Hongda House Wiring Electrical Cable Wire 10mm 8mm Thw Building Wire

Hongda House Wiring Electrical Cable Wire 10mm 8mm Thw Building Wire image

Get Latest Price Request a quote

Product Details

Model NO.

Electrical Cable Wire

Application

Heating, Underground

Conductor Material

Copper

Sheath Material

No Sheath

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Flame Retardant

Certification

ISO9001, CCC

Brand

OEM

Transport Package

Wooden Drum

Specification

500MCM

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

500 Kilometer/Month

Product Description

Cable Description

Plain annealed flexible copper conductor, insulated with a flexible grade PVC.

Cable Application

For the wiring of:

Control panels Light fittings Appliances

Cable Specification

Voltage Rating		300/500V 450/750V 600/1000V
Temperature Range		-10°C to 70°C
Core colour		Black, blue, brown, green/yellow, grey, orange, pink, purple, red, white, yellow

CONSTRUCTION

Conductor: Plain annealed copper wire, stranded according to IEC(EN) 60228 class 5.

Insulation: PVC compound

COLOUR CODE

Insulation colour as per bs7671

	with earth conductor	without earth conductor
2Cores	–	Brown,Blue
3Cores	Yellow/Green,Brown,Blue	Brown,Gray,Black
4Cores	Yellow/Green,Brown,Gray,Black	Brown,Gray,Black,Blue
5Cores	Yellow/Green,Brown,Gray,Black,Blue	Brown,Gray,Black,Blue,Black
above 5 Cores	Yellow/Green,Black Numbered	Black Numbered

PHYSICAL AND THERMAL PROPERTIES

Temperature range during operation: Max.90°C for XLPE

250°C in short-circuit for 5s max.

Minimum bending radius: 6 x Overall Diameter

Spes of flexible cable:

CABLE SIZE	NOMINAL STRANDING No.x DIAMETER	APPROX. OVERALL DIAMETER	CURRENT RATING Note 1	VOLT DROP	APPROX. CABLE WEIGHT MASS PER 100M COIL
(mm2)		(mm)	(A)	(MV/A/M)	(kg)
				(note 1)	(note 1)
0.5	15w x 0.20	2.48	3	93	0.99
0.75	22w x 0.20	2.68	6	62	1.07
1.0	29w x 0.20	2.86	10	44	1.53
1.50	28w x 0.25	3.12	16	29	2.00
2.50	46w x 0.25	3.54	27	18	2.94
4.0	52w x 0.30	4.48	37	11	4.72
6.0	84w x 0.30	5.20	47	7.30	7.30
10.0	140w x 0.30	6.12	65	4.40	11.34
16.0	200w x 0.30	9.50	87	2.80	22.0
25.0	312w x 0.30	12.50	114	1.75	30.0
35.0	440w x 0.30	12.90	141	1.25	40.0

Note 1: Based on a max ambient temperature of 30°C and a max conductor temperature of 70°C

Packing shipping

Any problem and inquiry pls contact with Tina
Phone number: +86-15737156317

We are China Hongda House Wiring Electrical Cable Wire 10mm 8mm Thw Building Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
