H1 Xdv-as/Ar Power Cables NF C 33-210 Aluminum Underground Cable 3X95+1X70 3X150+1X95 0.6/1kv
H1 Xdv-as/Ar Power Cables NF C 33-210 Aluminum Underground Cable 3X95+1X70 3X150+1X95 0.6/1kv image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
Cable Application
Characteristics
The phase conductors are made of solid or stranded circular (class 2) aluminum depending on type.
The neutral conductor made of Core : aluminum stranded circular (class 2) of solid round and sheathed with lead.
The watertightness between the lead sheath is made with a waterproof material.
Conductor: Solid or stranded copper
Insulation: Cross-linked polyethylene (XLPE) or Polyvinyl chloride (PVC)
Filler: Polypropylene filament with lapped binding tape
Binder: Binding tape
Inner sheath: Polyvinyl chloride (PVC)
Amour: steel tape armored(STA)
Sheath: Polyvinyl chloride (PVC)
Electrical characteristics
- Rated Voltage : 0.6/1 kV.
- Test Voltage : 3.5 kV for 15 minutes.
- Resistance of the sheath to voltage surges : 1.2/50 µs with positive or negative polarity and a peak value of 20 kV.
| Normal Section Area | Shape of Conductor | Insulation Thickness | Jacket Thickness | Overall Diameter | Approx Weight |
| mm2 | mm | mm | mm | kg/km | |
| 3×95+1×70 | SM/RE | 1.1 | 2.0 | 35 | 1759 |
| 3×150+1×95 | SM/RE | 1.4 | 2.2 | 43 | 2560 |
| 3×240+1×115 | SM/RE | 1.7 | 2.4 | 53 | 2705 |
Why Choose Us ?
1. We have a large production base, and advanced production equipment
2. Have an competitive price and high quality
3. Excellent after-sale service
4. Free issue:packaging list,invoice
5. Powerful technology team
6. Strict quality assurance system and perfect testing means
7. Advanced process equipment
8. Delivery on time
9. Our cable sales to Middle East,Africa,Russia,Southeast Asia, etc.
10.We have a good reputation in the overseas
Any problem and inquiry pls contact with Tina
We are China H1 Xdv-as/Ar Power Cables NF C 33-210 Aluminum Underground Cable 3X95+1X70 3X150+1X95 0.6/1kv manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
