H07vvh6-F Flexible Copper PVC Shielded Flat Travelling Hanger Crane Elevator Cable

H07vvh6-F Flexible Copper PVC Shielded Flat Travelling Hanger Crane Elevator Cable image

Get Latest Price Request a quote

Product Details

Model NO.

H07VVH6-F

Insulation Material

PVC

Sheath Material

PVC

Material Shape

Flat Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE, VDE

Model

H05vvh6-F

Brand

Huadong

Product Name

H07vvh6-F Elevator Traveling Cable

Rated Voltage

450/750V

Cross Section Size

1.5 2.5 4 6 10 16mm

Cores

4 5 7 8 10 12 18 24 Cores or Customized

Standards

IEC/En 60332

Temperature

-20 to 70 Centigrade

Warranty

100% Qualified

Sample

Available

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

H07VVH6-F flexible copper pvc shielded flat travelling hanger crane elevator cable

H07VVH6-F Flat PVC Cable Feature:
1. Conductor: Class 5 flexible plain copper conductor
2. Insulation: PVC (Polyvinyl Chloride)
3. Sheath: PVC (Polyvinyl Chloride)
4. Cores: 4 5 7 8 10 12 18 24 Cores or Customized
5. Voltage: 450/750V
6. Temperature Rating:-20°C to +70°C
7. Minimum Bending Radius:8 x overall diameter

H07VVH6-F Flat PVC Cable Application:H07VVH6-F power and control flat cables can be used on festoons systems on handling equipment as overhead cranes,
eleavors,conveyors ect.They are specially designed for indoor and outdoor applications

H07VVH6-F Flat PVC Cable Parameters:

No. of Cores x Nominal Cross Sectional Area	Nominal Conductor Diameter	Nominal Thickness of Insulation	Nominal Overall Diameter	Nominal Copper Weight	Nominal Weight
4 x1.5	1.5	0.8	5.1 x 14.8	130	58
5 x1.5	1.5	0.8	5.1 x 17.7	158	72
7 x1.5	1.5	0.8	5.1 x 25.2	223	101
8 x1.5	1.5	0.8	5.1 x 27.3	245	115
10 x1.5	1.5	0.8	5.1 x 33.9	304	144
12 x1.5	1.5	0.8	5.1 x 40.5	365	173
18 x1.5	1.5	0.8	6.1 x 61.4	628	259
24 x1.5	1.5	0.8	5.1 x 83.0	820	346
4 x2.5	1.9	0.8	5.8 x 18.1	192	96
5 x2.5	1.9	0.8	5.8 x 21.6	248	120
7 x2.5	1.9	0.8	5.8 x 31.7	336	168
8 x2.5	1.9	0.8	5.8 x 33.7	368	192
10 x2.5	1.9	0.8	5.8 x 42.6	515	240
12 x2.5	1.9	0.8	5.8 x 49.5	545	288
24 x2.5	1.9	0.8	5.8 x 102.0	1220	480
4 x4	2.5	0.8	6.7 x 20.1	154	271
5 x4	2.5	0.8	6.9 x 26.0	192	280
7 x4	2.5	0.8	6.7 x 35.5	269	475
4 x6	3.0	0.8	7.2 x 22.4	230	359
5 x6	3.0	0.8	7.4 x 31.0	288	530
7 x6	3.0	0.8	7.4 x 43.0	403	750
4 x10	4.0	1.0	9.2 x 28.7	384	707
5 x10	4.0	1.0	11.0 x 37.5	480	1120
4 x16	5.6	1.0	11.1 x 35.1	614	838
5 x16	5.6	1.0	11.2 x 43.5	768	1180

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International
Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced
20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers
We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC
Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.
