Low Voltage BS5467 Swa XLPE Cable Armoured Power Cables

Low Voltage BS5467 Swa XLPE Cable Armoured Power Cables image

Get Latest Price Request a quote

Product Details

Model NO.

bs5467

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE

Model

BS5467 Cable

Brand

Hongda

Armoured

Steel Wire or Steel Tape

Rated Voltage

600/1000V

Minimum Bending Radius

8 X Overall Diameter

Transport Package

Steel & Wooden Drum

Specification

1.5mm2 to 400mm2

Trademark

Hongda Cable

Origin

China

HS Code

8544492100

Production Capacity

300km/Month

Product Description

BS5467 SWA/PVC Cable IEC 60502 600/1000V

Applications: Power cable suitable for power networks, direct burial, outdoors, indoors and in cable ducts.

Conductors: Plain annealed stranded copper

Insulation: XLPE (Cross linked polyethylene)

Bedding: PVC (Polyvinyl-Chloride)

Armour/Protection: SWA (Galvanised single wire armour)

Sheath/Jacket: PVC (Polyvinyl-Chloride)

Colour: Black

Voltage: 600/1000v

Operating temperature: Maximum 90°C. Minimum bending 0°C

Minimum bending radius:

1.5 sq.mm – 16 sq.mm -6 x overall diameter (circular cond.)

25 sq.mm and above – 8 x overall diameter (shaped cond.)

Core identification:
Two Core – Brown, Blue
Three Core – Brown, Black & Grey (Optional: Brown, Blue & Green/Yellow)
Four Core – Brown, Black, Grey & Blue (Optional: Brown, Black, Grey & Green/Yellow)
Five Core – Numbered Cores (Optional: Brown, Black, Grey, Blue + Green/Yellow)
Six Core and Above – Numbered Cores (optional numbered + Green and Yellow)

Conductor stranding:
Class 2 stranded copper:
2 circular or circular compacted conductors
2* shaped or circular conductors or circular compacted conductors.
2S shaped conductors
(Dimensions and weights based on circular)

Standard:
BS5467: Electric cables. Thermosetting insulated, armoured cables for voltages of 600/1000V and 1900/3300V
IEC60502: Power cables with extruded insulation and their accessories for rated voltages from 1kV to 30kV
Flame Propagation Test to BS EN 60332-1-2 for single cable

Note:If you are considering installing in high UV exposure and/or high/low ambient temperatures i.e. desert/arctic conditions then special sheathing may be required.

Dimensions – BS5467 XLPE/PVC/AWA/PVC (Copper)

No. of Cores	Nominal Cross Sectional Area	Nominal Thickness of Insulation	Nominal Overall Diameter mm		Nominal Weight
No. of Cores	mm²	mm	Under Armour	Overall	kg/km
2	1.5	0.6	7.3	12.1	302
2	2.5	0.7	8.5	13.6	346
2	4	0.7	9.4	14.7	410
2	6	0.7	10.5	15.9	499
2	10	0.7	12.3	18	648
2	16	0.7	14.3	20.4	978
2	25	0.9	14.7	20.4	1290
2	35	0.9	16.8	23.3	1500
2	50	1	19	25.8	1890
2	70	1.1	22	29	2450
2	95	1.1	25.1	33.1	3300
2	120	1.2	27.9	36.1	4020
2	150	1.4	30.9	39.3	4750
3	1,5	0.6	7.8	12.6	330
3	2.5	0.7	9.2	14.1	390
3	4	0.7	10	15.3	464
3	6	0.7	11.2	16.6	568
3	10	0.7	13.1	19.5	866
3	16	0.7	15.3	21.6	1152
3	25	0.9	18.9	23.6	1800
3	35	0.9	21.3	25.7	2230
3	50	1	21.7	28.5	2490
3	70	1.1	25.2	32.2	3290
3	95	1.1	28.8	37	4440
3	120	1.2	32	40.4	5470
3	150	1.4	35.9	45.5	6930
3	185	1.6	40	49.8	8350
3	240	1.7	44.9	55.1	10400
3	300	1.8	49.8	60.2	12600
3	400	2	55.8	66.6	14600
4	1.5	0.6	8.5	13.3	365
4	2.5	0.7	9.9	15	438
4	4	0.7	11	16.4	532
4	6	0.7	12.3	18.7	764
4	10	0.7	14.5	21.1	1013
4	16	0.7	17	23.4	1360
4	25	0.9	21	26.1	2160
4	35	0.9	23.6	28.6	2690
4	50	1	25	32	3130
4	70	1.1	29.5	37.7	4500
4	95	1.1	33.3	41.7	5600
4	120	1.2	37.5	47.1	7400
4	150	1.4	41.6	51.4	8780
4	185	1.6	46.4	56.6	10630
4	240	1.7	52.6	63	13390
4	300	1.8	58	68.8	16290
4	400	2	65.4	78.1	19800
5	1.5	0.6	9.7	14.3	410
5	2.5	0.7	11.7	16.1	470
5	4	0.7	13	17.8	710
5	6	0.7	14.5	20	876
5	10	0.7	17.2	22.9	1165
5	16	0.7	20	26.6	1742
5	25	0.9	24.7	31.5	2323
5	35	0.9	27.8	34.8	2932
5	50	1	32.4	40.4	4192
7	1.5	0.6	10.2	15.2	470
7	2.5	0.7	12.3	17.1	600
7	4	0.7	13.6	19.1	881
12	1.5	0.6	13.7	19.4	780
12	2.5	0.7	16.3	22.4	1000
19	1.5	0.6	16.2	22.2	1000
19	2.5	0.7	19.9	26.6	1540
27	1.5	0.6	20	26.7	1500
27	2.5	0.7	24	30.7	1950
37	1.5	0.6	22.3	29	1800
37	2.5	0.7	26.9	33.8	2350

Class 2 Stranded Conductors for Single Core and Multi-Core Cables

Nominal Cross Sectional Area	Minimum No. Of Wires In Conductor						Maximum Resistance of Conductor At 20ºC
mm²	Circular		Circular Compacted		Shaped		Annealed Copper Conductor
mm²	Cu	Al	Cu	Al	Cu	Al	Plain Wires ohms/km
1.5	7	–	6	–	–	–	12.1
2.5	7	–	6	–	–	–	7.41
4	7	–	6	–	–	–	4.61
6	7	–	6	–	–	–	3.08
10	7	7	6	6	–	–	1.83
16	7	7	6	6	–	–	1.15
25	7	7	6	6	6	6	0.727
35	7	7	6	6	6	6	0.524
50	19	19	6	6	6	6	0.387
70	19	19	12	12	12	12	0.268
95	19	19	15	15	15	15	0.193
120	37	37	18	15	18	15	0.153
150	37	37	18	15	18	15	0.124
185	37	37	30	30	30	30	0.0991
240	37	37	34	30	34	30	0.0754
300	61	61	34	30	34	30	0.0601
400	61	61	53	53	53	53	0.047

Whilst HONGDA CABLE plc endeavours to ensure the information on the website, specification sheets and all other technical information is accurate, the information is for guidance only and it is subject to change without notice or liability. HONGDA Cable Plc is not responsible for the consequences of any inadequacies, inaccuracies or other deficiencies contained therein. When selecting cable accessories, please note that the actual cable dimensions may vary due to manufacturing tolerances.
