Product Details

Model NO.

HG 1000

Current

DC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC

Model

YJV

Brand

OEM

Color

Red Blue Black Yellow Green

Transport Package

in Drum or in Pallent

Specification

5*1.5 5*2.5

Trademark

OEM

Origin

Henan

HS Code

8544492100

Production Capacity

10000 M Per Day

Product Description

STANDARDS

IEC 60502

NFC

APPLICATION

U-1000 R2V cables can be used in all low voltage power installations. Multiconductors cables are adapted

to remote control and telecontrol installations.

In case of high ambiant temperature, use correction coefficient.

INSTALLATION

These cables can be fixed on cable trays, within conduits or fixed to walls. They also can be buried directly

with extra mechanical protection.

Cross sections 1,5 – 2,5 and 4 mm² have to be of class 2 flexiblility, if the cable is connected to equipment

subject to vibration.

CONSTRUCTION
Conductor material	Bare copper
Insulation	XLPE (chemical)
Outer sheath	PVC
Sheath colour	Black
ELECTRICAL
Rated Voltage Uo/U (Um)	0.6/1 kV
MECHANICAL
Mechanical resistance to impacts	Good
Cable flexibility	Rigid
USAGE
Max. conductor temperature in service	85°C
Short-circuit max. conductor temperature	250°C
Operating temperature, range	– 10 .. 60°C
Weather resistance	Very good
Flame retardant	C2, NF C 32-070
Chemical resistance	Accidental
Bending factor when laying	6(xD)
