Housing Wire Single Core 1.5mm2 2.5mm2 Flexible Copper / PVC UL Cable
Housing Wire Single Core 1.5mm2 2.5mm2 Flexible Copper / PVC UL Cable image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
Housing wire Single Core 1.5mm2 2.5mm2 Flexible Copper Cable PVC Insulation UL cable
Conductor:Stranded bare copper or tinned copper
Insulation:PVC
Jacket Material:PVC
Features & Conformity:
Features : Super fine conductor, flexible for small bending angle . Durable for certain external mechanical forces
Conformity Approval :ISO SGS CCC BV CE
Technical Parameter:
Rated Voltage: 300/500V, 450/750V
Min. bending Radius:
Fixed Installation: 5×D(Cable OD) : Movable Installation: 8×D(Cable OD)
Temperature Range:Fixed Installation: -20 to +70ºC ;Movable Installation: -5 to +70ºC
| Product Code | Nominal cross-sectional area of conductor | Class of conductor | Thickness of insulation | Thickness of outer sheath | Mean overall diameter | |
| Lower limit | Upper limit | |||||
| mm2 | mm | mm | mm | mm | ||
| RVV-2C1.5 | 2X1.5 | 5 | 0.7 | 0.8 | 6.8 | 8.6 |
| RVV-2C2.5 | 2X2.5 | 5 | 0.8 | 1.0 | 8.4 | 10.6 |
| RVV-3C1.5 | 3X1.5 | 5 | 0.7 | 0.9 | 7.4 | 9.4 |
| RVV-3C2.5 | 3X2.5 | 5 | 0.8 | 1.0 | 9.2 | 11.4 |
| RVV-4C1.5 | 4X1.5 | 5 | 0.7 | 1.0 | 8.4 | 10.5 |
| RVV-4C2.5 | 4X2.5 | 5 | 0.8 | 1.1 | 10.1 | 12.5 |
| RVV-5C1.5 | 5X1.5 | 5 | 0.7 | 1.1 | 9.3 | 11.6 |
| RVV-5C2.5 | 5X2.5 | 5 | 0.8 | 1.2 | 11.2 | 13 |
CONTACT US FOR MORE :
We are China Housing Wire Single Core 1.5mm2 2.5mm2 Flexible Copper / PVC UL Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
