 3X150 | 1.4 | 2.3 | 39.9 | 4420 | 0.124 | 350 | 385 |
| 3X185 | 1.6 | 2.4 | 44.1 | 5950 | 0.0991 | 405 | 435 |
| 3X240 | 1.7 | 2.6 | 51.1 | 7100 | 0.0754 | 480 | 500 |
| 3X300 | 1.8 | 2.7 | 56.1 | 9000 | 0.0601 | 555 | 565 |
| 3X400 | 2.0 | 3.0 | 62.4 | 10000 | 0.0470 | 640 | 640 |
Henan Hongda Cable Co., Ltd. located in No. 3, Changping Road, ZhanDian District, Jiaozuo, Wuzhi . our factory established in March of 2004. Our owns registered capital of RMB Fifty-one million six hundred and eighty thousand. Our company covers an area of 100,000 square meters, including 50,000 square meters of building area, and has more than 120 staff members and professional workers accounting for one third .our fixed assets of 90,000,000. We can provide more than 100 varieties, tens of thousands of specifications of wire and cable, with 10000 km annual production capacity
Our factory has advanced equipment of 20 sets production lines and 25 sets testing machinas, The production capacity is more than 12 million kilometers. We have skillful staff over 20-year experience,before starting working, every worker need to be trained professionally. Therefore, we can promise the product will be 100% quantified.
In our factory, every roll wire need to be test strictly, We wil test resistance, insulation thickness, the tension, stretch and so on. Before packing, every cable need to be test quantified, and we can make promise the 100% quantified.
Packing
Steel wooden drum (fumigation)
Cable length in each drum: 1000m/2000m or as per actual cable length requirements.
Drum size:
As per cable length and container size
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!
Shipping Port:
Tianjin, Qingdao, or other ports as per your requirements.
Sea freight:
FOB/C&F/CIF quotation are all available.
*For some countries such as Africa countries, middle east countries, our sea freight quotation is much cheaper than clients get from local shipping agency
Any problem and inquiry please contact with Tina
Phone number: +86-15737156317
We are China Low Voltage Cu XLPE PVC Insulated 3X2.5mm 3 Core 2.5mm2 U1000 RO2V Copper Wire Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
