JIS Standard 600V 2PNCT 3PNCT HT-PNCT FC-PNCT SC-PNCT PNCT-FCopper Conductor EPR Insulated Flexible Rubber Cable
PNCT Rubber Cable Feature:1. Conductor: Class 5 flexible plain copper conductor
2. Insulation: EPR(Ethylene Propylene Rubber)
3. Sheath: PCP(Polychioroprene)
4. Cores: 2 3 4 5 Cores or Others
5. Voltage: 600V
6. Temperature Rating: conductor operation temperature -40°C to +80°C
7. Standards:Japan’s Electrical Appliance and Material Safety Act, JIS C 3327,Technical Standards for
Electrical Equipmen
PNCT Rubber Cable Application
Pnct cables are used for moving equipment like unloader ,stacker & reclaimer,gantry crane, container crane,overhead crane
Gantry crane, etc. Its characteristics include high tension ,impact resistance abrasion resistance ,bending resistance
Flame retardance ,weather resistance ect.
Product Parameters:
|
Number of
Cores |
Composition
|
Outer
Dia |
Thickness
of Insulation |
Thickness
of Sheath |
Sheath
Overall Dia |
Conductor
Resis (20 )(Max.) |
Insulation
Resist (20 )(Min.) |
Weight
|
|
core sq mm
|
Max./mm
|
mm
|
mm
|
mm
|
mm
|
Ω/km
|
Ω/km
|
kg/km
|
|
3 X 6
|
0.26
|
3.6
|
1.1
|
2.2
|
19
|
3.39
|
400
|
600
|
|
3 X 10
|
0.26
|
4.8
|
1.1
|
2.4
|
22
|
1.95
|
300
|
850
|
|
3 X 16
|
0.26
|
6
|
1.2
|
2.6
|
25
|
1.24
|
300
|
1,170
|
|
3 X 25
|
0.26
|
7.4
|
1.2
|
2.8
|
28
|
0.795
|
300
|
1,600
|
|
3 X 35
|
0.26
|
8.7
|
1.2
|
3
|
31
|
0.565
|
200
|
2,010
|
|
3 X 50
|
0.26
|
10.4
|
1.5
|
3.3
|
37
|
0.393
|
200
|
2,800
|
|
3 X 70
|
0.26
|
12.5
|
2
|
3.7
|
44
|
0.277
|
200
|
3,990
|
|
3 X 95
|
0.26
|
14.5
|
2
|
4
|
49
|
0.21
|
200
|
5,080
|
|
3 X 120
|
0.26
|
16.2
|
2
|
4.2
|
53
|
0.164
|
200
|
6,130
|
|
3 X 150
|
0.26
|
18.2
|
2
|
4.5
|
58
|
0.132
|
200
|
7,450
|
|
3 X 185
|
0.26
|
20.2
|
2.5
|
4.9
|
65
|
0.108
|
200
|
9,290
|
|
3 X 240
|
0.26
|
23.3
|
2.5
|
5.3
|
72
|
0.0817
|
200
|
11,810
|
|
3 X 300
|
0.26
|
26
|
2.5
|
5.7
|
78
|
0.0654
|
200
|
14,310
|
|
4 X 6
|
0.31
|
3.6
|
1.1
|
2.3
|
21
|
3.39
|
400
|
730
|
|
4 X 10
|
0.31
|
4.8
|
1.1
|
2.5
|
24
|
1.95
|
300
|
1,050
|
|
4 X 16
|
0.31
|
6
|
1.2
|
2.7
|
27
|
1.24
|
300
|
1,450
|
|
4 X 25
|
0.31
|
7.4
|
1.2
|
3
|
31
|
0.795
|
300
|
2,010
|
|
4 X 35
|
0.31
|
8.7
|
1.2
|
3.2
|
35
|
0.565
|
200
|
2,570
|
|
4 X 50
|
0.31
|
10.4
|
1.5
|
3.5
|
41
|
0.393
|
200
|
3,540
|
|
4 X 70
|
0.31
|
12.5
|
2
|
4
|
49
|
0.277
|
200
|
5,030
|
|
4 X 95
|
0.31
|
14.5
|
2
|
4.3
|
54
|
0.21
|
200
|
6,420
|
|
4 X 120
|
0.31
|
16.2
|
2
|
4.6
|
59
|
0.164
|
200
|
7,780
|
|
4 X 150
|
0.31
|
18.2
|
2
|
4.9
|
64
|
0.132
|
200
|
9,460
|
|
4 X 185
|
0.31
|
20.2
|
2.5
|
5.4
|
72
|
0.108
|
200
|
11,830
|
|
4 X 240
|
0.31
|
23.3
|
2.5
|
5.8
|
80
|
0.0817
|
200
|
15,060
|
|
4 X 300
|
0.31
|
26
|
2.5
|
6.3
|
88
|
0.0654
|
200
|
18,290
|
